XR 1000 BEAM
PR-2723
This product manual contains important information about the safe installation and use of this projector.
Please read and follow these instructions carefully and keep this manual in a safe place for future reference.
PR LIGHTING LTD.
http://www.pr-light ing.com
1/20

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the XR 1000 BEAM PR-2723 and is the answer not in the manual?

Questions and answers

Summary of Contents for PR Lighting XR 1000 BEAM PR-2723

  • Page 1 PR-2723 This product manual contains important information about the safe installation and use of this projector. Please read and follow these instructions carefully and keep this manual in a safe place for future reference. PR LIGHTING LTD. http://www.pr-light ing.com 1/20...
  • Page 2: Table Of Contents

    INDEX SAFE USAGE OF THE PROJECTOR INSTALLING THE PROJECTOR FITTING THE LAMP POWER SUPPLY – MAINS CONTROL CONNECTIONS DMX TERMINATOR SETUP OPTIONS-PROJECTOR CONFIGURATION TO SET THE DMX START ADDRESS OPERATION MENU ERROR MESSAGES REPLACING GOBOS DMX PROTOCOL LED INDICATION MAINTENANCE LUBRICATION KEEPING THE PROJECTOR CLEAN TROUBLESHOOTING...
  • Page 3: Safe Usage Of The Projector

    SAFE USAGE OF THE PROJECTOR When unpacking and before disposing of the carton check there is no transportation damage before using the projector. Should there be any damage caused by transportation, consult your dealer and do not use the apparatus. The projector is for indoor use only, IP20.
  • Page 4: Fitting The Lamp

    INSTALL THE PROJECTOR Take 2 clamps and the safety cord out from the package and mount 2 clamps on the underside of fixture with 2 retainers attached to each clamp. Hang the fixture on the structure and fasten the screws attached to each clamp. (See the WARNING on the underside of the base as shown above) To pass the SAFETY CORD through the HOLES for safety! Always ensure that the projector is firmly anchored to avoid vibration and slipping whilst functioning.
  • Page 5: Power Supply – Mains

    POWER SUPPLY-MAINS Connect the power cord as follows: L (live) =brown E (earth) =yellow/green N (neutral) =blue Before connection with mains power, make sure that the voltage and frequency marked on the rating plate of the projector match what are supplied. It is recommended that each projector be supplied separately so that they may be individually switched on and off. IMPORTANT It is essential that each projector is correctly earthed(yellow/green twin wire) and the electrical installation conforms to all relevant standards.
  • Page 6: Dmx Terminator

    DMX TERMINATOR In the Controller mode, at the last fixture in the chain, the DMX output has to be connected with a DMX terminator. This prevents electrical noise from disturbing and corrupting the DMX control signals. The DMX terminator is simply an XLR connector with a 120 (ohm) resistor connected across pins 2 and 3, which is then plugged into the output socket on the last projector in the chain.
  • Page 7: Operation Menu

    OPERATION MENU First Menu Secondary Menu Third Menu Fourth Menu DMX Address (XXX:1~485) Reset Are You Sure Standard 16 DMX Mode Extended 16 (Default:Standard) Short 8 By Control Channel By Power On Lamp Control Config Settings (Default:CHAN) By DMX Present Fan Operate Mode Fan Operate Mode Normal...
  • Page 8 CTO Invert Defaults Defaults Defaults Restore Defaults Display On Always Display Mode Display Off After Delay Display Invert Display Invert Display Invert Disp Dim Level Disp Dim Level Disp Dim Level Disp Dim Level Disp Dim Level Display Options Disp Dim Level Display Dimming Disp Dim Level Disp Dim Level...
  • Page 9 Driver Board 2= Driver Board 2 X.X.X Driver Board 3= Driver Board 3 X.X.X Pan and Tilt= Pan and Tilt X.X.X Head Sensor= Power Board X.X.X DMX Channel View DMX Values 1=XXX Electronic SN= Electronic SN ************ RDM Device Label RDM Device Label ANSI E1.20 RDM Version X.X...
  • Page 10: Error Messages

    ERROR MESSAGES In the course of launch, Projector examines automatically whether there are errors and if there are, it will display information as follows: Sensor Err S1-M1 Color wheel (1# drive board motor 1) error Sensor Err S1-M2 CTO (1# drive board motor 2) error Sensor Err S1-M3 CYM-magenta (1# drive board motor 3) error Sensor Err S1-M4...
  • Page 11: Dmx Protocol

    DMX PROTOCOL Short Standard Extended Functions Description Mode Mode Mode Close 000-010 Open 011-025 Strobe speed from slow to fast 026-228 Strobe Macro 1 229-239 240-241 Macro 2 Macro 3 242-246 247-255 Open 000-003 Close Dimmer Linear dimming (0-100%) 004-255 Dimmer Fine 0-255 Dimmer in 16 bit...
  • Page 12 106-113 Color7 114-120 Color7+ White 121-127 White 128-191 Rotation, Clock wise from slow to fast 192-255 Rotation, Anti-clockwise from slow to fast Iris 000-255 From Big to Small In size Iris Fine 000-255 Iris in 16 Bit 000-010 White 011-072 Iris Effect 1 073-136 Iris Effect 2...
  • Page 13 196-205 Shake of Gobo 2 206-215 Shake of Gobo 3 216-225 Shake of Gobo 4 226-235 Shake of Gobo 5 236-245 Shake of Gobo 6 246-255 Shake of Gobo 7 000-128 Gobo Indexing (0°-540°) 129-188 Rotation ,Clockwise From slow to Fast Gobo Rotation 189-195 Stop...
  • Page 14: Lubrication

    LED INDICATION DMX signal OK Green No DMX signal Flash DMX signal error Yellow Setting the panel Blue Power Running self test mode Red/Green Green Reserved Wireless signal OK Green No connection to any transmitter Flash Lost contact with the transmitter or linking transmitter MAINTENANCE If the projector’s lens becomes damaged or broken it should be replaced.
  • Page 15: Technical Data

    TECHNICAL DATA VOLTAGES: 200V~240V AC,50/60Hz POWER CONSUMPTION: 1200W@220V LAMP: OSRAM HTI 1000W/PS Colour Temperature 6000K Socket PGJX36 Manufacturers Rated Lamp Life 750hours COLOURS: Smooth CYM colour mixing system plus CTO with macro 1 Color Wheel with 7 color plus white With variable speed bi-directional rainbow effect Step/linear colour changing COLOUR TEMPERATURE CORRECTION:...
  • Page 16 DIMMER: 0-100% linearly adjustable IRIS: 5-100% linearly adjustable with Macro SHUTTER: Double shutter blades, 0.3~25 F.P.S with Macro HEAD MOVEMENT: Pan 540º, Tilt 270º with auto position correction BEAM ANGLE: Beam: 5° in high light; Beam angle: 10°-21°, Frost effect: 9°-31°, Linear adjustment in 16 bit CONTROL: DMX512, 3 pin and 5 pin interfaces 21channels in short mode, 26 channels in standard mode and 33 channels in extended mode...
  • Page 17 LIGHT OUTPUT: 17/20...
  • Page 18 18/20...
  • Page 19 omponent Order Code NAME PART NO. QUANTITY REMARK Pan Motor 030040178 Tilt Motor 030040178 Dimmer Motor 030040186 Strobe Motor 030040210 CYM Motor 030040211 Rotating Gobo Wheel Motor 030040212 Fixed Gobo Wheel Motor 030040215 Color Wheel Motor 030040217 Iris Motor 030040217 Rotator Motor 030040218 Focus Motor...
  • Page 20 PR LIGHTING LTD. 1582 Xingye Avenue, Nancun Panyu Guangzhou, 511442 China TEL: +86-20-3995 2888 FAX: +86-20-3995 2330 P/N: 320020085 Version: 20120619 (Preliminary) 20/20...
