- Page 1 XS 1200 WASH PR-2935M This product manual contains important information about the safe installation and use of this projector. Please read and follow these instructions carefully and keep this manual in a safe place for future reference. PR LIGHTING LTD. http://www.pr-lighting.com...
-
Page 2: Table Of Contents
INDEX SAFE USAGE OF THE PROJECTOR INSTALLING THE PROJECTOR FITTING THE LAMP POWER SUPPLY – MAINS CONTROL CONNECTIONS DMX TERMINATOR SETUP OPTIONS-PROJECTOR CONFIGURATION TO SET THE DMX START ADDRESS OPERATION MENU ERROR MESSAGES DMX PROTOCOL LED INDICATION MAINTENANCE KEEPING THE PROJECTOR CLEAN TROUBLESHOOTING TECHNICAL DATA ELECTRICAL DIAGRAM... -
Page 3: Safe Usage Of The Projector
SAFE USAGE OF THE PROJECTOR When unpacking and before disposing of the carton check there is no transportation damage before using the projector. Should there be any damage caused by transportation, consult your dealer and do not use the apparatus. The projector is for indoor use only, IP20. -
Page 4: Fitting The Lamp
INSTALL THE PROJECTOR Take 2 clamps and 2 safety cords out from the package and mount 2 clamps on the underside of fixture with 2 retainers attached to each clamp. Hang the fixture on the structure and fasten the screws attached to each clamp. (See the WARNING on the underside of the base as shown above) To pass 2 SAFETY CORDS through 4 HOLES for safety! Always ensure that the projector is firmly anchored to avoid vibration and slipping whilst functioning. - Page 5 POWER SUPPLY-MAINS Connect the power cord as follows: L (live) =brown E (earth) =yellow/green N (neutral) =blue Use the plug provided to connect the mains power to the projector paying attention to the voltage and frequency marked on the panel of the projector. It is recommended that each projector be supplied separately so that they may be individually switched on and off.
-
Page 6: Dmx Terminator
DMX TERMINATOR In the Controller mode, at the last fixture in the chain, the DMX output has to be connected with a DMX terminator. This prevents electrical noise from disturbing and corrupting the DMX control signals. The DMX terminator is simply an XLR connector with a 120Ω (ohm) resistor connected across pins 2 and 3, which is then plugged into the output socket on the last projector in the chain. - Page 7 Press button UP and DOWN, you can set the address; Press button ENTER to confirm; In the same time. The GREEN LED will flash one time. It means the setting has been enabled. Press button FUNC, it will return to the upper menu one by one. 7/20...
-
Page 8: Operation Menu
OPERATION MENU 1st LEVEL 2nd LEVEL 3rd LEVEL 4th LEVEL PR LIGHTING XS SERIES DMX Address=001 XS 1200 WASH DMX Address DMX Address Reset Reset Are You Sure? DMX Mode Standard 16 DMX Mode DMX Mode Extended 16 DMX Mode... - Page 9 Restore Defaults Display Mode On Always Display Mode Display Mode Off After Delay Display Invert Display Invert Display Invert Disp Dim Level Disp Dim Level Disp Dim Level Disp Dim Level Display Options Disp Dim Level Disp Dim Level Display Dimming Disp Dim Level Disp Dim Level Disp Dim Level...
-
Page 10: Error Messages
ERROR MESSAGES In the course of launch, XS1200 Wash examines automatically whether there are errors and if there are, it will display information as follows: Display Message Sensor Err S1-M1 Colour wheel 1 (1# drive board motor 1) error Sensor Err S1-M2 CYM-cyan (1# drive board motor 2) error Sensor Err S1-M3 CYM-yellow (1# drive board motor 3) error... -
Page 11: Dmx Protocol
DMX PROTOCOL Short Standard Extended FUNCTION DESCRIPTION mode mode mode 000-010 Black 011-025 Open Strobe 026-225 Strobe speed from slow to fast 226-246 Macro 247-255 Open Black 000-003 Dimmer 004-255 Dimming from dark to light (0-100%) Dimmer Fine 000-255 Dimmer in 16 Bit precision 000-016 White Yellow+ Magenta=Red... - Page 12 Rainbow reverse rotation speed from 192-255 fast to slow 000-016 White 017-024 White/ colour 1 025-032 Colour 1 033-040 Colour 1/ colour 2 041-048 Colour 2 049-056 Colour 2/colour 3 057-064 Colour 3 065-072 Colour 3/colour 4 073-080 Colour 4 Colour Wheel 2 081-088 Colour 4/colour 5...
-
Page 13: Led Indication
LED INDICATION DMX signal OK Green No DMX signal Flash DMX signal error Yellow Setting the panel Blue Power Running self test mode Red/Green Green Reserved MAINTENANCE If the projector’s lens becomes damaged or broken it should be replaced. If the lamp becomes damaged or deformed in any way it must be replaced. - Page 14 Check the lenses are not broken. Defective projection Remove dust or grease from the lenses. Make sure the lamp is installed correctly. The project image appears to have a halo Carefully clean the optical group lenses and the projector components. Check the optics is clean.
-
Page 15: Technical Data
TECHNICAL DATA VOLTAGES: 220V/230V AC，50/60Hz Options: 200V/240V AC，50/60Hz POWER CONSUMPTION: 1300W@220V LAMP: PHILIPS MSR Gold 1200 SA/2 DE Colour Temperature 7500°K SFc10-4， double ended Socket Manufacturers Rated Lamp Life 750 Hours replacement OSRAM SharXS HTI 1200 W/D7/60 Colour Temperature 6000°K SFc10-4，... - Page 16 25°～38° linearly adjustable CONTROL: DMX512, 3 pin and 5 pin interfaces RDM control protocol 12 channels in short mode, 15 channels in standard mode, and 20 channels in extended mode. Self-test mode OTHER FUNCTIONS: Adjustable Pan & Tilt speed Fixture and lamp usage time display LCD display in English language menu Energy saving function of the ballast Built-in analyzer for easy fault finding, error messages...
- Page 17 FRESNEL LENS LIGHT OUTPUT: OPTIONAL CONVEX LENS LIGHT OUTPUT 17/20...
- Page 18 M1-6A Dimmer 调光 View side of no axletree 色片盘 1 青色 黄色 品红色 变焦 色片盘 2 频闪 1 频闪 2 M1-1 M1-2 M1-3 M1-4 M1-5 M1-6B M2-1 M2-2 M2-3 Dimmer 调光 COLOR-1 CYAN YELLOW MAGENTA ZOOM COLOR-2 STROBE-1 STROBE-2 View side of no axletree View side of no axletree View side of no axletree View side of no axletree...
-
Page 19: Component Order Codes
COMPONENT ORDER CODES NAME PART NO. QUANTITY REMARK 193020008 20A 115/250VAC MAINS FILTER 190010074 THERMOSTAT 040070059 575W 7A BALLAST IGNITOR 040090036 100050064 MSR 1200 SA/2 DE LAMP 290151323 HTD-804-3M TILT DRIVE BELT PAN DRIVE BELT 290151322 HTD-531-3M 030040127A PAN &TILT MOTOR 030040084 COLOUR WHEEL MOTOR 030040095... - Page 20 PR LIGHTING LTD. 1582 Xingye Avenue, Nancun Panyu Guangzhou, 511442 China TEL: +86-20-3995 2888 FAX: +86-20-3995 2330 P/N: 320020036 Version: 20110826 20/20...
