Copy Functions Explained
There are 3 possible copy functions available. These are;
Standard Copy, Enhanced Copy, and AB copy. Copy functions
are enabled/disabled in the Advanced Programming Options
(page 5).
Standard Copy: Pressing copy will copy the previous days
events into the displayed day. The unit will then display the 1st
event for the new day. This copy function is present only if the
unit is set to run in 5+2 or 7 day mode.
Enhanced Copy: The enhanced copy function is available in 7
day mode only. This allows any day to be copied to any other
day, or days. To use the enhanced copy function go into the
event programming using the PROG button, then:
1.
Use the
2.
Press the
When selected, the day should begin to fl ash.
3.
Use the
4.
Press
5.
Repeat steps 3 and 4 to select and copy other days.
6.
To stop copying, use the
fl ashing day and press the COPY button. The previously
fl ashing day will stop fl ashing to indicate it has been de-
selected.
NOTE: When a day has been copied to, it will remain visible and
not fl ashing when the DAY button is used to select other days.
AB Copy: The AB copy function is available in 5+2 mode only
and only if activated in the Advanced Programming setting.
A and B days, when selected, can be any group of days e.g. 5+2,
4+3 etc. The days do not have to run in sequence. For example,
to operate in a 5+2 day mode the days can be set as follows:
6
DAY button to fi nd the day to be copied from.
COPY button to select the day to be copied from.
DAY button to fi nd the day to be copied to.
COPY button to copy the selected day.
DAY button to go back to the
