Style Selections
is a registered trademark
®
of LF, LLC. All rights reserved.
Questions, problems, missing parts? Before returning to your retailer, call our
customer service department at 1-877-888-8225, 8 a.m. - 8 p.m., EST, Monday - Friday.
EB15197
WALL/CORNER MEDIA
ELECTRIC FIREPLACE
MODEL #81851/23DE5209-PB84
1
ITEM #0466670
Français p. 18
Español p. 35
Lowes.com
Advertisement
Table of Contents
Related Manuals for Style selections 81851/23DE5209-PB84
Summary of Contents for Style selections 81851/23DE5209-PB84
- Page 1 Style Selections is a registered trademark ® of LF, LLC. All rights reserved. MODEL #81851/23DE5209-PB84 Français p. 18 Español p. 35 Questions, problems, missing parts? Before returning to your retailer, call our customer service department at 1-877-888-8225, 8 a.m. - 8 p.m., EST, Monday - Friday.
-
Page 2: Table Of Contents
TABLE OF CONTENTS Product Specifications ......................... 2 Safety Information ..........................3 Package Contents ..........................6 Hardware Contents..........................7 Preparation ............................8 Assembly Instructions........................... 8 Operating Instructions ........................13 Care and Maintenance ........................13 Troubleshooting ..........................15 Warranty ............................. 16 Replacement Parts List ........................17 PRODUCT SPECIFICATIONS VOLTAGE 120 V, 60 Hz... -
Page 3: Safety Information
SAFETY INFORMATION Please read and understand this entire manual before attempting to assemble, operate or install the product. When using electrical appliances, basic precautions should always be followed to reduce the risk of fire, electrical shock and injury to persons, including the following: DANGER: •... - Page 4 4. The appliance is not to be used by children or persons with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction. SAFETY INFORMATION 5. Always unplug this appliance when not in use. 6.
-
Page 5: Save These Instructions
SAFETY INFORMATION • Batteries are to be inserted with the correct polarity. • Exhausted batteries are to be removed from the product SAVE THESE INSTRUCTIONS Cold-climate installation: It is mandatory the outer walls be insulated to conform to applicable insulation codes. ELECTRICAL CONNECTION A 15-Amp, 120-volt, 60 Hz circuit with a properly grounded outlet is required. -
Page 6: Package Contents
PACKAGE CONTENTS PART DESCRIPTION QUANTITY Base Left Side Panel Right Side Panel Center Shelf Left Front Door Right Front Door Mantel Top Wood Shelf Center Left Panel Center Right Panel Center Front Panel Top Left Support Panel Top Middle Support Panel Top Right Support Panel Rear Panel Center Back Panel... -
Page 7: Hardware Contents
HARDWARE CONTENTS (shown actual size) Truss Head Bolt Long Screw Wood Dowel Shelf Pin Screw Qty: 29 Qty: 5 Qty: 14 Qty: 38 Qty: 8 Door Pull (Not to scale) Qty: 2 Short Screw Qty: 24 Hinge Hinge Bracket (Not to scale) (Not to scale) Qty : 4 Qty : 4... -
Page 8: Preparation
PREPARATION Before beginning assembly of product, make sure all parts are present. Compare parts with package contents list and hardware contents list. If any part is missing or damaged, do not attempt to assemble, install or operate the product. To protect the product from possible scratches, please assemble the parts on a scratch-free surface. - Page 9 4. Attach the completed assembly from step 1 to the base (A). Secure with bolts (AA) through the holes in the plastic blocks -- preassembled on the center left panel (I) and center right panel (J) -- and into the base (A) HAND TIGHTEN ONLY.
- Page 10 7. Attach the mantel top (G) to the assembly using bolts (AA) through the plastic blocks into the pre-drilled holes on the bottom of mantel top (G). Note: A short- handled screwdriver (not included) might be helpful. HAND TIGHTEN ONLY. Hardware Used Bolt 8.
- Page 11 10. Remove the preassembled bolt from the door pulls (FF), then attach the door pull (FF) to the left front door (E) and right front door (F) with the bolts. Align the hinges (II) to the hinge brackets (JJ), sliding hinges (II) over the hinge brackets (JJ) at the locked position.
- Page 12 12. Note: Be sure to read all safety information prior to installing the insert (T). Insert (T) should be installed Install Insert in the fireplace as close to the final position as From Back possible; two people are recommended for this step. Lift insert (T) carefully into the back of the unit and center in the insert opening.
-
Page 13: Operating Instructions
OPERATING INSTRUCTIONS The heater can be operated by either the remote control or the control panel. Control Panel Display Front View of Insert (T) Remote (U) FUNCTION ICON DESCRIPTION POWER Use the POWER button to turn on or off the fireplace from the remote or control panel. -
Page 14: Care And Maintenance
CARE AND MAINTENANCE • Dust the fireplace regularly with a soft, non-lint producing cloth or household dusting product. • Clean the fireplace with a gentle non-abrasive household cleaner. Make sure to dry the fireplace immediately with a soft cloth or towel. •... -
Page 15: Troubleshooting
TROUBLESHOOTING PROBLEM POSSIBLE CAUSE CORRECTIVE ACTION Unplug the fireplace, remove the back panel of the fireplace and The thermostat sensor is check that the thermostat is plugged into the main circuit board. If Display shows “ ” broken or disconnected. this does not solve the problem contact customer service for a replacement thermostat sensor. -
Page 16: Warranty
1-YEAR LIMITED WARRANTY The manufacturer warrants this product to be free from manufacturing and material defects for a period of one year from date of purchase, subject to the following conditions and limitations. 1. Install and operate this item in accordance with the installation and operating instructions furnished with the product at all times. -
Page 17: Replacement Parts List
Emberbed with Log Y15-S146-P02 Emberbed Circuit Board Y15-S146-P44E Blue Flame Circuit Board Y15-C70-P40BL Flame Circuit Board Y15-C73-P40 Flame Generator/ Spinner Y15-S146-P11 Remote Control P115 Printed in China Style Selections is a registered trademark ® of LF, LLC. All rights reserved. Lowes.com...
