I2453M Wood
Fireplace
Insert
Owners & Installation Manual
www.regency-fire.com
MODEL:
I2453M
Tested & listed by:
Installer: Please complete the details on the back cover
and leave this manual with the homeowner.
Homeowner: Please keep these instructions for future reference.
0219WN026S
FPI FIREPLACE PRODUCTS INTERNATIONAL LTD. 6988 Venture St., Delta, BC Canada, V4G 1H4
920-388
02.15.22
Advertisement
Table of Contents
Related Manuals for Regency Fireplace Products Classic I2453M
Summary of Contents for Regency Fireplace Products Classic I2453M
- Page 1 Classic™ I2453M Wood Fireplace Insert Owners & Installation Manual www.regency-fire.com MODEL: I2453M Tested & listed by: Installer: Please complete the details on the back cover and leave this manual with the homeowner. Homeowner: Please keep these instructions for future reference. 0219WN026S FPI FIREPLACE PRODUCTS INTERNATIONAL LTD.
- Page 2 Thank you for purchasing a REGENCY FIREPLACE PRODUCT. The pride of workmanship that goes into each of our products will give you years of trouble-free enjoyment. Should you have any questions about your product that are not covered in this manual, please contact the REGENCY DEALER in your area. “This wood heater has a manufacturer set minimum low burn rate that must not be altered.
-
Page 3: Table Of Contents
table of contents safety label operating instructions Safety Label For I2453M ..........4 Operating Instructions ..........19 Draft Control ..............19 First Fire ..............19 Fan Operation ..............20 unit dimensions Ash Disposal ..............20 Safety Guidelines and Warnings .........20 Unit Dimensions ............5 maintenance installation Maintenance ..............21 Creosote ..............21 Masonry and Factory Built Fireplace Clearances ..6 Door Gasket ..............21... -
Page 4: Safety Label For I2453M
safety decal Safety Label for I2453M This is a copy of the label that accompanies your Regency Insert. We have printed a copy of the contents here for your review. NOTE: Regency units are constantly being improved. Check the label on the unit and if there is a difference, the label on the unit is the correct one. -
Page 5: Unit Dimensions
dimensions Unit Dimensions 4 " 591mm 8 " 97mm 35" 891mm 8 " 792mm 8 " 205mm 8 " 137mm 17" 433mm 8 " 141mm *From back of faceplate (not shown) to fuel door opening *From back of faceplate (not shown) to fuel door opening 7'' (178mm) 7"... -
Page 6: Masonry And Factory Built Fireplace Clearances
installation Masonry And Factory Built Fireplace Clearances The minimum required clearances to combustible materials when installed into a masonry or factory built fireplace are listed below. Unit Adjacent Mantle ** Side Minimum Minimum To Top of Unit Side Wall (to Top of Facing Facing Hearth... -
Page 7: Installation Into A Masonry Fireplace
installation Installation into a Masonry Chimney Specifications Draft is the force which moves air from the appliance up through the chimney. The amount of draft in your Fireplace chimney depends on the length of the chimney, local Before installing, check and clean your chimney geography, nearby obstructions and other factors. -
Page 8: Installation Into A Masonry Fireplace
installation 1. When installed in a factory built fireplace, a Installation Into a Factory WARNING full stainless steel rigid or flexible flue liner is Built Fireplace mandatory, for both safety and performance Fire Risk. purposes. When a flue or liner is in use, the When lining air-cooled factory-built Regency inserts are constructed with the highest insert is able to breathe better by allowing a... -
Page 9: Installing Your Insert
installation Installing Your Insert Your insert is very heavy and will require two or three people to move it into position. The insert can be made a little lighter by removing the cast iron door by opening it and lifting it off its hinges. Be sure to protect your hearth extension with a heavy blanket or carpet scrap during the installation. -
Page 10: Stainless Steel Smoke Deflector Installation
installation Stainless Steel Smoke Deflector Installation The stainless smoke deflector is located in the upper front area of the firebox. The deflector is held in place with 2 bolts Prior to the first fire, ensure deflector is seated properly and secured with 2 hand tightened bolts. Smoke deflector installed with 2 bolts. -
Page 11: Faceplate And Trim Installation
WOOD INSERT installation I2500M Wood Insert Faceplate and Trim Installation Faceplate & Trim Assembly Your Faceplate kit contains: Using the top panel (item B - see diagram 1) as a gauge, check that the side panels are within 1 Set Faceplate panel (top, left & right) approximately 1/4" of the overall width. If the 1 Set Trim (top, left, right) difference is greater than this, use the supplied 2 pcs. insulation... -
Page 12: Flue Collar Removal And Installation
installation Flue Collar Removal and Installation List of Tools required: 7. Take a ½” ratchet and remove the two bolts at back inside of the firebox. These - Pull rod (supplied with unit) bolts are used to secure the flue collar. Keep these and washers for re-install. - 1/2"... - Page 13 installation 12. Slide the unit back until the flue adaptor is slightly engaged. At this point it is recommended to level the unit. This will keep the adaptor from binding. 13. Insert the provided pull rod through the hole in the top center of the unit.
-
Page 14: Fan Installation
installation Fan Installation Installer: Please record unit serial number here before installing blower. Serial No.______________________________ Your fan should only be installed once the unit is 3. Ensure that the power cord is not in CAUTION: Label all wires prior in place in order to prevent any damage to the contact with any hot stove surfaces. -
Page 15: Floor Protection
HeatWave adapter installation Kit. 1. Remove knockout on the top side of installation Either left or right side. HeatWave Adaptor Installation Floor Protection HeatWave adapter installation Kit. Important: Push both baffles so they are tight against the side walls. Please check to ensure that your floor protection 1. -
Page 16: Wood Door & Handle Assembly
installation WOOD STOVES & INSERTS Wood Door & Handle Assembly WOOD DOOR & HANDLE ASSEMBLY Place the door onto the hinges and then place the door handle through the opening on the door, as shown in In preparation of installing the door handle, the nuts, Diagram 2. -
Page 17: Brick Installation
installation Brick Installation Firebrick is included to extend the life of your stove and radiate heat more evenly. Check to see that all firebricks are in their correct positions and have not become misaligned during shipping. Install all firebricks (if bricks were removed at install) per the diagram below and place in their correct positions. Do not use a grate. -
Page 18: Seasoned Wood
installation Seasoned Wood Whether you burn wood in a fireplace, stove or insert, good quality firewood is the key to convenience, efficiency and safety. Wet wood and pieces that are not the right size and shape for your wood burner can be frustrating, burn inefficiently and deposit creosote that can fuel a dangerous chimney fire. -
Page 19: Operating Instructions
operating instructions Operating First Fire 9. Before opening your door to reload, open the by-pass damper fully for approximately 10 to 15 Instructions seconds until the fire has been re-established. When your installation is completed and inspected This will minimize any smoking (spilling) back you are ready for your first fire. -
Page 20: Fan Operation
operating instructions Safety Guidelines Fan Operation 16. Do not store any fuel closer than 2 feet from and Warnings your unit. Do not place wood, paper, furniture, Automatic drapes or other combustibles near the appliance. To operate the fan - turn on the rheostat. CAUTION: Do not use chemicals AS fluids to 17. -
Page 21: Maintenance
operating instructions Maintenance 5. The chimney and chimney connector should be Latch Adjustment inspected at least once every two months during the heating season to determine is a creosote It is very important to carefully maintain your fire- The door latch may require adjustment as the door buildup has occurred. -
Page 22: Do Not Burn
maintenance DO NOT BURN: CAUTION: DO NOT BURN GARBAGE • Treated wood OR FLAMMABLE LIQUIDS SUCH AS • Coal GASOLINE, NAPTHA OR ENGINE • Garbage OIL. SOME FUELS COULD GENER- • Cardboard ATE CARBON MONOXIDE AND ARE • Solvents VERY DANGEROUS. •... -
Page 23: Vertical Stainless Deflector Replacement
maintenance Vertical Stainless Deflector Replacement 7/16'' Nuts 7/16'' Bolts Slide right + down to remove. Reverse to replace. Vertical Deflector Remove 2 front air tubes 1. Remove 2 front secondary air tubes / vermiculite baffles as per page 15. 2. Loosen the two 7/16'' bolts + nuts to remove / replace vertical deflector. 3. -
Page 24: Annual Maintenance
maintenance Annual Maintenance Completely clean out entire unit Annually Inspect air tube and bricks Replace any damaged parts. Adjust door catch assembly If unable to obtain a tight seal on the door - replace door gasket seal. Readjust door catch after new gasket installed. Inspect condition and seal of: Glass Gasket Door Gasket... -
Page 25: Parts List
parts list Main Assembly & Options - I2453M Part # Description Part # Description Part # Description 850-251 Door Assy - Large Black 23) 142-920 Fan Assembly 42) 163-931 Convection Grill - Nickel (Opt) 850-253 Door Assy - Large Nickel Accent 24) 910-155/P Fan Motor 240 Volts 163-930 Convection Grill - Blk... -
Page 26: Faceplates - I2453M
parts list Faceplates - I2453M Part # Description 140-911 Faceplate & Trim Set - Regular 180-570 Black Trim Regular (set of 3) 285) * Trim Right Regular 286) * Trim Top Regular 287) * Trim Left Regular 288) * Faceplate Side Regular 289) * Faceplate Top Regular 140-913... -
Page 27: Brick Panels - I2453M
parts list Brick Panels - I2453M Part # Description 180-960 Firebrick - Complete Set 70) 902-111 Brick Regular Full Size: 1-1/4" x 4-1/2" x 9" (32mm x 114mm x 229mm) 75) * Brick Partial: 1-1/4 x 4-1/2" x 2" (32mm x 114mm x 51mm) 76) * Brick Partial: 1-1/4"... -
Page 28: Warranty
warranty Limited Lifetime Warranty FPI Fireplace Products International Ltd. (for Canadian customers) and Fireplace Products U.S., Inc. (for U.S. customers) (collectively referred to herein as “FPI”) extends this Limited Lifetime Warranty to the original purchaser of this appliance provided the product remains in the original place of installation. The items covered by this limited warranty and the period of such coverage is set forth in the table below. - Page 29 warranty All warranty claims must be submitted by the dealer servicing the claim, including a copy of the Bill of Sale (proof of purchase by you). All claims must be complete and provide full details as requested by FPI to receive consideration for evaluation. Incomplete claims may be rejected.
- Page 30 warranty Limitations of Liability: The original purchaser’s exclusive remedy under this warranty, and FPI’s sole obligation under this warranty, express or implied, in contract or in tort, shall be limited to replacement, repair, or refund, as outlined above. IN NO EVENT WILL FPI BE LIABLE UNDER THIS WARRANTY FOR ANY INCIDENTAL OR CONSEQUENTIAL COMMERCIAL DAMAGES OR DAMAGES TO PROPERTY.
- Page 31 warranty Product Registration and Customer Support: Thank you for choosing a Regency Fireplace. Regency strives to be a world leader in the design, manufacture, and marketing of hearth products. To provide the best support for your product, we request that you complete a product registration form found on our Web Site under Customer Care within ninety (90) days of purchase.
- Page 32 32 | Regency I2453M...
- Page 33 notes Regency I2453M...
- Page 34 notes 34 | Regency I2453M...
- Page 36 Installer: Please complete the following information Dealer Name & Address: ______________________________________________ ___________________________________________________________________ Installer: ___________________________________________________________ Phone #: ___________________________________________________________ Date Installed: ______________________________________________________ Serial #: ____________________________________________________________ Printed in Canada Regency and Classic are trademarks of FPI Fireplace Products International Ltd. © Copyright 2022, FPI Fireplace Products International Ltd. All rights reserved.
