XR580 BEAM
PR-2554
The user manual contains important information about the safe installation and use of a projector. Please read
and follow these instructions carefully and keep the manual in a safe place for future reference.
PR LIGHTING LTD.
http://www.pr-lighting.com
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the XR580 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for PR Lighting XR580

Summary of Contents for PR Lighting XR580

  • Page 1 XR580 BEAM PR-2554 The user manual contains important information about the safe installation and use of a projector. Please read and follow these instructions carefully and keep the manual in a safe place for future reference. PR LIGHTING LTD. http://www.pr-lighting.com...
  • Page 2 / or dealer. Note: For the products made by Guangzhou PR lighting Ltd, the warranty for the whole product is one year starting from the delivery date but the light source is not within the warranty.

  • Page 3: Safety And Warnings

    1. SAFETY AND WARNINGS NOTE Before a projector’s installation, power-on, operation and maintenance, please carefully read the safety information hereinafter! The following safety signs are used in the user manual. User Electrical Protective High Warning Flames Goggles Manual shock Gloves Temperature When unpacking , check if there is transportation damage before using the projector.
  • Page 4 There are safety cord holes at the bottom of the base of a projector. In view of safety, please run the safety ● cord supplied through the safety cord holes for safety support. Before any installation, maintenance and cleaning work, please ensure the projector is disconnected from ●...
  • Page 5  Check if lens are in good condition(not cracked) Heavily Defective Beam  Clean dust or grease on the lens. 3. APPEARANCE 1.Front Lens 2.Lens Cover 3.Head Cover 4.Arm Cover 5.Tilt Lock 6.Lamp Chamber Cover 7.Base Handle While transportation, the head should be locked-Tilt Lock and Pan Lock should be at locking positions. Before the use of the projector, unlock both.

  • Page 6: Installation

    4. INSTALLATION RIGGING ● Before moving a projector, Please lock Pan and Tilt. Before its operation, please unlock them. It’s forbidden to run a projector with power while it is locked. Safety cord Warning Please run the safety cord through the two safety Clamp cord holes...
  • Page 7 DMX CONTROL CONNECTION: ● Connection between controller and projector and between one projector and another must be made with a twin-screened cable, with each wire having at least a 0.5mm in diameter. Connection to and from the projector is via cannon 5 pin (which are included with the projector) or 5 pin XLR plugs and sockets.
  • Page 8 ALIGNMENT/INSTALLATION/REPLACEMENT OF A LAMP ● Lock the yoke before fitting/replacingthe lamp. Just as Shown by Figure 1, after Opening the cover at the rear of the projector by loosening 8 fastfit screws, you can open the head. To adjust the lamp as per Figure 2. Take out the lamp as per the figure 3. Before lamp installation, tighten its power wires well.

  • Page 9: Setup And Configuration

    5. SETUP AND CONFIGURATION FRONT PANEL OPERATION ● The projector configuration can be set conveniently via push buttons and color touch screen. To browse through or change the projector ’s settings, touch the white area of the touch screen or press OK button for more than ►...

  • Page 10: Master/Slave Mode

    Only after the projector is linked with a transmitter, can it receive wireless signal sent by the transmitter. If unlinking it, Press “Enter” for the menu of Un-link Wireless under the upper level menu of Config Settigns , then the fixture is unlinked with the wireless transmitter.
  • Page 11 Really Reset? Gobo Reset Confirm or Cancel Really Reset? Dimmer/Shutter reset Confirm or Cancel Really Reset? Fo. Fr. Pr. Reset Confirm or Cancel Short Mode Standard Mode DMX Channel Mode Extended Mode View Selected Mode Lamp Control OFF/ ON On By Power On OFF/ ON Lamp Control Control By DMX...
  • Page 12 Fahrenheit Degree Un-Link Wireless Really Un-Link? Confirm or Cancel Restore Defaults? Factory Defaults Confirm or Cancel Pan DMX Invert OFF/ ON Tilt DMX Invert OFF/ ON Pan/Tilt Settings Pan Tilt Swap OFF/ ON Option Settings XY Feedback OFF/ ON Pan/Tilt mode Speed/Time Dimmer Invert OFF/ ON...
  • Page 13 xxx xxx Pan & Tilt board xxx xxx Driver Board1 xxx xxx Driver Board 2 xxx xxx Driver Board 3 Fan Driver Board=XXXC Electronic SN XXXXXX XR 580 Beam RDM Device Label ANSI E1.20 RDM Speed Status Lamp Fan1 xxx on/off Lamp Fan2 xxx on/off Lamp T Fan xxx on/off...
  • Page 14 … Factory Mode Change Operation Mode? DMX Mode Confirm or Cancel Change Operation Mode? Preset Memory Confirm or Cancel Change Operation Mode? Master Mode User Memory 1 Confirm or Cancel Change Operation Mode? User Memory 2 Confirm or Cancel Operation Change Operation Mode? Mode Preset Memory...

  • Page 15: Dmx Protocol

    CTO Fine XXX Color Wheel XXX Color Wheel Fine XXX Fixed Gobo Wheel XXX Rot. Gobo Wheel XXX Rot. Gobo Rotation XXX Rot. Gobo Rotation F. XXX Prism 1 XXX Prism 1 Rotation XXX Prism 2XXX Prism 2 Rotation XXX Focus XXX Focus Fine XXX Pan XXX...
  • Page 16 000-005 006-024 Diffuser 025-255 Linear CTO CTO Fine 000-255 CTO in 16 bit 000-063 Indexing (0-360degrees) 064-068 Color1(Red) 069-073 Color2( Light Green) 074-078 Color3(Blue) 079-083 Color4(Cyan) 084-088 Color5(Yellow) 089-093 Color6(Magenta) 094-098 Color7(Orange) Color Wheel 099-103 Color8(Green) 104-108 Color9(Deep Blue) 109-113 Color10(UV) 114-118 Color11(Light Yellow)
  • Page 17 196-199 Shake effect 4 from slow to fast 200-203 Shake effect 5 from slow to fast 204-207 Shake effect 6 from slow to fast 208-211 Shake effect 7 from slow to fast 212-215 Shake effect 8 from slow to fast 216-219 Shake effect 9 from slow to fast 220-223...
  • Page 18 193-255 Rotation(Anti- Clockwise from slow to fast) 000-016 White Prism 2 017-127 Prism3 128-255 Frost in 000-128 Prism2 Indexing 129-191 Rotation(Clockwise from slow to fast) Prism2 Rotation Stop 193-255 Rotation(Anti- Clockwise from slow to fast) 000-255 Focus Linear Focus 000-255 Focus Fine Focus in 16 bit precision 000-255...
  • Page 19 8. Logos Option Settings Lamp Control Information Chinese/English Service Error Messages Operation Mode Address User Memories Reset Config Settings 9.Error messages The system can detect some errors during the reset, if displayed, touch to view the error. The error messages are as follows: Name Type Correction...

  • Page 20: Technical Data

    Check if fan and its wiring are normal CMY Fan Error Head Fan Error Check if fan and its wiring are normal Gobo Fan Error Check if fan and its wiring are normal Check if fan and its wiring are normal Basic Fan Error Pan and Tilt Board...

  • Page 21: Fixed Gobo Wheel

    Color 9 Color 10 Color8 Color 11 Color 7 Color 12 Color 5 Color 1 Color 4 Color 2 Color 3 Code No. Colors 092550001 092550002 Light Green 092550003 Blue 092550004 Cyan 092550005 Yellow 092550006 Magenta 092550007 Orange 092550008 Green 092550009 Deep Blue 092550010...

  • Page 22: Rotating Gobo Wheel

    Bi-directionally rotatable, and shakable at variable speeds Gobo1 Gobo2 Gobo3 Gobo4 Gobo5 Gobo6 Gobo7 Gobo8 Gobo9 Gobo10 Gobo11 Gobo12 Gobo13 Gobo14 Gobo15 Gobo16 Gobo17 Gobo18 ROTATING GOBO WHEEL 1 Rotating gobo wheel: 7Interchangeable Gobos +Open Bi-directionally rotatable, and shakable at variable speeds Gobo Replaceable, Gobo diameter: Φ22.5mm ,Gobo image diameter: Φ12mm Gobo1 Gobo 2...

  • Page 23: Ambient Temperature

    FOCUS DMX linear Focus DIMMER/STROBE 0-100% Linearly adjustable/ Double shutter blades, 0.3~25 F.P.S HEAD MOVEMENT Pan 540º , Tilt 270º with auto position correction BEAM ANGLE Beam 2° CONTROL DMX512, 5-pin interfaces(Optional 3-pin) 22channels in short mode, 26channels in standard mode , 30channels in extended mode Self-test mode OTHER FUNCTIONS Adjustable Pan &...

  • Page 24: Light Output

    LIGHT OUTPUT (lux) 3440000 860000 215000 137600 95556 Flux 382222 DISTANCE 0.17 0.35 0.52 0.87 1.05 DIAMETER(m) 11. CIRCUIT DIAGRAM AND PCB CONNECTIONS CIRCUIT DIAGRAM...
  • Page 26 PCB CONNECTIONS ● 8-Channel SLAVE1 ：P/N230060609 8 Channel Driver Board 1 M1-1 Motor 24V Input M1-2 Motor Reserved M1-3 Motor Reserved M1-4 Motor HALL1-6Magnet Sensor M1-5 Motor HALL1-5 Magnet Sensor M1-6 Motor HALL1-4 Magnet Sensor Reserved HALL1-3 Magnet Sensor Reserved HALL1-2 Magnet Sensor Reserved HALL1-1 Magnet Sensor...
  • Page 27 12. COMPONENT ORDER CODES NAME PART NO. QUANTITY REMARK PAN MOTOR 030040233A 030040233A TILT MOTOR DIMMER/STROBE MOTORS 030040121 030040212A ROTATING GOBO WHEEL MOTOR 030040073 GOBO ROTATION MOTOR FIXED GOBO WHEEL MOTOR 030040221A 030040224A COLOR WHEEL MOTOR FOCUS MOTOR 030040213A 030040254 PRISM ROTATION MOTOR 030040214 PRISM-IN/OUT MOTOR...
  • Page 28 1582 Xingye Avenue, Nancun Panyu Guangzhou, 511442 China TEL: +86-20-3995 2888 PR lighting will try its best to offer accurate and overall information about a product’s technical data. Any changes won’t be notified if necessary. Patented Products. Counterfeiting Will be Prosecuted! P/N: 320020809...
