PILOT WASH
PR-2302
This product manual contains important information about the safe installation
and use of this projector. Please read and follow these instructions carefully
and keep this manual in a safe place for future reference.
PR LIGHTING LTD.
No. 571, Yingbin Road, Dashi Panyu, Guangzhou, 511430 China
http://www.pr-lighting.com
Advertisement
Table of Contents
Related Manuals for PR Lighting PILOT WASH
Summary of Contents for PR Lighting PILOT WASH
- Page 1 PILOT WASH PR-2302 This product manual contains important information about the safe installation and use of this projector. Please read and follow these instructions carefully and keep this manual in a safe place for future reference. PR LIGHTING LTD. No. 571, Yingbin Road, Dashi Panyu, Guangzhou, 511430 China...
-
Page 2: Table Of Contents
Please read and follow these instructions carefully and keep this manual in a safe place for future reference. The PILOT WASH is an innovative projector with an elegant housing, which is made from high intensity and heat–resistant complex plastic. The PILOT WASH complies to CE norms and standards and uses international protocol DMX 512. -
Page 3: Safe Usage Of The Projector
Always disconnect from the mains, when the device is not in use or before cleaning it or before attempting any maintenance work. If you have any questions, don’ t hesitate to consult your dealer or manufacturer. 3/14 Pilot Wash manual.doc... -
Page 4: Installing The Projector
20.1Kg for each PILOT WASH. For safety the projector should have a secondary fixing with a safety chain through the holes on the underside of the unit. -
Page 5: Power Supply - Mains
IMPORTANT It is essential that each projector is correctly earthed and the electrical installation conforms to all relevant standards. Power consumption of the PILOT WASH is 480W at 220V. OPERATION AND STAND-ALONE MODE The projector may be operated either in Stand-Alone automatic mode or be controlled via standard DMX512 by a controller. -
Page 6: Xlr Connectors And Terminator
Note: care should be taken to ensure that none of the connections touch the body of the plug or each other. The body of the plug is not connected in any way. The PILOT WASH accepts digital control signals in standard DMX512 (1990) format. -
Page 7: Controller Mode - Dmx Operation
“ listen” to the digital control information being sent out from the controller. The PILOT WASH has 10 channels if high resolution (16 bit) Pan & Tilt have been enabled (see the table in the next page), so set the No. 1 projector’ s address 001, No. 2 projector’ s address 011, No. -
Page 8: Dmx Control Channel Functions
DMX CONTROL CHANNEL FUNCTIONS The PILOT WASH uses 10 DMX channels. They are listed in the following table. CHANNEL DMX VALUE DESCRIPTION From light magenta to dark magenta 0-255 Magenta (5-7) Setup options and address reset 0-255 From light yellow to dark yellow... -
Page 9: Keeping The Projector Clean
Cyan, Yellow, and Magenta colours Shutter/Strobe: 2 Blade shutter for dimming and strobe effect, adjustable from 1~7 F.P.S. 6°~16° Effects of beam: Frost, by adjusting Fresnel lens Movement: Pan movement 370°-Tilt movement 265° Net weight: 20.1kg Others: Auto thermal cut-off 9/14 Pilot Wash manual.doc... -
Page 10: Dimensions And Light Output
DIMENSIONS AND LIGHT OUTPUT DIMENSIONS LIGHT OUTPUT 10/14 Pilot Wash manual.doc... -
Page 11: Electrical Diagram
ELECTRICAL DIAGRAM 11/14 Pilot Wash manual.doc... - Page 12 TTL LOGICAL CHIP IC22 170170039 STABLE-VOLTAGE CHIP BUS CHIP FOR IC23 170170012 RECEIVING/TRANSMITTING IC24 170040032 EEPROM IC25 170040035 RESET CHIP MAIN IC 230040123 MICROPROCESSOR PAN DRIVE BELT (NOT SHOWN) 290151217 HTD309-3M-103Z TILT DRIVE BELT (NOT SHOWN) 290151218 HTD420-3M-140Z 12/14 Pilot Wash manual.doc...
-
Page 13: Changing The Operation Voltage And/Or Frequency
To be carried out by qualified engineers only. The power input settings of the PILOT WASH may be changed to suit the supply in the area where the unit is operated. The voltage and frequency is pre-set at the factory and will be marked on the exterior of the unit. - Page 14 PR LIGHTING LTD. No. 571, Yingbin Road, Dashi, Panyu, Guangzhou, China Post-Code: 511430 TEL: +86-020-8478 1888 FAX: +86-020-8478 6023 P/N: 321010045 Last Revision: 28:06:2004 14/14 Pilot Wash manual.doc...
