BERWICK FIREPLACE INSERT
Model: I100B-1
PLEASE KEEP THESE INSTRUCTIONS FOR
FUTURE REFERENCE
WARNING:
Improper installation, adjustment, alteration, service or maintenance can
cause injury or property damage. Refer to this manual. For assistance
or additional information consult an authorised installer, service agency
or the distributor.
January-06-2014
918-731c
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Regency Fireplace Products I100B-1
Summary of Contents for Regency Fireplace Products I100B-1
- Page 1 Owners & Installation BERWICK FIREPLACE INSERT Model: I100B-1 PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE WARNING: Improper installation, adjustment, alteration, service or maintenance can cause injury or property damage. Refer to this manual. For assistance or additional information consult an authorised installer, service agency or the distributor.
- Page 2 Thank-you for purchasing a REGENCY FIREPLACE PRODUCT. The pride of workmanship that goes into each of our products will give you years of trouble-free enjoyment. Should you have any questions about your product that are not covered in this manual, please contact the REGENCY DEALER in your area.
-
Page 3: Table Of Contents
TABLE OF CONTENTS Data Badge................4 OPERATING INSTRUCTIONS Unit Dimensions ..............5 Operating Instructions ............12 Air Slide Control..............12 INSTALLATION First Fire ................12 Before Installing Your Insert...........6 Residential Installation............6 MAINTENANCE Safety Guidelines and Warnings ...........7 Creosote ................13 Chimney Specifi cations ............7 - Ways to Prevent & Keep Units Free of Creosote ..13 Wood Insert Specifi... -
Page 4: Data Badge
SAFETY LABEL This is a copy of the label that accompanies each NOTE: Regency units are constantly being I100 -1 Fireplace Insert. We have printed a copy of improved. Check the label on the unit and if the contents here for your review. there is a difference, the label on the unit is the correct one. -
Page 5: Unit Dimensions
UNIT DIMENSIONS Regency Berwick Fireplace Insert... -
Page 6: Installation
INSTALLATION Regency Inserts are constructed with the high- 5) If your existing fi replace damper control CAUTION: MIXING OF APPLIANCE OR est quality materials and assembled under strict will become inaccessible once you have FLUE-SYSTEM COMPONENTS FROM quality control procedures that ensure years of installed your Regency Insert, you should DIFFERENT SOURCES OR MODIFYING trouble free and reliable performance. -
Page 7: Safety Guidelines And Warnings
INSTALLATION SAFETY GUIDELINES CHIMNEY AND WARNINGS SPECIFICATIONS 1) Never use petrol, petrol type lantern fuels, Before installing, check and clean your chimney kerosene, charcoal lighter fuel, or similar system thoroughly. If in doubt about its condi- liquids to start or ‘freshen up’ a fi re in your tion, seek professional advice. -
Page 8: Zero Clearance Dimensions
INSTALLATION ZERO CLEARANCE DIMENSIONS ZERO CLEARANCE BOX DIMENSIONS Regency Berwick Fireplace Insert... -
Page 9: Fireplace Clearances
INSTALLATION FIREPLACE CLEARANCES Regency Berwick Fireplace Insert... -
Page 10: Installation Into Amasonry Fireplace
INSTALLATION INSTALLATION INTO A INSTALLATION INTO A 6) Once the above items have been checked, slide your insert into position after fi rst po- MASONRY FIREPLACE FACTORY BUILT sitioning the fl ue liner and offset if required. (Re-install raincap at completion of installa- FIREPLACE tion). -
Page 11: Faceplate & Fan Installation
INSTALLATION FACEPLATE & FAN INSTALLATION 5) Install the draft plate cover by sliding the tabs into the tab brackets 1) Remove the door from the unit by lifting it up off the hinges. on the inside top of the fi rebox, ensure the damper control rod fi ts 2) Position the faceplate up against the unit by sliding the left side of thru the opening in the draft plate cover. -
Page 12: Operating Instructions
OPERATING INSTRUCTIONS AIR SLIDE CONTROL FIRST FIRE OPERATING INSTRUCTIONS Both the primary and air wash drafts are control- When your installation is completed and in- led by the control rod located on the right side spected you are ready for your fi rst fi re. With your unit now correctly installed and safety of the unit (when facing the unit). -
Page 13: Maintenance
MAINTENANCE 10) For those units installed at higher elevations CREOSOTE MAINTENANCE or into sub-standard masonry fi replaces, drafting problems may occur. Consult an When wood is burned slowly, it produces It is very important to carefully maintain your experienced dealer or mason on methods tar and other organic vapours, which when fi... -
Page 14: Parts List
PARTS LIST STOVE ASSEMBLY Part # Description 8010503 Door Assembly (without handle) 8010114 Door Handle Set 1194003 Back Heat Shield 1194007 Top Heat Shield 8010501 Air Slide I100-910 Faceplate & Fan 8010108 Firebrick Set (16 pcs) 1193003 Back Fan Guide Defl ector 8010106 Glass Neoceram W/Gasket 1141704... -
Page 15: Warranty
Regency Fireplace Products and evaluated for manufacturer defect. The authorised selling dealer is responsible for all in-fi eld service work carried out on your Regency product. Regency Fireplace Products will not be liable for results or costs of workmanship from unauthorised service persons or dealers. - Page 16 ® Register your Regency warranty online www.regency-fi re.com.au Reasons to register your product online today! • View and modify a list of all your registered products. • Request automatic email notifi cation of new product updates. • Stay informed about the current promotions, events, and special offers on related products.
