Installation Instructions
Please Note:
qualifi ed electrician or competent heating installer, and
should be in accordance with the current edition of the
IEEE wiring regulations.
Product specifi cation
Specifi cation
Power supply
Switching action
Unit switch rating
Battery back-up
Programme resolution
Dimensions, mm (W, H, D)
Design standard
Control Pollution Situation
Rated Impulse Voltage
Ball Pressure Test
Installation
Remove wallplate from unit by unscrewing the two screws
on the bottom edge of the unit.
From the top left hand corner of the wallplate, there must
be clearances of at least 140 mm to the right, 15mm to the
left, 30mm above and 100mm below in order to mount the
plug-on module.
This product should only be installed by a
230V model
230 Vac,
±15%,
50/60 Hz
2 x SPDT internally linked,
Type 1B
230 Vac,
3(1)A
24 hours minimum
± 1 minute
135 x 88 x 32
EN 60730-2-7
Degree 2
2.5 kV
75°C
24V model
24 Vac,
±15%,
50/60 Hz
24Vac,
3(1)A
3
