Page 1: Installation Guide
AT-RS710TX, AT-RS718TX, and AT-FS708 Ethernet and Fast Ethernet Switches Installation Guide PN 613-10676-00 Rev. A... - Page 2 Copyright ©1997 Allied Telesyn International Corp. All rights reserved. No part of this publication may be reproduced without prior written permission from Allied Telesyn International Corp. Allied Telesyn International Corp. reserves the right to make changes in specifications and other information contained in this document without prior written notice. The information provided herein is subject to change without notice.
-
Page 3: Electrical Safety And Installation Requirements
Electrical Safety and Installation Requirements STANDARDS: This product meets the following standards U.S. Federal Communications Commission RADIATED ENERGY Note: This equipment has been tested and found to comply with the limits for a Class A digital device pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. - Page 4 Electrical Safety and Installation Requirements LIGHTNING DANGER DANGER: DO NOT WORK on equipment or CABLES during periods of LIGHTNING ACTIVITY. INSTALLATION ELECTRICAL—AUTO VOLTAGE ADJUSTMENT This product will automatically adjust to any voltage between the ranges shown on the label. ELECTRICAL—TYPE CLASS 1 EQUIPMENT THIS EQUIPMENT MUST BE EARTHED.
- Page 5 SwitchBasics Series Installation Guide GERÄTE DER KLASSE 1 DIESE GERÄTE MÜSSEN GEERDET SEIN. Der Netzstecker darf nur mit einer vorschriftsmäßig geerdeten Steckdose verbunden werden. Ein unvorschriftsmäßiger Anschluß kann die Metallteile des Gehauses unter gefährliche elektrische Spannungen setzen. NETZKABEL Das Netzkabel sollte eine maximale Länge von 4,5 Metern, einen Nennwert von mindestens 6 A und 250 V haben, aus HAR-Material hergestellt und mit einer gepreßten, IEC 320 entsprechenden, Anschlußverbindung an einem Ende, und am anderen Ende mit einem im Land des Endverbrauchers geprüften Stecker ausgestattet sein.
- Page 6 Electrical Safety and Installation Requirements ELEKTRISK—KLASSE 1-UDSTYR DETTE UDSTYR KRÆVER JORDFORBINDELSE. Stikket skal være forbundet med en korrekt installeret jordforbunden stikkontakt. En ukorrekt installeret stikkontakt kan sætte livsfarlig spænding til tilgængelige metaldele. ELEKTRISK—EDNING Anvend ledning af maksimum 4,5 meters længde, med en kapacitet på minimum 6 amp., 250 v, bestående af en IEC 320 connector med indstøbt HAR ledning i den ene ende og et stik i den anden ende, der er godkendt af myndighederne i brugerlandet.
- Page 7 SwitchBasics Series Installation Guide ELEKTRISCHE SNOEREN Gebruik een elektrisch snoer, maximum 4,5 meter lang, berekend voor ten minste 6 ampåçère, 250 V, uit HAR vervaardigd, met aan het ene uiteinde een gevormd IEC 320 aansluitstuk en aan het andere uiteinde een stekker die goedgekeurd is door het land waar het toestel gebruikt zal worden.
- Page 8 Electrical Safety and Installation Requirements ATTENTION: Ne pas bloquer les fentes d’aération, ceci empêcherait l’air ambiant de circuler librement pour le refroidissement. TEMPÉRATURE DE FONCTIONNEMENT Ce matériel est capable de tolérer une température ambiante maximum de 40 degrés Celsius. POUR TOUS PAYS : Installer le matériel conformément aux normes électriques nationales et locales.
- Page 9 SwitchBasics Series Installation Guide KAIKKI MAAT: Asenna tuote paikallisten ja kansallisten sähköturvallisuusmääräysten mukaisesti. STANDARD: Questo prodotto è conforme ai seguenti standard. AVVERTENZA: in ambiente domestico questo prodotto potrebbe causare radio interferenza. In questo caso potrebbe richiedersi all’utente di prendere gli adeguati provvedimenti. Emissione RFI (interferenza di radiofrequenza) EN55022 Classe A AVVERTENZA: questo prodotto richiede cavi schermati per adeguarsi ai limiti di emissione...
- Page 10 Electrical Safety and Installation Requirements SIKKERHETSNORMER: Dette produktet tilfredsstiller følgende sikkerhetsnormer. ADVARSEL: Hvis dette produktet benyttes til privat bruk, kan produktet forårsake radioforstyrrelse. Hvis dette skjer, må brukeren ta de nødvendige forholdsregler. RFI stråling EN55022 Klasse A ADVARSEL: Det må benyttes isolerte kabler med dette produktet for å tilfredsstille Klasse A strålingsgrenser.
- Page 11 SwitchBasics Series Installation Guide PADRÕES: Este produto atende aos seguintes padrões. AVISO: Num ambiente doméstico este produto pode causar interferência na radiorrecepção e, neste caso, pode ser necessário que o utente tome as medidas adequadas. Emissão de interferência de radiofrequência EN55022 Classe A AVISO: Este produto requer cabos protegidos a fim de obedecer aos limites de emissão da Classe A.
- Page 12 Electrical Safety and Installation Requirements ESTÁNDARES: Este producto cumple con los siguientes estándares. ADVERTENCIA: en un entorno doméstico, este producto puede causar radiointerferencias, en cuyo caso, puede requerirse del usuario que tome las medidas que sean convenientes al respecto. Emisión RFI EN55022 Clase A ADVERTENCIA: este producto requiere de cables armados para cumplir con los límites de emisión de Clase A.
- Page 13 SwitchBasics Series Installation Guide STANDARDER: Denna produkt uppfyller följande standarder. VARNING: Denna produkt kan ge upphov till radiostörningar i hemmet, vilket kan tvinga användaren till att vidtaga erforderliga åtgärder. Radiostörning EN55022 Klass A VARNING: Skärmkabel bör användas med denna produkt för att uppfylla kraven gällande radiostörningar enligt Klass A.
-
Page 15: Table Of Contents
Table of Contents Electrical Safety and Installation Requirements ........iii Chapter 1 Product Description ..................1 Overview ......................1 Common Major Features..................2 Physical Description....................4 DIP Switches ....................4 Connectors ....................5 Front Panel LEDs ..................6 MDI Button....................7 Power Supply....................8 Required Voltage ..................8 Auto-Negotiation ....................8 Chapter 2 Installation .....................11 Before you Proceed ....................11... - Page 16 Appendix A Switch Specifications .................. 23 Physical Characteristics................... 23 Safety Agency....................23 Cabling Specifications ..................24 Electrical Specifications ................... 24 UTP (RJ45) Connector..................24 Low Last Bit-to-First Delay ................24 Network Specifications..................25 100Base-TX Cable..................... 25 100Base-TX Connector Pinouts ............... 26 Straight-through Cable ................
-
Page 17: Chapter 1 Product Description
Chapter 1 Product Description Overview This chapter describes the features of the following unmanaged Ethernet and Fast Ethernet switches: AT-RS710TX AT-RS718TX AT-FS708 Each switch model is described in Table 1: Table 1: Switch Models and Port Description Model Description AT-RS710TX... -
Page 18: Common Major Features
Product Description Table 1: Switch Models and Port Description (Continued) Model Description AT-FS708 Eight auto-negotiating 10/100 Mbps twisted pair RJ45 ports One MDI button on Port 8 Total bandwidth of 800 Mbps Note For definitions of technical terms associated with Allied Telesyn’s products, refer to the Glossary on Allied Telesyn’s website at www.alliedtelesyn.com. -
Page 19: Dip Switches
AT-RS710TX, AT-RS718TX, and AT-FS708 Switches Installation Guide Figure 1 and Figure 2 show the front panels of the AT-RS710TX and the AT-RS718TX, respectively. The sample rear panel in Figure 3 shows the DIP switches present in these models for setting each 10 Mbps port to either half or full duplex transmission. -
Page 20: Physical Description
DIP switches on the AT-RS710TX and AT-RS718TX Connectors Media-dependent interface button LEDs Power supply DIP Switches The AT-RS710TX and the AT-RS718TX switches are equipped with DIP switches in the rear panel. This enables you to configure each 10 Mbps port for half or full duplex transmission. -
Page 21: Connectors
AT-RS710TX, AT-RS718TX, and AT-FS708 Switches Installation Guide Note Since Ports A and B are capable of auto-negotiation, they have no associated DIP switches. The same reasoning applies to all eight ports on the AT-FS708 switch. More details are provided in Chapter 2. -
Page 22: Front Panel Leds
100M FULL DUPLEX COLLISION POWER LINK/ACTIVITY Figure 5: A Close Up of the AT-RS718TX Front Panel LEDs Note The AT-RS710TX does not have port numbers 9 through 16. 100M COLLISION FULL DUPLEX ACTIVITY POWER LINK Figure 6: A Close Up of the AT-FS708 Front Panel LEDs... -
Page 23: Mdi Button
Off means the bandwidth is 10 Mbps. 100M Green On means the bandwidth is 100 Mbps. Applies to Ports A and B on the AT-RS710TX and the AT-RS718TX and to all ports on the AT-FS708. Blinking indicates the port is detecting a collision. COLLISION Amber Applies to half duplex transmission only. -
Page 24: Power Supply
Auto-Negotiation The 10/100 Mbps ports on the following models are capable of auto-negotiation: Ports A and B on the AT-RS710TX and the AT-RS718TX All 8 ports on the AT-FS708 This means these ports automatically adapt to the wire speed (10 or 100 Mbps) and duplex transmission (half or full) supported by the link without user reconfiguration. - Page 25 AT-RS710TX, AT-RS718TX, and AT-FS708 Switches Installation Guide The auto-negotiation protocol also includes automatic sensing of a port’s duplex mode, allowing auto-negotiation-capable end-system devices to not only configure the speed but also change to full duplex for even higher traffic throughput. This is particularly useful in environments where NICs are being replaced or desktop workstations are moved.
-
Page 27: Chapter 2 Installation
Before installing the switch, make sure you read “Electrical Safety and Installation Requirements” on page iii. Verifying Package Contents Make sure that the package includes the following items: One AT-RS710TX, AT-RS718TX, or AT-FS708 switch One AC power cord Two rackmounting brackets Four self-adhesive rubber feet... -
Page 28: Site Requirements
Installation Site Requirements Make sure you observe the following site requirements: Make sure you are placing the switch in a dust-free and moisture-free environment. Do not block ventilation openings on the unit. Make sure that the switch’s power is accessible and cables can be connected easily. -
Page 29: Rackmount Installation
AT-RS710TX, AT-RS718TX, and AT-FS708 Switches Installation Guide Rackmount Installation You will need a Phillips screwdriver for this installation. Caution Do not use power tools to perform this installation. If previously attached, remove the rubber feet and all cables and power cord from the switch. -
Page 30: Mdi Button Setting
If Your Switch Model Use this MDI Use This To Connect to Button Cable This Device Ports Are Position AT-RS710TX: Straight- Switch or hub (To HUB) through Port A (100 Mbps) and DTE (end station or server) Port 8 (To PC) -
Page 31: Full/Half Duplex Setting
The DIP switches are located in the rear panel and are set in the factory for half duplex. Each numbered DIP switch corresponds to the 10 Mbps port on the front panel. Figure 8 shows a close-up of the AT-RS710TX’s rear panel as an example. -
Page 32: Standalone Configuration
Cat 5, UTP wiring Figure 9: AT-RS710TX Connected to End Stations Cascade Configuration Cascading means that two switches can be connected together using any of the switch ports provided you maintain the same medium type. -
Page 33: Uplink Configuration
For 100 Mbps connection to the backbone, set the following ports to the To Hub position: Port A of either the AT-RS710TX or the AT-RS718TX Port 8 of the AT-FS708 Figure 11 illustrates how the AT-FS708 switches can be used as an uplink to the... - Page 34 Installation CORPORATE BACKBONE AT-FS708 Switch Sales Engineering AT-FS708 Switch AT-FS708 Switch Finance Formula 8200 Switch SNMP station Figure 11: Switches as Uplink to the Backbone...
-
Page 35: Chapter 3 Troubleshooting
Chapter 3 Troubleshooting This chapter describes the procedures to test and troubleshoot the switches. Connectivity Testing In the following procedure, you will test each port for a valid connection and to confirm the correct operation of the network. Start with Ports 1 and 2. Connect these two ports of a single switch to two nodes or workstations and turn on the switch power supply. -
Page 36: Problem Solving
Troubleshooting Problem Solving Is the unit receiving power? Check the POWER LED on the front of the switch. This green LED should be lit. If the power LED is not on: Check the back of the unit. Make sure the power switch is in the 1 position. - Page 37 AT-RS710TX, AT-RS718TX, and AT-FS708 Switches Installation Guide Problem 3: The MDI button is in the wrong setting. Solution 3: — When using the cascade port of the switch, you should set the button to the To HUB position; otherwise, the switch should be in the To PC position.
-
Page 39: Appendix A Switch Specifications
Appendix A Switch Specifications Physical Characteristics Chassis Dimensions: 13 in (330 mm) (L) x 8.7 in (220 mm) (W) x 1.7 in (43.2 mm) (H) Weight: 5.6 lbs. (2.6 kg.) Operating temperatures: 0° to 40° C Storage temperatures: -20° to 70° C Relative humidity: 10% to 90% (operating) 5% to 90% (storage) -
Page 40: Cabling Specifications
Switch Specifications Cabling Specifications STP/UTP Category 5 wiring, 100 ohm impedance 100 meters between switch and network node Electrical Specifications Power: Internal universal power supply with 100 to 120 VAC or 200 to 240 VAC, 50/60 Hz input. UTP (RJ45) Connector Figure 12 shows an RJ45 connector. -
Page 41: Network Specifications
AT-RS710, AT-RS718, and AT-FS708 Switches Installation Guide Network Specifications Table 6 provides an overview of IEEE 802.3 and 802.3u specifications for 10Base-T and 100Base-TX network configurations using shielded twisted-pair wiring. Table 6: IEEE 802.3 and 802.3u Network Specifications 10Base-T 100Base-TX Media Shielded Twisted Pair Shielded Twisted Pair... -
Page 42: 100Base-Tx Connector Pinouts
Switch Specifications 100Base-TX Connector Pinouts Straight-through Cable 1 TX+ TX+ 1 2 TX- TX- 2 3 RX+ RX+ 3 6 RX- RX- 6 Crossover Cable 1 TX+ TX+ 1 2 TX- TX- 2 3 RX+ RX+ 3 6 RX- RX- 6... -
Page 43: Technical Support Fax Order
Appendix B Technical Support Fax Order Name___________________________________________________________________ Company ________________________________________________________________ Address _________________________________________________________________ City ________________________ State/Province ________________________________ Zip/Postal Code ___________________ Country ________________________________ Phone _______________________________ Fax ________________________________ Incident Summary Model number of Allied Telesyn product I am using ______________________________ Network software products I am using _________________________________________ _______________________________________________________________________ Brief summary of problem __________________________________________________ _______________________________________________________________________... -
Page 45: At-Rs710, At-Rs718, And At-Fs708 Switches Installation Guide Feedback
Appendix C AT-RS710, AT-RS718, and AT-FS708 Switches Installation Guide Feedback Please tell us what additional information you would like to see discussed in the guide. If there are topics you would like information on that were not covered in the guide, please photocopy this page, answer the questions and fax or mail this form back to Allied Telesyn International Corp. -
Page 47: Appendix D Where To Find Us
Appendix D Where To Find Us For Technical Support or Service Location Phone Americas 1 (800) 428-4835 1 (425) 481-3790 United States, Canada, Mexico, Central America, South America Asia (+65) 3815-613 (+65) 3833-830 Singapore, Taiwan, Thailand, Malaysia, Indonesia, Korea, Philippines, China, India Australia (612) 416-0619 (612) 416-9764... - Page 48 Where To Find Us For Sales Information United States Australia Scottsdale, AZ Lindfield, NSW Tel: (602) 423-7087 Fax: (602) 423-7088 Tel: (612) 416-0619, Fax: (612) 416-9764 Los Angeles, CA Canada Tel: (310) 412-8684, Fax: (310) 412-8685 Rexdale, Ontario Mission Viejo, CA Tel: (416) 675-6738, Fax: (416) 675-0057 Tel: (714) 699-0628, Fax: (714) 699-0276 Richmond, British Columbia...
