Changing the Test Setup

To change the test parameters, follow these steps:
1 Choose Test Setup from the Test menu in the main
window of the Configuration and Diagnostic Program, or
use the <Test Setup> command button in the Run Tests
dialog box.
2 Press [Tab] to highlight any of the fields within the Test
Setup dialog box.
3 To change a setting in any field, follow these steps:
a In the Group Select box, use the arrow keys to select a
b In the Group X Tests box, use the arrow keys to highlight a
c In the Repetitions box, specify the number of times you
d In the Errors box, press the [Space Bar] to select or
4 When you are satisfied with the new test setup, highlight
the <OK> command button and press [Enter].
5 To run the tests, choose Run Tests from the Test menu and
select the <Start> command button.

Miscellaneous Checks

Check for specific hardware problems, such as broken traces
or loose/broken solder connections.
If you have installed the adapter correctly and you still
experience problems, check the software.
test group.
test. Press the [Space Bar] to enable or disable an
individual test.
want to run the tests, or use the arrow keys to select the
Continuous option.
deselect the Halt on Error parameter.
Changing the Test Setup 4-9
