- Page 1 wires VIDEO DOOR PHONE KIT 3.5”/7” 1 Fam./2 Fam./ 3 Fam. User manual...
-
Page 2: Installation Instructions
INSTALLATION INSTRUCTIONS – VIDEO DOOR PHONE KIT Dear Customer, thank you for choosing the ELECTRA products. We will assist you throughout the entire warranty period. For technical support and assistance you can contact us at ELECTRA Building Communications GmbH WIEN, +43 1 810 20 99, sales@electra-automation.com. - Page 3 VSB – Video selection box; Product code: VSB.4DN02.xxy04 (4 video inputs/1 video output) SCU – Central supply unit for 1 Fam; Product code: SCU.VDR02.xxy14 (110-230Vc.a., 50Hz/13.5Vd.c. - 2Ad.c.). Central supply unit for 3 Fam; Product code: SCU.VDR02.xxy34 PSU – Additional supply unit; Product code: PSU.VDR02.xxy04, necessary when, due to various reasons, the supply voltage (+U, GND) at the hubs of the terminals drops below 12V.
- Page 4 1) Max. 75 ml 4 x 0.5 mm (H03VV-F4G 0.5) 2) Max. 150 ml 4 x 0.75 mm (H05VV-F4G 0.75) 25-30mm 25-30mm 3) Max. 250 ml UTP cat5e (AWG24)/UTP cat6e (AWG23) 25-30mm 25-30mm UTP cat5e (AWG24) Vout Vout UTP cat6e (AWG23) 110Va.c./230Va.c.
- Page 8 ICPE by TÜV HESSEN Designed and Manufactured by ELECTRA Made in EU ELECTRA is a trademark of ELECTRA Group - No. 008958332 EUIPO - Alicante, Spain ELECTRA products are registered as Industrial Models at EUIPO - Alicante, Spain 11.2017 INS.VK3.ELY04...
