Summary of Contents for Style selections 23WM1258

  • Page 1 ITEM #0386379 ELECTRIC FIREPLACE AND MANTEL Style Selections® is a registered trademark of LF, LLC. All Rights Reserved. MODEL #23WM1258 Français p. 14 Español p. 27 Questions, problems, missing parts? Before returning to your retailer, call our customer service department at 1-877-888-8225, 8 a.m. - 8 p.m., EST, Monday - Friday.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS Product Specifications ......................... 2 Safety Information ..........................3 Package Contents ..........................6 Hardware Contents ..........................7 Preparation ............................7 Assembly Instruction ..........................8 Operating Instructions ........................10 Care and Maintenance ........................10 Troubleshooting ...........................11 Warranty ............................. 12 Replacement Parts ..........................

  • Page 3: Safety Information

    SAFETY INFORMATION Please read and understand this entire manual before attempting to assemble, operate or install the product. WARNING • Before assembly, carefully use scissors or utility knife to cut and unwrap all parts. Make sure you do not discard the hardware. CAUTION •...

  • Page 4: Grounding Instructions

    SAFETY INFORMATION 18. To prevent a possible fire, do not block air intakes or exhaust in any manner. Do not use on soft surfaces, like a bed, where opening may become blocked. 19. This appliance has hot and arcing or sparking parts inside. Do not use it in areas where gasoline, paint or flammable liquids are used or stored.
  • Page 5 SAFETY INFORMATION WARNING: Make sure the power is turned off before proceeding. Any electrical repairs or rewiring of this unit should be carried out by a licensed electrician in accordance with national and local codes. If repairing or replacing any electrical component or wiring, the original wire routing, color coding and securing locations must be followed.

  • Page 6: Package Contents

    PACKAGE CONTENTS Part Description Quantity Hearth/Base Left Front Panel Right Front Panel Center Front Panel Center Top Panel Left Side Panel Right Side Panel Mantel/Top Insert...

  • Page 7: Hardware Contents

    HARDWARE CONTENTS Picture (Shown to size) Description Quantity Part Bolt Washer Wood Dowel Screw Touch-up Pen Model No. W3352 Not actual size PREPARATION Before beginning assembly of product, make sure all parts are present. Compare parts with package contents list and diagram above. If any part is missing or damaged, do not attempt to assemble, install or operate the product.

  • Page 8: Assembly Instruction

    ASSEMBLY INSTRUCTIONS 1. Locate the left front panel (B), right front panel (C), center front panel (D), and set out face down on a scratch-free surface. Insert one wood dowel (CC) into each of the pre-drilled holes. Push the left front panel (B) and right front panel (C) snug to the center front panel (D).
  • Page 9 4. Locate left side panel (F) and right side panel (G). Insert one wood dowel (CC) into each of the pre-drilled holes. Secure with bolt (AA) and washer (BB) through the pre-drilled holes in the mounting blocks. HAND TIGHTEN ONLY. Hardware Used Bolt x 10...

  • Page 10: Operating Instructions

    OPERATING INSTRUCTIONS Control panel can be accessed at upper-right corner of insert (I). - POWER The power button supplies power to all of the functions of the fireplace. The power button will put the in- sert in a standby mode. This will turn off all functions at once but will hold the settings in the memory. By pressing the power button again the unit will turn on at the same settings.

  • Page 11: Troubleshooting

    REPLACING THE REMOTE CONTROL BATTERY When the remote control stops operating or its range seems reduced, it is time to replace the battery with a new one. Note: Batteries should be removed if the product is to be left unused for a long time. 1.

  • Page 12: Warranty

    1-YEAR LIMITED WARRANTY The manufacturer warrants this product to be free from manufacturing and material defects for a period of one year from date of purchase, subject to the following conditions and limitations. 1. Install and operate this Electric Fireplace in accordance with the installation and operating instructions furnished with the product at all times.

  • Page 13: Replacement Parts

    REPLACEMENT PARTS LIST For replacement parts, call our customer service department at 1-877-888-8225, 8 a.m. - 8 p.m., EST, Monday - Friday. Part No. Part Description 23EF023GRA Heater/Blower Assembly Y07-C26-P01 Main Circuit Board Y11-C53-P15 Flame Generator Drive Motor Y07-P10Q Flame Generator/ Spinner Y10-S52-P011 LCD Display Y10-C43-P70...
