Installation instructions
Resident building intercom 2 families
touch line
evolution
RFID secure keyless entry
Call
Communication: FULL-DUPLEX hands-free
Audio monitoring
Gate opening
Open lock alert
3 volume levels + turned off
Choose ringtone
Auxiliary function:
e.g.: auto gate/garage door opening
Extensions:
+3 additional indoor terminals
+3 additional outdoor panels
+1 doorbell: main indoor terminal connection
Staple here!
APE.2S0.x&x
www.electra.ro
APE.2S1.x&x
APE.2F0.x&x
APE.2F1.x&x
Advertisement
Table of Contents
Related Manuals for Electra APE.2S1.x&x
Summary of Contents for Electra APE.2S1.x&x
-
Page 1: Installation Instructions
Audio monitoring Gate opening Open lock alert 3 volume levels + turned off Choose ringtone Auxiliary function: e.g.: auto gate/garage door opening Extensions: +3 additional indoor terminals +3 additional outdoor panels APE.2S0.x&x APE.2F0.x&x +1 doorbell: main indoor terminal connection www.electra.ro... - Page 2 90% at +20 °C Cable 2 × 0,25 mm Outdoor panel protection class IP 34 Bd. Chimiei 8 • 700291 Tel. +40 232 214.370 clientfeedback@electra.ro Iași, ROMÂNIA Fax +40 232 232.830 office@electra.ro J22/1225/1991 • RO1962470 www.electra.ro page 2/6 Installation Instructions - edition: 17.09.2012...
- Page 3 ≈17 cm cable length Main cable Lock cable Special screw with wrench Name/Address Module Sticker B. Surface mounting Print the label using: Print Label ELT www.electra.ro Fastening clips Cable fastening and guiding piece ≈17 cm cable length (from the wall) Main cable Lock cable B4,2 × 60 Screw TORKS Screw (4 pcs.) 2.2 power supply + connection box (similar) A.
-
Page 4: Electrical Connections
12 Va . c . 230 Va . c . phase (230 V a.c. / 50 Hz) null earthing Transformer Outdoor panel BY Y2 Y1 Hubs specific to ELECTRA locks connection for opening the lock YEM.32x feed for Electra DC lock Electromagnetic lock Alternative current (AC) feed for Electra AC lock 2 x 0,5 mm... -
Page 5: Installation & Setup
insTall aTiOn seTup 4.1 verifying the accuracy of the connections and connecting the power supply check the correctness of the connections in the installation! The +14 V, C/D and GND signals are the same for all components of the installation. Any short-circuit between them will affect all the indoor terminals, causing them not to function. -
Page 6: Functions And Adjustments
4.4 programming the indoor terminals The installation does not work if 2 terminals share the same address! All indoor terminals leave the producer with address 1. The main indoor terminal will nOT be programmed. Operatorul 1 is programming from the main outdoor panel (address 1). Operator 1 Operator 2 Steps...
