5-4 MODURATION ADJUSTMENTS
1) Select an adjustment item using [VOL].
2) Set or modify the adjustment value as specifi ed using [DIAL], then push [BAND] to store the adjustment value.
ADJUSTMENT
FM (Wide)
1 • Frequency: Displayed
DEVIATION
• Transmitting
VHF (Low band)
VHF (High band)
2 • Frequency: Displayed
• Transmitting
UHF ( Low band)
3 • Frequency: Displayed
• Transmitting
UHF (High band)
4 • Frequency: Displayed
• Transmitting
VHF (Low band)
5 • Frequency: Displayed
• Transmitting
VHF (High band)
6 • Frequency: Displayed
• Transmitting
UHF ( Low band)
7 • Frequency: Displayed
• Transmitting
UHF (High band)
8 • Frequency: Displayed
• Transmitting
¤ CONNECTION
SETTING
HPF
: OFF
LPF
: 20 kHz
• POWER SUPPLY
AMMETER
+
−
+
–
DC power supply
6–10 V/3 A
TRANSCEIVER'S
CONDITION
1) Connect a modulation analyzer to
the antenna connector through an
attenuator, and set it as;
2) Connect an audio generator to the JIG
cable #2 and set it as;
• Set the audio generator as;
MODULATION ANALYZER
(30 – 600 MHz)
VOLTAGE METER
+
−
+
–
OPERATION
HPF
: OFF
LPF
: 20 kHz
Frequency : 1 kHz
Level
: 150 mVrms
Level
: OFF
JIG CABLE #2
(See the page 5 -1.)
ATTENUATOR
(30 dB/10 W)
"7.2 V"
5 - 8
ADJUST-
MENT
VALUE
ITEM
± 4.1 to ± 4.3
Minimum level
To [MIC]
kHz
