¤ ENTERING ADJUSTMENT MODE
1) Turn the transceiver's power OFF.
2) Connect the JIG cable "#1" (See the page 5-1) to the [SP] jack.
3) While pushing [SET], [BAND] and [V/M/C], turn the transceiver's power ON.
JIG CABLE #1
(See the page 5 -1.)
To [SP]
[V/M/C]
[SET]
[BAND]
¤ KEY ASSIGNMENTS FOR THE ADJUSTMENT MODE
Adjust the value for the item
Selects previous and next adjustment item
Adjustment frequency
Adjustment item
Operating mode for the adjustment
Stores the adjustment value
¤ QUITTING ADJUSTMENT MODE
1) Turn the transceiver's power OFF.
2) Disconnect the JIG cable, then turn the transceiver's power ON.
5 - 2
