- Page 1 AQUA LED 1500-W FRAMING PR-8176 This product manual contains important information about the safe installation and use of this projector. Please read and follow these instructions carefully and keep this manual in a safe place for future reference. PR LIGHTING LTD.
-
Page 2: Table Of Contents
Any future technical changes are not subject to further notice. Note: For the products made by Guangzhou PR lighting Ltd, the warranty for the whole product is one year starting from the delivery date but the light source is not within the warranty. -
Page 3: Safetyand Warnings
1. SAFETYAND WARNINGS NOTE Before a projector’s installation, power-on, operation and maintenance, please carefully read the safety information hereinafter! The following safety signs are used in the user manual. Goggles User Electrical Protective High Warning Flames Manual shock Gloves Temperature When unpacking , check if there is transportation damage before using the projector. -
Page 4: Instructions
There are safety cord holes at the bottom of the base of a projector. In view of safety, please run the safety ● cord supplied through the safety cord holes for safety support. Before any installation, maintenance and cleaning work, please ensure the projector is disconnected from ●... -
Page 5: Appearance
LUBRICATION ● To ensure smooth movement of gobos and focus lens, it’s advised rotators’bearings and 2 sliding bars for focus lens be lubricated every 2 months. High quality and high temperature lubricant/grease is advised.. TROUBLESHOOTING ● PROBLEM ACTION Check if the fuse is burned ... - Page 6 Note: 1. the distance between the foot of the base and the front lens cover(the head facing downward) 2. the distance between mounting truss and the front lens cover( the head facing downward) 3. The maximum diameter of the rotating head ( minimum spacing between fixtures) Warning please run the safety cords through 2 safety...
- Page 7 The earth wire(yellow/green) must be connected to the ground. And electrical connection must be in ● DMX OUT DMX IN accordance with the standards concerned. If any questions about the electrical installation, do not continue but consult a qualified electrician. DMX512 ●...
-
Page 8: Setupand Configuration
REPLACEMENT OF GOBOS ● Fix gobo wheel Rotating gobo wheel Color wheel Lock tilt and unfasten 4 screws of the small cover of the head. Open the cover and you’ll see the structure as above. 1→2. It’s installation Replacement of the color filter. Pull out the color filter directly by hand as the figure hereinafter in the sequence is in reverse sequence as the removal（2→1）. - Page 9 Projector configuration can be set conveniently via push button and color touch screen. Launch the projector and press button ENTER for more than 5 seconds to unlock the panel, the LCD will show the function menu of the projector, each main menu has its submenus and each submenu has a specific function. For details, please see the “OPERATION MENU”...
-
Page 10: Operation Menu
SLAVE SLAVE MASTER 主机 从机 从机 回路插 DMX TERMINATOR 输入 输出 输入 输出 输入 INPUT OUTPUT OUTPUT INPUT 6. OPERATION MENU 1st LEVEL 2nd LEVEL 3rd LEVEL 4th LEVEL 5th LEVEL 1-478 Short mode 1-475 Standard mode DMX Address 1-459 Extend mode Default IPAddress 2.X.X.X /10.X.X.X Address... - Page 11 Chinese Celsius Degree Temperature Unit Fahrenheit Degree Un-Link Wireless Really Un-Link? Confirm/ Cancel Factory Defaults Restore Defaults? Confirm/ Cancel Pan DMX Invert OFF/ ON Tilt DMX Invert OFF/ ON Pan/Tilt Settings Pan Tilt Swap OFF/ ON XYFeedback OFF/ ON Pan/Tilt mode Speed/Time Iris Invert OFF/ ON...
-
Page 12: Dmx Protocol
Fan Status Head Fan Strobe XXX Manual Effect Control Service Dimmer XXX … Factory Test Change Operation Mode? Confirm/ Cancel DMX Mode Preset Memory Change Operation Mode? Confirm/ Cancel User Memory 1 Change Operation Mode? Master Mode Operation User Memory 2 Change Operation Mode? Mode Preset Memory... - Page 13 Colour Macro 8 Colour Macro 9 Colour Macro 10 Colour Macro 11 Colour Macro 12 Colour Macro 13 Colour Macro 14 Colour Macro 15 Colour Macro 16 Colour Macro 17 Colour Macro 18 Colour Macro 19 Colour Macro 20 Colour Macro 21 Colour Macro 22 Colour Macro 23 Colour Macro 24...
- Page 14 Colour Macro 51 Colour Macro 52 Colour Macro 53 Colour Macro 54 Colour Macro 55 Colour Macro 56 Colour Macro 57 Colour Macro 58 Colour Macro 59 Colour Macro 60 Colour Macro 61 Colour Macro 62 Colour Macro 63 Colour Macro 64 Colour Macro 65 Colour Macro 66 Colour Macro 67...
- Page 15 Colour Macro 94 Colour Macro 95 Colour Macro 96 CMY colour mixing from slow to fast Cyan Cyan (Linear 0-100%) Cyan Fine Cyan in 16 Bit precision Yellow Yellow (Linear 0-100%) Yellow Fine Yellow in 16 Bit precision Magenta Magenta (Linear 0-100%) Magenta Fine Magenta in 16 Bit precision Linear adjust from high to low...
- Page 16 Iris Linear Iris from small to big 0-100% Iris in 16 bit Iris in 16 bit precision Iris Macro Iris Macro disabled Iris Macro1: from big to small with speed from slow to fast Iris Macro2: from small to big with speed from slow to fast Iris Macro3: Iris contracts from slow to fast Iris Macro4(Macro1 at random) with speed from slow to fast Iris Macro5(Macro2 at random) with speed from slow to fast...
- Page 17 Gobo2 shake from slow to fast Gobo3 shake from slow to fast Gobo4 shake from slow to fast Gobo5 shake from slow to fast Gobo6 shake from slow to fast Rotating gobo wheel rotation Indexing 0-360° Clockwise rotation from slow to fast Stop Anti-clockwise rotation from slow to fast Rotating gobo wheel rotation in 16 bit...
- Page 18 Framing blade 4right fine adjustment Framing module rotation Framing module indexing(0-360degrees) Stop Framing module clockwise rotation from slow to fast Stop Framing module anti-clockwise rotation from slow to fast Framing module rotation in 16 bit Framing module fine rotation Prism No Prism Prism Prism rotation...
- Page 19 Pan/Tilt speed Fast Speed Mode Pan &Tilt speed from fast to slow Power/Special functions No function: Reserved To activate following functions, stay in DMX value for at least 5 s Graphic display On Graphic display Off Reserved Reserved Fan standard mode Fan theater mode Reserved Fast speed dimmer...
-
Page 20: Logos On The Screen
Note: 1. Fan error can automatically turn the LED lamp off. 2. Note: "Speed Mode" means Pan and Tilt will move from Point A to Point B at their respective maximum speeds."Time Mode" means both Pan and Tilt will arrive at designated point at the same time. It's advised Time Mode be used if the projector runs circles or in oblique lines. -
Page 21: Technicaldata
Timeout Check if wiring, positioning parts and motors are normal Effect wheel Timeout Check if wiring, positioning parts and motors are normal Effect wheel Rotation Pan Board Error Check signal wire Tilt Board Error Check signal wire Driver Board 1 Error Check signal wire Driver Board2... - Page 22 Rotating gob wheel: Rotating gobo external size: 37.5mm Image size 24mm ; fixed gobo size 36.3mm Image size 23mm 1 fixed gobo wheel 7 exchangeable gobos+ white Shake effect with varied speeds and bi-directional rotation with varied speeds Fixed gobo wheel FRAMING MODULE Continual rotation with graphics with different sizes and shapes 4 blades for complete curtain effect...
- Page 23 HEAD MOVEMENT Pan 540º, Tilt 270º with auto position correction BEAM ANGLE Beam angle: 6°～ 56° Linear zoom with 16 bit precision CONTROL International standard DMX512 signal , 5 pin interface(Optional 3pin interface) RDM control protocol ArtNet protocol(Optional) 35channels in short mode, 38channels in standard mode,54channel in extended mode Master/slave synchronized mode Stand-alone mode OTHER FUNCTIONS...
-
Page 24: Circuit Diagramand Pcb Connections
LIGHT OUTPUT: 11. CIRCUIT DIAGRAMAND PCB CONNECTIONS CIRCUIT DIAGRAM ●... - Page 26 PCB CONNECTIONS ● Display board Name 485 Signal Reserved DMX 512 Signal Wireless Power Input Reserved Internet Input Driver board 1 Name LED driver Output LED driver Output PWM Input 48V Input + 48V Input - Pan and Tilt board Name Pan &...
- Page 27 Fan board Name PWM Fan Output PWM Output PWM Output 485 Signal 11-12 Reserved 13-15 Temperature Power Input Name Driver board3 Focus Motor Zoom Motor Prism In/Out Motor Prism rotation Motor Frost Motor Reserved Magnet sensors Zoom Magnet sensors Focus Prism/Prism rotation magnet sensor Reserved Power Input...
- Page 28 Driver board 3 Name Rotating gobo wheel rotation motor Effect wheel In/Out motor Gobo rotation motor Effect wheel rotation motor Rotating gobo wheel magnet sensor Gobo rotation sensor Power Input 9-10 485 Signal Input 485 Signal Output 13-14 Reserved Driver board 4 Name 485 Signal 6-11...
-
Page 29: Component Order Codes
Framing module board Name Motor 1 Software Input Motor 8 Motor 7 Iris Motor Motor 6 Motor 5 Motor 4 Motor 3 Reserved Motor 2 12. COMPONENT ORDER CODES NAME PART NO. QUANTITY REMARK POWER SUPPLY 192010215 POWER SUPPLY 192010224 LED ENGINE 150020323 FAN FOR LED ENGINE... - Page 30 Guangzhou, 511442 China TEL: +86-20-3995 2888 FAX: +86-20-3995 2330 PR lighting will try its best to offer accurate and overall information about a product’s technical data. Any changes won’t be notified if necessary. Patented Products. Counterfeiting Will be Prosecuted! P/N: 320020999A...
