Safety advice WARNING FOR YOUR OWN SAFETY, PLEASE READ THIS USER MANUAL CAREFULLY BEFORE YOUR INITIAL START-UP! • Before your initial start-up, please make sure that there is no damage caused during transportation. • Should there be any damage, consult your dealer and do not use the equipment. • To maintain the equipment in good working condition and to ensure safe operation, it is necessary for the user to follow the safety instructions and warning notes written in this manual. • Please note that damages caused by user modifications to this equipment are not subject to warranty. CAUTION! TAKE CARE USING THIS EQUIPMENT! HIGH VOLTAGE-RISK OF ELECTRIC SHOCK!! IMPORTANT: The manufacturer will not accept liability for any resulting damages caused by the non-observance of this manual or any unauthorised modification to the equipment.
Page 3
• 0 - 100% dimming with variable strobe • Bracket allows for floor standing applications • 4 push button menu with LED display • IP rated power in/out • IP rated DMX in/out • Convection cooled • Adjustable tilt angle • Large carry handles NOTE: The fixture may be installed by removing the rubber feet and securing using four or more fixing holes in the base. 45° - Lux 16290 4843 2073 1242 Specifications Spectra Flood 24T9 Power consumption 230W Power supply 100~240V, 50/60Hz 45° Dimensions 425 x 570 x 264mm Weight 15.7kg Order code LEDJ280 570mm 264mm www.prolight.co.uk Spectra Flood 24T9 User Manual...
Technical specifications 01 - Bracket 05 - LED display 09 - Power in socket In the box: 1 x fixture, 02 - Bracket tightening knobs 06 - Function buttons 10 - Power out socket 1 x power cable & 03 - Carry handles 07 - DMX input socket 1 x user manual 04 - Earth point 08 - DMX output socket www.prolight.co.uk Spectra Flood 24T9 User Manual...
Operating instructions DMX channel mode: Operating in a DMX control mode environment gives the user the greatest flexibility when it comes to customising or creating a show. In this mode you will be able to control each individual trait of the fixture and each fixture independently. d001 To access the DMX channel mode, press the “MODE” button on the rear of the unit to show on the LED display. Now use the “UP” and “DOWN” buttons to set the desired DMX address. Now press the “ENTER” button to choose one of the 1, 3, 4 or 6 DMX channel modes, press the “ENTER” button to confirm the setting. To exit out of any of the above options, press the “MODE” button. 1 channel mode: 3 channel mode: Channel Value Function Channel Value Function No function 000-255 Red (0-100%) 001-022 Red 000-255 Green (0-100%) 023-045 Green 000-255 Blue (0-100%) 046-068 Blue 4 channel mode: 069-091 Cyan 092-114 Yellow Channel Value...
Page 6
Operating instructions 6 channel mode: Channel Value Function 000-255 Master dimmer (0-100%) 000-255 Red (0-100%) when channel 6 is 000 000-008 Red 009-017 Orange 018-026 Yellow 027-035 Spring Yellow 036-044 Light Yellow 045-053 Lime 054-062 Light Green 063-071 Green 072-080 Pastel Green 081-089 Light Cyan 090-098 Cyan 099-107 Light Blue 108-116 Medium Blue 117-125 Blue Static colours can be used 126-134 Violet when channel 6 is 001-025...
Page 7
6 channel mode continued: 000-255 Green (0-100%) 000-255 Blue (0-100%) 000-009 No function 010-255 Strobe (slow-fast) No function 001-025 Program 1 - Static colour (see channel 2) 026-051 Program 2 - 7 colour fade 052-077 Program 3 - 3 colour fade 078-103 Program 4 - 7 colour change 104-129 Program 5 - 3 colour change 130-155 Program 6 - Dynamic colour fade 1 156-181 Program 7 - Dynamic colour fade 2 182-207 Program 8 - Red continous fade 208-233 Program 9 - Green continous fade 234-255 Program 10 - Blue continous fade www.prolight.co.uk Spectra Flood 24T9 User Manual...
Operating instructions Built-in program mode: Pr. 0 1 To access the built-in program mode press “MODE” until the display shows on the LED display. Press “ENTER” to confirm the setting. Use the “UP” and “DOWN” buttons to select a program from Pr. 0 1 Pr. 1 0 . Press the “ENTER” button to confirm the setting. To change the speed of the selected program press the “ENTER” button and then use the “UP” and SP00 SP99 “DOWN” buttons to select any value from . Press the “ENTER” button to confirm the F500 F599 setting, then use the “UP” and “DOWN” buttons to select and value from for the strobe feature. Press the “ENTER” button to confirm the setting. Pr. 0 1 Pr. 0 1 In you are able to set a specific static colour. When in press the “ENTER”...
XLR terminals located on all DMX fixtures (most controllers only have a data “out” terminal). DMX linking: DMX is a language allowing all makes and models of different manufactures to be linked together and operate from a single controller, as long as all fixtures and the controller are DMX compliant. To ensure proper DMX data transmission, when using several DMX fixtures try to use the shortest cable path possible. The order in which fixtures are connected in a DMX line does not influence the DMX addressing. For example; a fixture assigned to a DMX address of 1 may be placed anywhere in a DMX line, at the beginning, at the end, or anywhere in the middle. When a fixture is assigned a DMX address of 1, the DMX controller knows to send DATA assigned to address 1 to that unit, no matter where it is located in the DMX chain. DATA cable (DMX cable) requirements (for DMX operation): This fixture can be controlled via DMX-512 protocol. The DMX address is set on the back of the unit. Further DMX cables can be purchased from all good sound and lighting suppliers or Pro Light Concepts dealers. Please quote: LEDJ 1m Interior - LEDJ 1m Exterior LEDJ 2m Exterior LEDJ 5m Exterior LEDJ 10m Exterior Exterior DMX cable DMX cable DMX cable DMX cable DMX cable Order code: LEDJ91 Order code: LEDJ141 Order code: LEDJ142 Order code: LEDJ143 Order code: LEDJ144 Also remember LEDJ 1m Exterior...
DMX setup Notice: Be sure to follow the diagrams below when making your own cables. Do not connect the cables shield conductor to the ground lug or allow the shield conductor to come in contact with the XLRs outer casing. Grounding the shield could cause a short circuit and erratic behaviour. Special note: Line termination: When longer runs of cable are used, Termination reduces signal transmission you may need to use a terminator on problems and interferance. it is always advisable to connect a DMX terminal, the last unit to avoid erratic behaviour. (resistance 120 Ohm 1/4 W) between pin 2 Using a cable terminator will decrease (DMX-) and pin 3 (DMX+) of the last fixture. the possibilities of erratic behaviour. (3-pin - Order ref: CABL9O, 5-pin - Order ref: CABL89) 5-pin XLR DMX connectors: Some manufactures use 5-pin XLR connectors for data transmission in place of 3-pin. 5-pin XLR fixtures may be implemented in a 3-pin XLR DMX line. When inserting standard 5-pin XLR connectors in to a 3-pin line a cable adaptor must be used. The diagram below details the correct cable conversion.
WEEE notice Correct Disposal of this Product (Waste Electrical & Electronic Equipment) (Applicable in the European Union and other European countries with separate collection systems) This marking shown on the product or its literature, indicates that it should not be disposed of with other household wastes at the end of its working life. To prevent possible harm to the environment or human health from uncontrolled waste disposal, please separate this from other types of wastes and recycle it responsibly to promote the sustainable reuse of material resources. Household users should contact either the retailer where they purchased this product, or their local government office, for details of where and how they can take this item for environmentally safe recycling. Business users should contact their supplier and check the terms and conditions of the purchase contract. This product should not be mixed with other commercial wastes for disposal. www.prolight.co.uk Spectra Flood 24T9 User Manual...
Page 12
www.prolight.co.uk Spectra Flood 24T9 User Manual...
