Manual version........................... 7 About this manual ..........................7 CHAPTER 2. CONTENTS OF THE PACKAGE ................8 CHAPTER 3. WHAT CAN THE AT-RG624/634 DO FOR YOU?..........9 CHAPTER 4. PRODUCT DETAILS..................... 10 Top view of unit ..........................10 Rear view of unit ..........................12 CHAPTER 5.
AT-RG624/634 Series - User Manual 1. IMPORTANT SAFETY INSTRUCTIONS Please observe the following instructions, non-observance could lead to serious injury or even death, through fire or electric shock Save these instructions Do not open the unit Do not open this product except when there is a specific indication in the manual.
Page 5
AT-RG624/634 Series - User Manual Gas Leak Do not use the telephone to report a gas leak in the vicinity of the leak. Figure 3: Gas Leak Avoid harmful substances Be careful not to drop water or any other harmful substance onto the product.
Page 6
AT-RG624/634 Series - User Manual Do not use outside To avoid the risk of electrical shock or fire, this device, connecting peripherals and cables, should not be used in an outside environment. Figure 7: Do not use outside Do not use with non-standard plugs or wiring This could lead to fire, only use with industry standard plugs and wiring suitable for your territory.
AT-RG624/634 Series - User Manual Use the power adapter supplied Only the power adapter supplied with this unit is guaranteed to function correctly with this unit. Figure 11: Only use the power adapter supplied with this unit Conditions of use...
AT-RG624/634 Series - User Manual Handling Do not drop the unit, handle with care. Figure 14: Handling Product care Cleaning Keep the product free from dust and maintain in a clean condition. Unplug before cleaning. Figure 15: Unplug before cleaning...
June 2004 Rev. A2 About this manual Thank you for choosing the AT-RG624/634 Series Residential ADSL Gateway. Please read this manual carefully and use the device correctly. Please see below for the meaning of the icons used in this manual.
Wall Bracket User Manual Warranty Card (Notice) The package does not contain screws. The following items are included with each AT-RG624/634. Contact your sales representative if any items are damaged or missing. One AT-RG624/634 One AC/DC power adapter One wall bracket...
AT-RG624/634 Series - User Manual 3. What can the AT -RG624/634 do for you? The AT-RG624/634 is Customer Premise Equipment (CPE) designed for installation in a customer residence, it interfaces with new generation fibre/copper networks designed to support broadband communications.
AT-RG624/634 Series - User Manual 4. Product Details Top view of unit Figure 20: Top view AT-RG624 ADSL LED ADSL LAN 4 LAN 3 LNK/ACT LED LAN 2 LAN 1 SYSTEM LED SYSTEM POWER LED POWER Figure 21: Top view AT-RG634...
Page 13
AT-RG624/634 Series - User Manual Table 2: VoIP led indications RG634 State Function VoIP Green light on LED turns on green when you lift the receiver of the telephone or fax connected to at least one VoIP port and remains on during...
AT-RG624/634 Series - User Manual Rear view of unit Figure 22: Back view AT-RG624 Back view AT-RG634 ADSL port ADSL port DEFAULT DEFAULT TEL ports LAN ports LAN ports POWER POWER Table 5: Ports description Port Function TEL PORT (RG634) Connects analog telephone and fax with telephone cord DEFAULT Used to reset the unit;...
AT-RG624/634 Series - User Manual 5. Telephones and cables POTS Telephone and Fax Operation (AT - RG634 only) Check if the dial mode on your telephone/fax is set up for tone mode (T, Tone). If not, set the switch as shown below.
100BASE-T. There are two types of LAN cable, straight cable and crossed cable; for the AT-RG624/634, it does not matter which of these types of LAN cable you use. The LAN interfaces on the AT-RG624/634 can auto-sense whether the cable is straight or crossed.
AT-RG624/634 Series - User Manual 6. Installing the AT -RG624/634 Installation Before installing the AT-RG624/634, please read the safety information “For your Safety” in Chapter 1. When deciding the location of the device, please observe the following instructions: Do not install in direct sunlight, or a damp or dusty place...
Page 18
AT-RG624/634 Series - User Manual Wall mounting the RG624/634: • Using the wall mount bracket as a template drive 3 drywall screws horizontally into the plywood towards the top and to either side of the available space. If plywood is not available, then use the wall mount...
AT-RG624/634 Series - User Manual 7. Connecting the AT -RG624/634 Connecting the PSTN telephone ports (AT -RG634 only) Connect PSTN (POTS) telephone and PSTN fax units to the TEL ports with the appropriate telephone cords. Push in the plug of the telephone cord to the TEL port until you hear a “click”...
AT-RG624/634 Series - User Manual ADSL cable connection To connect to the ADSL port with the UTP telephone cord follow the steps below: • Ensure the cable is the right length to reach the terminator • Plug the ADSL cable into the ADSL port until you hear a “click” and make sure it is correctly fixed by pulling the ADSL cable lightly.
AT-RG624/634 Series - User Manual Disconnecting power supply This product doesn’t have a power switch; it automatically turns on when you connect the power cable. When you want to turn it off, just unplug the power plug. Figure 31: Power cable...
AT-RG624/634 Series - User Manual Appendix A: Troubleshooting This Appendix describes some of the more common problems that may occur during AT-RG624/634 installation and use. In the event of a problem, please look at the LED indications and then refer to this Appendix.
AT-RG624/634 Series - User Manual VoIP LED (AT-RG634 only) It indicates the status of telephone. Table 8: VoIP led Colour Statement Detail VoIP Green light on LED light turns green when you lift the receiver of the telephone or fax connected to the VoIP...
Page 24
AT-RG624/634 Series - User Manual Check also if the length of the cable is over the limit. UTP cable must be less than 100 m. To connect this product to a computer, you must use a straight cable. To connect this product to a HUB or switch, you must use a crossed cable.
