Summary of Contents for PR Lighting XRLED PR-8177A
- Page 1 XRLED 1500-W Framing PR-8177A This product manual contains important information about the safe installation and use of this projector. Please read and follow these instructions carefully and keep this manual in a safe place for future reference. PR LIGHTING LTD. http://www.pr-lighting.com...
-
Page 2: Table Of Contents
Any future technical changes are not subject to further notice. Note: For the products made by Guangzhou PR lighting Ltd, the warranty for the whole product is one year starting from the delivery date but the light source is not within the warranty. -
Page 3: Safety And Warnings
1. SAFETY AND WARNINGS NOTE Before a projector’s installation, power-on, operation and maintenance, please carefully read the safety information hereinafter! The following safety signs are used in the user manual. Warning User Electrical Goggles Protective Flames High Manual shock Gloves Temperature When unpacking , check if there is transportation damage before using the projector. -
Page 4: Instructions
Do not switch on and off the projector constantly in very short intervals, otherwise the light source’s and other ● electrical parts’ life will be shortened . The projector is of class IP65, and not used in the environment higher than it. ●... -
Page 5: Appearance
LUBRICATION ● To ensure smooth movement of gobos and focus lens, it’s advised rotators’ bearings and 2 sliding bars for focus lens be lubricated every 2 months. High quality and high temperature lubricant/grease is advised.. TROUBLESHOOTING ● PROBLEM ACTION Check if the fuse is burned ... - Page 6 CLAMP SAFETY WARMING Please run safety cord CORD through 2 safety holes for safety Take 2 clamps and 1 safety cords out from the package and mount 2 clamps on the underside of fixture with 4 retainers attached to each clamp. Hang the fixture on the structure and fasten the screws attached to each clamp. (See the WARNING on the underside of the base as shown above) Always ensure that the projector is firmly anchored to avoid vibration and slipping whilst functioning.
- Page 7 DMX CONTROL CONNECTION ● Connection between controller and projector and between one projector and another must be made with a twin-screened cable, with each wire having at least a 0.5mm in diameter. Connection to and from the projector is via cannon 5 pin (which are included with the projector) or 5 pin XLR plugs and sockets.
-
Page 8: Setup And Configuration
REPLACEMENT OF GOBOS ● Rotating gobo wheel Color wheel Fixed gobo wheel Lock the tilt and unfasten 6 fast fit screws in the front cove. Open the cover and you’ll see the structures as the figures above. For the replacement of color filters, use the fingers to remove the filters and place new ones. For the rotating gobos: remove the rotator by hand;... - Page 9 save any changes o enter into submenus. Push key ▲or ▼ to change numbers(plus or minus) or tap any item required for changes. Push the left key or shortcut key X to go back to the upper level menu. If none pushed, the system will go back to initial display automatically.
-
Page 10: Operation Menu
6. OPERATION MENU 1st LEVEL 2nd LEVEL 3rd LEVEL 4th LEVEL 5th LEVEL 1-477（Short Mode） 1-474（Standard Mode） DMX Address 1-458（Extended Mode） Default IP Address 2.X.X.X /10.X.X.X Address IP Address Custom IP Address X.X.X.X SubNet Mask X.X.X.X ArtNet 0-255 ArtNet Universe Total Reset Really Reset? Confirm/ Cancel... - Page 11 Fahrenheit Degree Un-Link Wireless Really Un-Link? Confirm/ Cancel Defaults Restore Defaults? Confirm/ Cancel Pan DMX Invert OFF/ ON Tilt DMX Invert OFF/ ON Pan/Tilt Settings Pan Tilt Swap OFF/ ON XY Feedback OFF/ ON Pan/Tilt mode Speed/Time Iris Invert OFF/ ON Zoom Invert OFF/ ON Invert Settings...
- Page 12 Strobe XXX Manual Effect Control Service Dimmer XXX … Factory Test Change Operation Mode? Confirm/ Cancel DMX Mode Preset Memory Change Operation Mode? Confirm/ Cancel User Memory 1 Change Operation Mode? Master Mode Operation User Memory 2 Change Operation Mode? Mode Preset Memory Change Operation Mode?
-
Page 13: Dmx Protocol
7. DMX PROTOCOL Short Standard Extended Decimal Function Description Decimal High mode mode mode Strobe Close Pulse strobe speed from slow to fast Strobe speed slow to fast Dimmer Close Dimmer from dark to light (0-100%) Dimmer Fine Fine dimmer CYM Macro The following functions can be used after CMY,CTO, and Color Wheels1 and Color Wheel2... - Page 14 Colour Macro 27 Colour Macro 28 Colour Macro 29 Colour Macro 30 Colour Macro 31 Colour Macro 32 Colour Macro 33 Colour Macro 34 Colour Macro 35 Colour Macro 36 Colour Macro 37 Colour Macro 38 Colour Macro39 Colour Macro 40 Colour Macro 41 Colour Macro 42 Colour Macro 43...
- Page 15 Colour Macro 70 Colour Macro 71 Colour Macro 72 Colour Macro 73 Colour Macro 74 Colour Macro 75 Colour Macro 76 Colour Macro 77 Colour Macro 78 Colour Macro 79 Colour Macro 80 Colour Macro 81 Colour Macro 82 Colour Macro 83 Colour Macro 84 Colour Macro 85 Colour Macro 86...
- Page 16 Colour Wheel Continual positioning index 0-360° positioning White White/Color1(UV) Color1(UV) Color1(UV)/Color 2(Red) Color 2(Red) Color 2(Red)/Color 3(Pink) Color 3(Pink) Color 3(Pink)/ Color 4(Orange) Color 4(Orange) Color 4(Orange) /Color 5(Green) Color 5(Green) Color 5（Green））/Color 6（Blue） Color 6(Blue) Color6(Blue)/ White White Clockwise rainbow effect rotation speed from slow to fast Anti-clockwise rainbow effect rotation speed from slow to fast Color Wheel Fine Color Continual positioning in 16 Bit precision...
- Page 17 Gobo5 Gobo6 Gobo7 Clockwise rotation from slow to fast Anti-clockwise rotation from slow to fast Gobo1 shake from slow to fast Gobo2 shake from slow to fast Gobo3 shake from slow to fast Gobo4 shake from slow to fast Gobo5 shake from slow to fast Gobo6 shake from slow to fast Gobo7 shake from slow to fast Rotating gobo wheel...
- Page 18 Framing blade 2 left Framing blade2 left linearly closing from big to small Framing blade 2 left in 16 bit Framing blade 2 left fine adjustment Framing blade 2 right Framing blade 2 right linearly closing from big to small Framing blade 2 right in 16 bit Framing blade 2 right fine adjustment Framing blade 3 left...
- Page 19 Effect wheel in Effect Wheel Rotation Forwards rotation from slow to fast Reverse rotation from slow to fast Frost Light Frost from 0% to 100% Focus Linearly focusing Focus Fine Focus in 16 precision Zoom Linearly zooming Zoom Fine Zoom in 16 Bit precision Pan movement Pan Fine Pan movement in 16 bit precision...
- Page 20 Gamma curve 2.6 LED refresh rate 1200Hz LED refresh rate 2400Hz LED refresh rate 4800Hz LED refresh rate 10000Hz LED refresh rate 12000Hz LED refresh rate 1500Hz LED refresh rate 20000Hz LED refresh rate 25000Hz Reserved Pan/Tilt speed mode Pan/Tilt time mode Reserved Reserved Pan/Tilt reset...
-
Page 21: Technical Data
8.TECHNICAL DATA ELECTRICAL PARAMETERS Input voltage: 100V-240V AC，50/60Hz Orange Pink Input power: 880 W@220V AC 930 W@100V AC Power factor: PF>0.9 Green SPECIFICATIONS OF LIGHT SOURCE Lamp 600W Colour Temperature 8000K 20000hrs Manufacturers Rated Lamp Life Blue Ra≥70 , R9≥90 Ra≥95 Lamp：... - Page 22 Φ24mm Φ23mm Image size of rotating gobo is , image size of fixed gobos is FRAMING MODULE Continual rotation with graphics with different sizes and shapes 4 blades for full curtain effect PRISM 1pc 4 facet prism, bi-directional rotation with varied speeds and indexing function FROST Linear frost (0-100%) EFFECT WHEEL...
- Page 23 Pan and Tilt swappable and invertible Fixture and lamp hours’ display Color screen, Chinese-English menus, brightness and contrast adjustable Diagnostic system with sensors Built-in rechargeable battery for settings via control panel without mains power Software version display Protection and insulation of input signals Modular construction for easy maintenance ArtNet interface DMX512 wireless receiver...
-
Page 24: Circuit Diagram & Pcb Connections
LIGHT OUTPUT: 1882 56°（lux） 6°（lux） 68560 17690 7862 4422 2830 1966 6° 56° Distance（m） 6° Diameter（m） 1.19 1.79 2.38 2.98 3.57 56°Diameter（m） 4.90 9.79 14.69 19.59 24.49 29.38 CIRCUIT DIAGRAM... - Page 26 PCB CONNECTIONS Master board ● Name DMX512 signal input Reserved Reserved Reserved Power input Reserved 485 signal input Wireless signal input Ethernet module interface 8-channel driver board1 ● Name 485 signal input 485 signal output Focus 1 Focus 2 Zoom 1 Zoom 2 Magnet sensor for zoom Magnet sensor for prism/prism...
- Page 27 LED driver board ● Name Power input –negative Power input positive LED output PWM input Pan /Tilt driver board ● Name Optical sensor for Tilt Magnet sensor for Tilt Reserved Reserved Power input 485 signal output 485 signal input Reserved Magnet sensor for Pan Optical sensor for Pan Pan motor...
- Page 28 6-channel driver board ● Name Magnet sensor for magenta/CTO Magnet sensor for yellow flag Magnet sensor for color filters/cyan flag Reserved Yellow Reserved 485 signal input 485 signal output Magenta Color wheel Cyan Reserved Reserved Power input Framing module driver board ●...
- Page 29 2-channel driver board ● Name 485 signal input 485 signal output Gobo wheel Framing module rotation Framing module rotation/fixed gobo wheel magnet sensor Reserved Reserved Reserved Reserved Reserved Reserved Reserved Power input Power input...
-
Page 30: Component Order Codes
10. COMPONENT ORDER CODES NAME CODE NUMBER REMARK 192010215 SWITCHING POWER SUPPLY 192010226 SWITCHING POWER SUPPLY LED ENGINE MODULE 150020323 LED ENGINE MODULE FAN 030060074C HEAD FAN 030040119 TILT BELT 290151207 PAN BELT 290151240 030040213A FOCUS MOTOR 030040154A ZOOM MOTOR PRISM IN/OUT MOTOR 030040253 PRISM ROTATION MOTOR... - Page 32 Guangzhou, 511442 China TEL: +86-20-3995 2888 FAX: +86-20-3995 2330 PR lighting will try its best to offer accurate and overall information about a product’s technical data. Any changes won’t be notified if necessary. Patented Products. Counterfeiting Will be Prosecuted! P/N: 320020991...
