USER MANUAL
EN
Door entry system terminals
ABS case + Secured Glass
classic AUDIO
Operating voltage:
11...14 Vd.c.
classic
Stand-by current:
PAS.27N
2 mAd.c.
Operating current:
40 mAd.c.
ABS case + Secured Glass
classic VIDEO
Operating voltage:
11...14 Vd.c.
classic
Stand-by current:
MCS.47N
2 mAd.c.
Operating current:
160 mAd.c.
1
EN Safety instructions
3
EN Installation
classic
AUDIO
Main
+14
terminal
COM
GND
Additional
DATA
terminal
+14
COM
GND
DATA
4
EN Installation - Video system connections
V0
GNV
+14V
COM
DATA
GND
MANUALUL UTILIZATORULUI
RO
Terminale sistem interfon
Carcasă ABS + Sticlă securizată
170 x 96 x 22 mm
0.3 kg
0 C ... 45 C – IP 31
o
o
Tensiune în funcționare:
11...14 Vc.c.
Curent în stand-by:
2 mAc.c.
Curent în funcționare:
40 mAc.c.
Carcasă ABS + Sticlă securizată
96 x 170 x 22 mm
0.4 kg
0 C ... 45 C – IP 31
o
o
4.3" LCD, TFT, 480 x 3(RGB) x 272
Tensiune în funcționare:
11...14 Vc.c.
Curent în stand-by:
2 mAc.c.
Curent în funcționare:
160 mAc.c.
RO Instrucțiuni de siguranță
2
1
OUT
*
+14V COM DATA GND Vout GNV
+14V COM DATA GND Vin GNV
APT
2
EN Cables
AUDIO
Standard
4 Wire 4 Fire
/
TCYY – 2x2x0.5-24 AWG (max. 30m);
TCYY – 3x2x0.5-24 AWG (max. 50m);
TCYY – 4x2x0.5-24 AWG (max. 50m);
4 x 0.5 mm (max. 60m);
2
4 x 0.75 mm (max. 100m);
2
PSU/ DDA
PAS.27N
+14
COM
GND
DATA
20-25mm
6mm
20-25mm
VIDEO
UTP/FTP cat5e (AWG24) /cat6 (AWG23)
Screw connectors
Conectori cu șurub
RO Instalare
classic
4.3" VIDEO
+14
COM
GND
DATA
Vin
GNV
GNV
Vout
RO Instalare - Conexiuni instalație video
APT
IN
DAV.44A
RO Cabluri
UTP/FTP cat5e (AWG24) /
cat6 (AWG23)
Screw connectors
Conectori cu șurub
25-30mm
+14
COM
GND
DATA
6mm
25-30mm
6mm
+14
COM
GND
DATA
Vin
GNV
GNV
Vout
1
2
+14
COM
GND
DATA
Vin
GNV
GNV
Vout
classic
MANDATORY!
A short circuit must be made
*
between the +Uv and 14V terminals
OBLIGATORIU!
Trebuie făcut scurt circuit
*
între bornele +Uv și 14V
6mm
+14
COM
GND
DATA
