PR Lighting XRLED 700 Spot User Manual

Hide thumbs Also See for XRLED 700 Spot:
Table of Contents

Advertisement

Quick Links

XRLED 700 Spot
PR-8163
This product manual contains important information about the safe installation and use of this projector.
Please read and follow these instructions carefully and keep this manual in a safe place for future reference.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the XRLED 700 Spot and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for PR Lighting XRLED 700 Spot

Summary of Contents for PR Lighting XRLED 700 Spot

  • Page 1 XRLED 700 Spot PR-8163 This product manual contains important information about the safe installation and use of this projector. Please read and follow these instructions carefully and keep this manual in a safe place for future reference.
  • Page 2 PR LIGHTING LTD. http://www.pr-lighting.com 2/21...

  • Page 3: Table Of Contents

    INDEX SAFE USAGE OF THE PROJECTOR INSTALLING THE PROJECTOR POWER SUPPLY – MAINS CONTROL CONNECTIONS DMX TERMINATOR SETUP OPTIONS-PROJECTOR CONFIGURATION TO SET THE DMX START ADDRESS STAND-ALONE MODE MASTER/SLAVE MODE OPERATION MENU REPLACING GOBOS DMX PROTOCOL INDICATION OF LED DIGITAL TUBE MAINTENANCE LUBRICATION KEEPING THE PROJECTOR CLEAN...

  • Page 4: Safe Usage Of The Projector

    SAFE USAGE OF THE PROJECTOR When unpacking and before disposing of the carton check there is no transportation damage before using the projector. Should there be any damage caused by transportation, consult your dealer and do not use the apparatus. The projector is for indoor use only, IP20.
  • Page 5 INSTALL THE PROJECTOR Handle Safety cord Clamp Warning Please run the safety cord through a safety cord hole for safety. Safety cord hold Operation menu Take 2 clamps and the safety cord out from the package and mount 2 clamps on the underside of fixture with 2 retainers attached to each clamp.

  • Page 6: Power Supply – Mains

    POWER SUPPLY-MAINS Connect the power cord as follows: L (live) =brown E (earth) =yellow/green N (neutral) =blue Use the plug provided to connect the mains power to the projector paying attention to the voltage and frequency marked on the panel of the projector.

  • Page 7: Dmx Terminator

    DMX TERMINATOR In the Controller mode, at the last fixture in the chain, the DMX output has to be connected with a DMX terminator. This prevents electrical noise from disturbing and corrupting the DMX control signals. The DMX terminator is simply an XLR connector with a 120Ω (ohm) resistor connected across pins 2 and 3, which is then plugged into the output socket on the last projector in the chain.

  • Page 8: Stand-Alone Mode

    STAND-ALONE MODE Operate the projector without connecting a controller, enable the master mode in the operation panel, the projector will run in Stand-Alone mode automatically. DMX address can be set without limitations. MASTER/SLAVE MODE Many projectors can run synchronously in the Master/Slave mode by linking them with each other. Select one projector as the master with setting options at any mode of master’s modes enabled and make the other projectors as the slaves with setting options slave mode enabled and their DMX start address “001”.

  • Page 9: Operation Menu

    OPERATION MENU 1st LEVEL 2nd LEVEL 3rd LEVEL 4th LEVEL AddR DMX Address （XXX:1~512） Reset Are You Sure Standard 19 STD 19,Maximm Address:494 CNFG DMX Channel mode Short 18 Config Settings (Default is：STD) Short 15,Maximm Address:498 Extended 31 Extended 23,Maximm Address:490 Pan Tilt Swap （Default is OFF）...
  • Page 10 Auto- Test TEST Test Mode White Colour 1 ～ Colour 6 Colour Wheel Rotation Stop rotating Reverse Rotation Effect 1 Manual Test Iris Effect 2 Effect 3 NO Gobo Gobo 1 ～ Gobo 7 F-Gobo wheel Rotation Reverse Rotation Shake 1 ～ 6 NO Gobo Gobo 1 ～...
  • Page 11 Stop Prism Rotate Rotation Reverse Rotation Focus 0-255 ZOOM 0-255 Pan Location 0-255 Tilt Location 0-255 Pan&Tilt Speed 0-255 DMX Operation Preset Memory User Memory CH1 Strobe 0-255 CH2 Dimmer 0-255 CH3 Colour wheel 0-255 CH4 Iris 0-255 CH5 F-Gobo wheel 0-255 mENU Operation Mode...

  • Page 12: Replacing Gobos

    REPLACING GOBOS Rotating Gobo Wheel Fixed Gobo Wheel Disconnect the fixture from power. Carefully lift off the cover by undoing the 4 fast-fit screws. Before the replacement of fixed gobos, take leaf spring out using finger, push the gobos out carefully and insert new gobos. For rotating gobos: take rotating gobo wheel out by hand, push gobos out after pulling out leaf springs.
  • Page 13 080-095 096-111 Green 112-127 Yellow Forward Rotation(Speed From Slow to 128-159 Fast) 160-223 White Reverse Rotation(Speed From Slow to 224-255 Fast) From big to Small 000-207 208-223 Iris effect 1 Iris 224-239 Iris effect 2 Iris effect 3 240-255 Iris Fine Iris in 16 Bit precision 0-255 000-015...
  • Page 14 128-143 Rotation speed from slow to fast 144-159 Reverse rotation from slow to fast 160-175 Gobo shake 1 from fast to slow 176-191 Gobo shake 2 from fast to slow 192-207 Gobo shake 3 from fast to slow 208-223 Gobo shake 4 from fast to slow 224-239 Gobo shake 5 from fast to slow 240-255...

  • Page 15: Keeping The Projector Clean

    INDICATION OF LCD Display DMX signal OK Green LED indication No DMX signal Linked with Wireless Transmitter Blue LED indication Not linked with transmitter Flash Being linked with a transmitter or losing link MAINTENANCE If the projector does not function, check the fuses on the power socket of the projector, they should only be replaced by fuses of the same specification.
  • Page 16 VOLTAGES: 100V ~ 240V AC，50/60Hz POWER CONSUMPTION: 400W@220V COLOURS: 6 colors +open color wheel With variable speed bi-directional rainbow effect Color Temperature 8000K±500K GOBOS: 1 Rotating gobo wheel: 7 interchangeable gobos+ white, glass or metal gobos can be fixed Indexable, bi-directionally rotatable and Wheel Scrolling at variable speeds, shakable at variable speeds 1 Fixed gobo wheel : 7 interchangeable gobos+ white bi-directional wheel scrolling at variable speeds, shaking at variable speeds...
  • Page 17 12°～36°linear adjustment CONTROL: DMX512, 3 pin, 5 pin interfaces 15channels in short mode,19 channels in standard mode, and 23 channels in extended mode. Master/slave mode Stand-alone mode Self-test mode OTHER FUNCTIONS: Adjustable Pan & Tilt speed Fixture usage time display Software version display DMX512 wireless available Optional DMX512 wireless remitter...
  • Page 18 36°lux 2164 12°lux 12548 3137 1394 DISTANCE(m) 12°DISTANCE(m) 1.1m 2.15m 3.23m 4.29m 5.37m 6.44m 36°DISTANCE(m) 3.18m 6.35m 9.53m 12.71m 15.88m 19.06m 18/21...

  • Page 19: Electrical Diagram

    ELECTRICAL DIAGRAM 19/21...

  • Page 20: Component Order Codes

    COMPONENT ORDER CODES NAME PART NO. QUANTITY REMARK 400W POWER SUPPLY 192010153 192010156 230W POWER SUPPLY 250020279 LED WHITE LIGHT SOURCE 270041045 6.3A FUSE 5X20 6.3A、250V 290151378 TILT BELT HTD-684-3M 290151374 HTD-447-3M PAN BELT 030060074 92X92X25 TAIL FAN 030060080 60X60X20 BASE FAN PAN MOTOR 030040190...
  • Page 21 PR LIGHTING LTD. 1582 Xingye Avenue, Nancun Panyu Guangzhou, 511442 China TEL: +86-20-3995 2888 FAX: +86-20-3995 2330 P/N: 320020229 Version: 20140821 (Preliminary） 21/21...
