Box Contents - CODELOCKS 0460 Installation Instructions

0460/0465 0470/0475
O460 – Narrow stile lock case complete with
threaded cylinder and cams.
0465 – Narrow stile lock case complete with
passage function, threaded cylinder and cams.
O470 – Narrow stile lock case complete with
euro profile cylinder and cams.
0475 – Narrow stile lock case complete with
passage function, euro profile cylinder and cams.
Note: Model number with a 'K' suffix indicates knob
handle. Model number with an 'L' suffix indicates lever
handle model.
Before installing please check

box contents.

BOX CONTENTS
A 1 x code front plate complete with threaded
cylinder (or europrofile cylinder)
B 1 x code front plate lever handle or knob
C 2 keys
D 1 x back plate
E 1 x back plate lever handle or knob
F 2 x neoprene seals
G 1 x cam plug for use with threaded
lockcase or europrofile lockcase
H 1 x gear ring for left hand hung doors
I 5 x fixing bolts (1 x spare)
J 1 x spindle set
K 1 x allen key
L 1 x tweezers
M 2 x spare tumblers (one red, one blue)
1 x code card
1 x template
1 x installation & operating instructions
1 x code change instructions
A
B E
B
C
G
F
H
I
M
D
E
K
L
J
