AQUA LED 1800-W SPOT
PR-8168
This product manual contains important information about the safe installation and use of this projector.
Please read and follow these instructions carefully and keep this manual in a safe place for future reference.
PR LIGHTING LTD.
http://www.pr-lighting.com
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AQUA LED 1800-W SPOT and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for PR Lighting AQUA LED 1800-W SPOT

Summary of Contents for PR Lighting AQUA LED 1800-W SPOT

  • Page 1 AQUA LED 1800-W SPOT PR-8168 This product manual contains important information about the safe installation and use of this projector. Please read and follow these instructions carefully and keep this manual in a safe place for future reference. PR LIGHTING LTD.
  • Page 2 Any future technical changes are not subject to further notice. Note: For the products made by Guangzhou PR lighting Ltd, the warranty for the whole product is one year starting from the delivery date but the light source is not within the warranty.

  • Page 3: Safety And Warnings

    1. SAFETYAND WARNINGS NOTE Before a projector’s installation, power-on, operation and maintenance, please carefully read the safety information hereinafter! The following safety signs are used in the user manual. Goggles User Electrical Protective High Warning Flames Manual shock Gloves Temperature When unpacking , check if there is transportation damage before using the projector.
  • Page 4 All power cords must conform to related safety and regulations ● Do not switch on and off the projector constantly in very short intervals, otherwise the light source’s and other ● electrical parts’ life will be shortened . There are safety cord holes at the bottom of the base of a projector. In view of safety, please run the safety ●...
  • Page 5 Do not use alcohol or other organic solvent to clean the housing to avoid damage. ● Do not use any solvent with chemical elements to clean color filters or hot mirror. ● LUBRICATION ● To ensure smooth movement of gobos and focus lens, it’s advised rotators’bearings and 2 sliding bars for focus lens be lubricated every 2 months.
  • Page 6 During transportation, please lock the projector well; Before the use of projector please unlock the head. It’s forbidden to run the projector without unlock Pan and Tilt Note: 1. the distance between the foot of the base and the front lens cover(the head facing downward) 2.
  • Page 7 L (live) =brown E (earth) =yellow/green N (neutral) =blue Before power connection, please ensure the power supplied must match what the nameplate says. It is recommended that each projector be connected with power separately so that they may be individually switched on and off. The earth wire(yellow/green) must be connected to the ground.
  • Page 8 into the output socket on the last projector in the chain. The connections are illustrated below DMX TERMINATOR CONNECTION Connect a 120 (OHM) resistor across pins 2 and 3 in an XLR plug and insert into the DMX out socket on the last unit in the chain.
  • Page 9 Projector configuration can be set conveniently via push button and LCD display. Launch the projector and press button ENTER for more than 3 seconds to unlock the panel, the LCD will show the function menu of the projector, each main menu has its submenus and each submenu has a specific function. For details, please see the “OPERATION MENU”...

  • Page 10: Operation Menu

    MASTER/SLAVE MODE ● Many projectors can run synchronously in the Master/Slave mode by linking them with each other. First, connect the first fixture’s DMX output to the second fixture’s DMX input using XLR-XLR control cable and then connect the second fixture’s DMX output to the third fixture’s DMX input, and so on until all projector are connected in this way.
  • Page 11 sACN Only sACN In /XLR Out Normal time out Loss of DMX Hold Last Value OffAfter Delay Display Mode OnAlways Invert OFF Display Config Display Invert Invert ON InvertAuto English Language Setting Chinese Celsius Degree Temperature Unit Fahrenheit Degree Un-Link Wireless Really Un-Link? Confirm/ Cancel Defaults...

  • Page 12: Dmx Protocol

    System= XXX Driver Board 3 Boot =XXX System= XXX Driver Board 4 Boot =XXX System= XXX Fan Board Boot =XXX Electronic SN= Electronic SN ************ RDM Device Label RDM Device Label ANSI E1.20 RDM Version X.X Fan Status Head Fan Strobe XXX Manual Effect Control Service...
  • Page 13 No Function Colour Macro 1 Colour Macro 2 Colour Macro 3 Colour Macro 4 Colour Macro 5 Colour Macro 6 Colour Macro 7 Colour Macro 8 Colour Macro 9 Colour Macro 10 Colour Macro 11 Colour Macro 12 Colour Macro 13 Colour Macro 14 Colour Macro 15 Colour Macro 16...
  • Page 14 Colour Macro 43 Colour Macro 44 Colour Macro 45 Colour Macro 46 Colour Macro 47 Colour Macro 48 Colour Macro 49 Colour Macro 50 Colour Macro 51 Colour Macro 52 Colour Macro 53 Colour Macro 54 Colour Macro 55 Colour Macro 56 Colour Macro 57 Colour Macro 58 Colour Macro 59...
  • Page 15 Colour Macro 86 Colour Macro 87 Colour Macro 88 Colour Macro 89 Colour Macro 90 Colour Macro 91 Colour Macro 92 Colour Macro 93 Colour Macro 94 Colour Macro 95 CMY colour mixing from slow to fast Cyan Cyan (Linear 0-100%) Cyan Fine Cyan in 16 Bit precision Yellow...
  • Page 16 Color 6(Purple) Color6(Purple)/ White White Anti-clockwise rainbow effect rotation speed from slow to fast Clockwise rainbow effect rotation speed from slow to fast Color Wheel Fine Color Continual positioning in 16 Bit precision Iris Linear Iris from small to big 0-100% Iris in 16 bit Iris in 16 bit precision Iris Macro...
  • Page 17 Rotating gobo wheel 1 fine rotation Rotating gobo wheel 2 White Gobo1 Gobo2 Gobo3 Gobo4 Gobo5 Gobo6 Clockwise rotation from slow to fast Anti-clockwise rotation from slow to fast Gobo1 shake from slow to fast Gobo2 shake from slow to fast Gobo3 shake from slow to fast Gobo4 shake from slow to fast Gobo5 shake from slow to fast...
  • Page 18 Focus Fine Focus in 16 precision Zoom Linearly zooming Zoom Fine Zoom in 16 Bit precision Pan movement Pan Fine Pan movement in 16 bit precision Tilt Tilt movement Tilt fine Tilt movement 16 bit precision Pan/Tilt speed Fast Speed Mode Pan &Tilt speed from fast to slow Power/Special functions No function:...

  • Page 19: Error Message

    Reserved Pan/Tilt speed mode Pan/Tilt time mode Reserved Reserved Pan/Tilt reset Colour wheel reset Gobo wheels reset Reserved Zoom/focus/frost/prism reset Others(Iris/ effect wheel) reset Total reset Reserved Reserved Note: 1. Fan errors can cause LED lamps to be shut off; 2.

  • Page 20: Technical Data

    Timeout Check if wiring, positioning parts and motors are normal Yellow Timeout Check if wiring, positioning parts and motors are normal Magenta Timeout Check if wiring, positioning parts and motors are normal Timeout Check if wiring, positioning parts and motors are normal Color wheel Timeout Check if wiring, positioning parts and motors are normal...

  • Page 21: Effect Wheel

    COLOR S (Optional) CMY linear coloring mixing system with macros 1 Color Wheel 6 color s+ white Blue Purple Bi-directional rainbow effect with variable speeds and half color effect Linear /stepping color changing Green Linear CTO system(0-100%) GOBOS(Optional) Orange Pink 2 rotating gobo wheels: 6 exchangeable+ white, glass or metal gobos Bi-directional rotation, indexing, shake with varied speeds, bi-directional scrolling with varied speeds...

  • Page 22: Head Movement

    3 dimmer speeds 4 dimmer gamma curves Dimmer frequency(1.2K~2.5K) good for high speed 4K video camera IRIS Linear iris 5-100% with macros STROBE Double shutter blades, 0.3~25 F.P.S HEAD MOVEMENT Pan 540º, Tilt 270º with auto position correction BEAMANGLE Linear zoom 6°～ 56°with 16 bit precision CONTROL International standard DMX512 signal , 5 pin interface RDM control protocol...

  • Page 23: Light Output

    WEIGHT 55Kg SIZES: LIGHT OUTPUT CIRCUIT DIAGRAMAND PCB CONNECTIONS...

  • Page 24: Circuit Diagram

    CIRCUIT DIAGRAM...
  • Page 25 PCB CONNECTIONS ● Master Board of PR-8168 Name 485 signal Reserved 512 signal Wireless interface Power Input Reserved Ethernet board interface LED Drive r Board of PR-8168 Name LED driver output LED driver output PWM dimmer input 48V positive input 48Vnegtive input Fan adaptor board of PR-8168 Name...
  • Page 26 Power adaptor board of PR-8168 Name 485 singal 6-11 Reserved +24V power input -24V power input 14-19 24V power ouput 8 channel fan speed adjusting board of PR-8168 Name Adjusting fan ouput PWM output PWM output 11-12 485 signal 13-15 Reserved Thermal switch Power input...
  • Page 27 5 Channel Motor Driver Board(CMY) of PR-8168 Name CTO motor Color wheel motor Cyan motor Yellow motor Magenta motor Reserved CTO/Yellow magnet sensor Color wheel/Cyan magnet sensor Cyan magnet sensor 10-11 Power input 485 signal input 485 signaloutput 14-15 16-17 Resvered Name Rotating gobo wheel1 motor...

  • Page 28: Component Order Codes

    13-14 Resvered 2Channel Motor Driver Board(Gobo wheel2) of PR-8168 12. COMPONENT ORDER CODES NAME CODE NUMBER REMARK SWITCHING POWER SUPPLY 192010220 SWITCHING POWER SUPPLY 192010224 LED ENGINE MODULE 150020313 LED ENGINE MODULE FAN 030060109 COLOR WHEELTURBO FAN 030060072 DRIVER POWER FAN 030060075 LED DRIVER BOARD FAN 030060084...
  • Page 31 Guangzhou, 511442 China TEL: +86-20-3995 2888 FAX: +86-20-3995 2330 PR lighting will try its best to offer accurate and overall information about a product’s technical data. Any changes won’t be notified if necessary. Patented Products. Counterfeiting Will be Prosecuted! P/N: 320021016A...

This manual is also suitable for:
