Summary of Contents for Escea AF series
-
Page 1: User Guide
User Guide AF-Series Gas Fireplace For the latest documentation, visit www.escea.com 630337_2... - Page 2 SPONSIBLE PERSON TO ENSURE THAT THEY CAN USE THE APPLIANCE SAFELY. YOUNG CHILDREN SHOULD BE SUPERVISED TO ENSURE THAT THEY DO NOT PLAY WITH THE APPLIANCE. Escea NZ Ltd Manufactured by: 17 Carnforth st, PO Box 5277 Dunedin, New Zealand Email: info@escea.co.nz...
-
Page 3: Table Of Contents
Contents Remote Control Layout Basic Operation Initial Start / Battery Placement Adjusting the Room Temp Fan Boost Effect Only Setting the Time Keylock Timer Operation Activate Timer De-activate Timer Auxiliary On/Off Button Over Temp Shutoff Operation Sound and Smell Sounds Fan: Gas Control Valve: Appliance Metalwork:... -
Page 4: Remote Control Layout
Remote Control Layout Display Shows temperature settings and status of timers and other functions On / Off Switches the appliance on and off. Flame Effect Places the fire in a constant low Fan Boost output mode. Puts the fan into a high output mode. Minus Adjusts the temperature and time Plus... -
Page 5: Basic Operation
Basic Operation − Initial Start / Battery Placement Remove the battery cover on the rear of the remote. Insert the new “AA” size batteries, being careful of the polarity. You should now see on the display of the remote the time showing “0:00”. To turn the fire on, press the “POWER”... -
Page 6: Keylock
Keylock Should you wish to keep the fire from being tampered with by children or to discourage people from altering the temperature you can engage a keylock function which stops the remote buttons from changing any settings. To engage the keylock simply press the “Flame Effect”... -
Page 7: Auxiliary On/Off Button
“Set” temperature. Your Escea gas fire has a setting where it will turn off the main burner once the “Room” temperature exceeds the “Set” temperature, leaving only the pilot lit. The main burner will re-light when the “Room” temperature falls back below the “Set”... -
Page 8: Sound And Smell
− Fan: Escea gas appliances use electric fans to push heated air further into the room. It is not unusual for the fan to make a “whirring” sound when ON. This sound will increase or decrease in volume depending on the thermostatic settings. -
Page 9: Fascia, Log And Glass Care
NEVER, EVER RUB THE FASCIA. The outside of an Escea Fascia must only be cleaned with a soft microfibre cloth. If heavier cleaning is required for the likes of grease or stubborn fingerprint removal we recommend the use of: Steel Kleen brand Ezi Wipes for stainless steel fascias only, and warm soapy water for powder coated fascia’s. -
Page 10: Trouble Shooting
Trouble shooting Escea gas fires communicate both to and from the fire and remote. This enables the remote to provide some basic fault finding information that is useful in diagnosing faults with your gas supply or flue. NOTE: The remote will take a minute or two to receive and display the error from the fire. Pressing the plus or... -
Page 11: Power Failure
The valve solenoids have failed the pre-ignition test. This is to detect a faulty valve solenoid. However, it is possible a wire has dislodged. • Check that the connections to each solenoid are secure and in place. It may be that the connections on the ends of the wires need to be tight- Valve Solenoid ened a little (e.g.
