Axxera AV6225BH Owner's Manual

Dvd multimedia receiver with bluetooth featuring a 6.2" touch screen display
Hide thumbs
Table of Contents

Advertisement

Quick Links

AV6225BH
INSTALLATION/OWNER'S MANUAL
®
DVD Multimedia Receiver with Bluetooth
featuring a
6.2"
Touch Screen Display
Safety Notes:
The DVD video display of the in-dash unit will not operate while the vehicle is moving. This is a safety feature
to prevent driver distraction. In-dash DVD video functions will only operate when vehicle is in Park and the
parking brake is engaged. It is illegal in most states for the driver to view video while the vehicle is in motion.

Advertisement

Table of Contents
loading

Related Manuals for Axxera AV6225BH

Summary of Contents for Axxera AV6225BH

  • Page 1 AV6225BH INSTALLATION/OWNER’S MANUAL ® DVD Multimedia Receiver with Bluetooth featuring a 6.2" Touch Screen Display Safety Notes: The DVD video display of the in-dash unit will not operate while the vehicle is moving. This is a safety feature to prevent driver distraction. In-dash DVD video functions will only operate when vehicle is in Park and the...
  • Page 2 Copyright Notes This product incorporates copyright protection technology that is protected by method claims of certain U.S. patents and other intellectual property rights owned by Macrovision Corporation and other rights owners. Use of this copyright protection technology must be authorized by Macrovision Corporation, and is intended for home and other limited viewing uses only unless otherwise authorized by Macrovision Corporation.

  • Page 3: Table Of Contents

    AV6225BH PREPARATION Table of Contents Page Warning Statement ..........

  • Page 4: Warning Statement

    AV6225BH PREPARATION WARNING Upon installation of this Monitor/DVD player (“unit”) into a vehicle, the driver of the vehicle must not operate this unit by watching videos or playing video games while driving. Failure to follow this instruction could lead to driver distraction which could result in serious injury or death to the vehicle’s occupants or persons outside...

  • Page 5: Safety Information/Precautions

    Please read all instructions carefully before attempting to install or operate. Due to its technical nature, it is highly recommended that your Axxera AV6225BH is installed by a professional installer or an authorized dealer. This product is only for use in vehicles with 12VDC negative ground only.

  • Page 6: Preparation/Mounting

    AV6225BH INSTALLATION Preparation Before You Start • Disconnect negative battery terminal. Consult a qualified technician for instructions. • Avoid installing the unit where it would be subject to high temperatures, such as from direct sunlight, or where it would be subject to dust, dirt or excessive vibration.

  • Page 7: Wiring Diagram

    AV6225BH INSTALLATION Wiring Diagram - Inputs/Outputs V-IN V-OUT 2 V-OUT 1 L-IN R-IN HDMI Dual Mirror Input USB Input (Charging Only) SUBWOOFER GREY SUBWOOFER GREY REAR CAMERA INPUT YELLOW SWC - GND (BLACK) SWC 1 (BROWN) SWC 2 (BROWN/BLACK) ORANGE...

  • Page 8: Control Locations

    AV6225BH OPERATION Control Locations Power/Mode IR Sensor Play/Pause/Channels 1-6 USB Port Select/Volume Up/Down Reset Mute Auxiliary Input Microphone Eject Power & Mode Go to / * Key Talk Mute End / Reject Adjust Angle Setup Clock Subtitle & Local/Distance Select...

  • Page 9: Remote Preparation

    AV6225BH OPERATION Remote Control Preparation Remove battery insulation tape . Notes: • The remote control uses one 3 volt Lithium CR2025 battery. Remove the battery if the remote will not be used for a month or longer. • Remove and dispose of battery properly.

  • Page 10: General Operation

    AV6225BH OPERATION General Operation Power On/Off Momentarily press to turn the unit on or off. Volume Rotate the volume knob to increase or decrease the volume level. Mute Momentarily press MUTE to silence the audio. Momentarily press MUTE again to return to the previously selected volume.
  • Page 11 AV6225BH OPERATION General Operation From the Main Menu screen, press SETUP in the bottom right corner to Setup Menu access the Setup menu and select from six categories across the bottom: General, Time, Video, Language, Illumination and Calibration. General: • Animation - Select Off, 10 second, 30 second, 1 minute, 90 second, 2 minute, 3 minute or 4 minute to set animation length.

  • Page 12: General Operation

    AV6225BH OPERATION General Operation Setup Menu Time: • Hour - Press < or > to adjust the hour down or up. • Minute - Press < or > to adjust the minutes down or up. • Format - Select between a 12HR or 24HR clock display.

  • Page 13: Am/Fm Tuner Operation

    AV6225BH OPERATION AM/FM/RDS Tuner Operation Select the Radio icon from the Main Menu screen. Radio Operation Press to return to Main Menu screen. Main Menu Current Mode Indicator Displays current mode of operation. Press << to tune radio to a lower frequency. Press < to tune the unit Tune Frequency Down down one step at a time.
  • Page 14 AV6225BH OPERATION AM/FM/RDS Tuner Operation Press to adjust the following Audio options: Audio • EQ - Select from the preset EQ options: JAZZ, CLASSIC, POP, ROCK, BEAT OR FLAT, or select USER to manually adjust Bass, Middle and Treble options between -7 and 7.
  • Page 15 AV6225BH OPERATION AM/FM/RDS Tuner Operation Local / Distance Press to toggle between LOCAL and DX (distance) tuning. Program Type (PTY) Press to select Program Type / Genre. Traffic Announcements Press to turn on/off Traffic Announcements. Alternative Frequencies Press to select Alternative Frequencies.

  • Page 16: Cd/Usb Operation

    AV6225BH OPERATION CD/USB Operation To play audio files from a disc or MP3/WMA files from a disc or USB CD/MP3/WMA or JPG Operation device, insert disc or device and playback will begin automatically. To return to disc or USB playback from another mode of operation, select the corresponding icon from the Main Menu.
  • Page 17 AV6225BH OPERATION CD/USB Operation Press to access the Camera when the camera function is enabled. Camera Previous Options Press to see the previous screen of options. Mute Press to mute the unit's sound. Press again to unmute, or sound can be restored by adjusting the volume knob of the front panel.
  • Page 18 AV6225BH OPERATION Media Compatibility - USB File Type FAT 12 File System FAT 16/FAT 32 .mp3/.MP3/.Mp3/.mP3 File .wma/.WMA Extension .rmp/.m4a MPEG 1 MPEG MPEG 2 Format MPEG 2.5 MPEG 1 32/44. 1 /48kHz MPEG 2 12/16/22.05/24kHz Sampling Frequency MPEG 2.5 8/11.025/12kHz...

  • Page 19: Media Compatibility Cd/Dvd

    AV6225BH OPERATION Media Compatibility - CD/DVD File Type Level 1, Level 2 ISO9660 Level 3 Playback ISO9660 JOLIET File System Extension Filename 32 bytes 32 bytes Playback ROMEO Other Filename Extensions Apple ISO .mp3/.MP3/.Mp3/.mP3 File .wma/.WMA Extension .rmp/.m4a MPEG 1...
  • Page 20 AV6225BH OPERATION Media Compatibility Media Compatibility The following types of discs/files are compatible: • CD-DA, CD-ROM (ISO), CD-R, CD-RW • DVD Video, DVD+R/RW, DVD-R/RW • AVI - Max video resolution: 720x480, Max video bit rate: 5000 kbps • Mpeg2: Max video resolution: 720x480, Max video bit rate: 5000 kbps •...
  • Page 21 AV6225BH OPERATION WARNING Upon installation of this Monitor/DVD player (“unit”) into a vehicle, the driver of the vehicle must not operate this unit by watching videos or playing video games while driving. Failure to follow this instruction could lead to driver distraction which could result in serious injury or death to the vehicle’s occupants or persons outside...

  • Page 22: Dvd Operation

    AV6225BH OPERATION DVD Operation Inserting a Disc Insert disc into the slot, and playback will begin automatically. Sub- menus may have to be pressed to access the DVD content. Read the directions of your specific DVD disc for other features.

  • Page 23: Dvd Operation

    AV6225BH OPERATION DVD Operation Next Chapter Press to advance to the next chapter. Fast Reverse Press to fast reverse playback at various speeds: FRx2, FRx4, FRx8 or FRx20. Fast Forward Press to fast forward playback at various speeds: FRx2, FRx4, FRx8 or FRx20.

  • Page 24: Dualmirror Operation

    AV6225BH OPERATION DualMirror™ Operation The DualMirror™ technology allows you to mirror the screen of select Android smartphones as well as iPhone, iPod and iPad devices onto the receiver's screen and to charge your mobile device through the rear USB port. Simply plug in your device to the rear HDMI and USB inputs, and you are ready to view your favorite navigation or music apps directly on the receiver’s screen.
  • Page 25 AV6225BH OPERATION DualMirror™ Operation Connecting an iPhone, iPod or iPad device (Lightning cable not included)

  • Page 26: Bluetooth Operation

    AV6225BH OPERATION Bluetooth Operation Preparation Before you can use a Bluetooth device, it must be paired and connected. Make sure that Bluetooth is activated on your device before you begin the pairing process. Pairing a New Device The unit broadcasts the pairing signal constantly when no devices are currently connected.
  • Page 27 AV6225BH OPERATION Bluetooth Operation Make a Call Press to display the keypad and make a call. Dialed Call Log Press to display a log of dialed calls. Use the icons on the right to search for a specific contact or scroll through the list.

  • Page 28: Auxiliary Inputs/Rear Camera Operation

    AV6225BH OPERATION Front 3.5mm Aux Input & Rear RCA A/V Input Auxiliary Input Connect an optional audio source into the 3.5mm (front panel) input. Select auxiliary input from the Main Menu to listen to audio. Adjust volume on the external audio source as needed (if connected to the headphone output of the device).

  • Page 29: Limited One Year Warranty

    AV6225BH OPERATION Limited One Year Warranty This warranty gives you specific legal rights. You What to do? may also have other rights which vary from state to 1. Before you call for service, check the state. troubleshooting guide in your owner’s manual. A slight adjustment of any custom controls may save Dual Electronics Corp.

  • Page 30: Specifications

    AV6225BH OPERATION Specifications Disc Frequency response: 20Hz-20kHz Channel separation @ 1kHz: >80dB D/A converter: 24 Bit FM Tuner Tuning range: 87.5MHz-107.9MHz Usable sensitivity: 10dBf 50dB quieting sensitivity: 20dBf Stereo separation @ 1kHz: 38dB Frequency response: 30Hz-13kHz AM Tuner Tuning range:...

  • Page 31: Troubleshooting

    Please keep your original sales receipt and be prepared to provide this receipt in the event you require service, as your original receipt is considered the best proof of purchase and indicates the date you purchased your Axxera product. Dealer Name...
  • Page 32 Dual Electronics Corp. Toll Free: 1-866-382-5476 Monday-Friday, 9AM-5PM EST www.axxeraaudio.com ©2015 Dual Electronics Corp. All rights reserved. NSA0415-V01 Printed in China...
