Programming the speed dome

The speed dome setup menu allows the operator to customise and
program all aspects of speed dome operation. All menu settings are
retained in non-volatile memory so if power is lost to the speed dome
for any reason, all settings will be retained.
M A I N M E N U
- - - - - - - - - - - - - - - - - - - - - - - - - - - - -
< S Y S T E M I N F O R M A T I O N >
< D I S P L A Y S E T U P >
< D O M E C A M E R A S E T U P >
< A L A R M S E T U P >
< S Y S T E M I N I T I A L I S E >
< P A S S W O R D S E T U P >
< H E L P >
E X I T
To access the speed dome setup menu, key:
SHOT - 95 - ENTER
To navigate the main menu, move the joystick
up / down to choose a menu item or change
settings within a menu item.
To enter a menu item or confirm a new setting,
key:
NEAR
To exit a menu item or cancel a new setting,
key:
FAR
Where a menu item is surrounded by
brackets, it indicates that there is a sub menu.
: 2.5W036V
Where a menu screen shows
EXIT
, selecting
this option will exit the menu and the speed
dome will return to normal operation. Where a
menu screen shows
BACK
, selecting this
option will return to the higher menu level.
The main menu has five options:
<SYSTEM INFORMATION>
- Provides
information such as firmware version, protocol
and ID values as defined by the dip switch
settings.
<DISPLAY SETUP>
- Allows the operator to
specify which On Screen Display information
is shown during normal operation. Also allows
privacy zones to be defined and time/date to
be changed
<DOME CAMERA SETUP>
- Allows all
operating features of the speed dome to be
programmed and managed. Also allows
settings for the camera module to be changed
<PASSWORD SETUP>
- Allows a password
to be set to protect the speed dome setup
<SYSTEM INITIALISE>
- Allows various
speed dome settings to be reset to factory
defaults
System information
S Y S T E M I N F O R M A T I O N
- - - - - - - - - - - - - - - - - - - - - - - - - - - - -
F I R M W A R E V E R
1.0SY28V
C O L O U R S Y S T E M
: P A L
P R O T O C O L
: P E L C O - D
A D D R E S S
: 0 0 1
B A U D R A T E
: 2 4 0 0
C o m m . M O D E
R S 4 2 2 / R S 4 8 5
B A C K
E X I T
From the main menu, use the joystick to
highlight
SYSTEM INFORMATION
and key:
NEAR
To return to the main menu, highlight
BACK
and key:
NEAR
To exit the setup menu completely, highlight
EXIT
and key:
NEAR
Display setup
D I S P L A Y S E T U P
- - - - - - - - - - - - - - - - - - - - - - - - - - - - -
C A M E R A I D
O N / O F F
A C T I O N T I T L E
O N / O F F / A U T O
P T Z I N F O R M A T I O N
O N / O F F / A U T O
P R E S E T L A B E L
O N / O F F / A U T O
A L A R M I / O
O N / O F F
D A T E / T I M E
O N / O F F / A U T O
< D A T E T I M E S E T U P >
< P R I V A C Y Z O N E >
B A C K
E X I T
From the main menu, use the joystick to
highlight
DISPLAY SETUP
and key:
NEAR
CAMERA ID (ON / OFF)
- shows camera ID
according to the DIP switch settings, eg
CAM 1.
ACTION TITLE (ON / OFF / AUTO)
- shows
current speed dome action, eg PRESET3.
PTZ INFORMATION (ON / OFF / AUTO)
shows the current pan / tilt position in degrees
and the current zoom level.
PRESET LABEL (ON / OFF / AUTO)
preset title (if defined) when a preset is called.
ALARM I/O (ON/OFF)
- shows real time
status of the alarm inputs and outputs.
<DATE TIME SETUP)
- sub menu to change
the date and time
<PRIVACY ZONE>
- sub menu to setup the
speed dome privacy zones
Highlight the item to modify and key:
NEAR
Use the joystick to change the setting and key:
NEAR
to save or:
FAR
to cancel.
Note: If the auto option is chosen, the relevant
information is displayed for a few seconds
8
before disappearing.
DATE TIME SETUP
D A T E / T I M E S E T U P
- - - - - - - - - - - - - - - - - - - - - - - - - - - - -
D A T E
0 7 - 0 1 - 0 7 / S U N
T I M E
1 4 : 3 7 : 1 5
B A C K
E X I T
From the display setup menu, use the joystick
to highlight
DATE/TIME SETUP
NEAR
Highlight the item to modify and key:
Move the joystick up and down to change an
individual value and left and right to move to
the previous / next value
-
- shows
and key:
NEAR
