Custom Audio Electronics TK300II Command Reference Manual page 85

[Notes] • Error correction level is specifi ed by either "level" or "ratio".
• Error correction level specifi ed by "level" (m = 0) is as follows. The number of the error
correction code word is fi xed regardless of the number of code words on the data area.
• Error correction level specifi ed by "ratio" (m = 1) is as follows. The error correction level
is defi ned by the calculated value [number of data code word × x × 0.1 = (A)]. The number
of the error correction code word is changeable in proportion to the number of the code
words on the data area.
0 - 3
4 - 10
11 - 20
21 - 45
46 - 100
101 - 200
201 - 400
400 or more
• The error correction code word calculated by modulus 929.
[Default] m = 1, x = 1 [ratio: 10%]
[Reference]
[Example]
<B2D k, P, x, d1...dn>
Printers: KPM300
[Name]
Store the two-dimensional barcode data in the symbol save area
[Format] ASCII
[Range]
[Description] Store the PDF417 symbol data (d1...dn) in the symbol save area.
• x = number of characters ( = dn)
• d1...dn = barcode data
[Notes] • n bytes of d1...dn are processed as symbol data.
• Specify only the data code word of the symbol with this function. Be sure not to in-
clude the control data in the data d1...dn because they are added automatically by the
printer.
[Default]
[Reference]
[Example]
x FUNCTION
0 Error correction level 0
1 Error correction level 1
2 Error correction level 2
3 Error correction level 3
4 Error correction level 4
5 Error correction level 5
6 Error correction level 6
7 Error correction level 7
8 Error correction level 8
CALCULATED
VALUE (A)
, KUBE II
VeriPrint
<B2D k, P, x, d1...dn>
N. OF ERROR CORRECTION CODE WORD
2
4
8
16
32
64
128
256
512
CORRECTION LEVEL
Error correction level 1
Error correction level 2
Error correction level 3
Error correction level 4
Error correction level 5
Error correction level 6
Error correction level 7
Error correction level 8
, KUBE-L
VeriPrint VeriPrint
SVELTA Emulation
N. OF ERROR
CORRECTION CODE WORD
4
8
16
32
64
128
256
512
, TK300II
VeriPrint
Command Reference
