Owners &
Installation
LISTINGS AND CODE APPROVALS
These gas appliances have been tested in
accordance with AS4553, NZS 5262 and
have been certifi ed by the Australian Gas
Association for installation and operation as
described in these Installation and Operating
Instructions.
Your unit should be serviced annually by
an authorised service person.
IG34 GAS INBUILT
PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE
WARNING:
Improper installation, adjustment, altera-
tion, service or maintenance can cause
injury or property damage. Refer to this
manual. For assistance or additional in-
formation consult an authorised installer,
service agency or the gas supplier.
FOR YOUR SAFETY
Do not store or use gasoline or other fl am-
mable vapours and liquids in the vicinity of
this or any other appliance.
Installation and service must be performed
by an authorised installer, service agency or
the gas supplier.
918-793c
Models:
REFERENCE
FOR YOUR SAFETY
What to do if you smell gas:
Do not try to light any appli-
ance
Do not touch any electri-
cal switch: do not use any
phone in your building.
Immediately call your gas
supplier from a neighbour's
phone. Follow the gas sup-
plier's instructions.
If you cannot reach your
gas supplier, call the fi re
department.
IG34-NG
IG34-LPG
IG34-ULPG
01/02/14
Advertisement
Table of Contents
Related Manuals for Regency Fireplace Products IG34-NG
Summary of Contents for Regency Fireplace Products IG34-NG
- Page 1 Owners & Installation IG34 GAS INBUILT Models: IG34-NG IG34-LPG IG34-ULPG PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE WARNING: FOR YOUR SAFETY Improper installation, adjustment, altera- What to do if you smell gas: tion, service or maintenance can cause Do not try to light any appli- injury or property damage.
-
Page 2: Unit Dimensions
REGENCY GAS INBUILT FIREPLACE TO THE NEW OWNER Congratulations! You are the owner of a state-of-the-art Gas Inbuilt Fireplace by FPI. The Regency Gas Fireplace Series of appliances has been designed to provide you with all the warmth and charm of a fi replace, at the fl ick of a switch. The model IG34 of this series has been approved by Australian Gas Association for both safety and effi... -
Page 3: Table Of Contents
TABLE OF CONTENTS DATA BADGE Final Check..............22 Wiring standard ............22 Operating Instructions ..........23 Copy of Data Badge .............4 Lighting Instructions.............23 Shutdown Instructions ..........23 INSTALLATION First Fire ..............23 Remote Control ............23 Summary of Controls ..........23 Important Message ............5 Fan Operation..............23 For Your Safety ..............5 Copy Of Lighting Instruction Plate .......24 Before You Start ............5 Normal Operating Sounds Of Gas Appliances ....24... -
Page 4: Data Badge
DATA BADGE This is a copy of the label that accompanies each Regency IG34 Gas Check the label on the unit and if there is a difference, the label on the Inbuilt fi replace. We have printed a copy of the contents here for your unit is the correct one. -
Page 5: Installation
INSTALLATION IMPORTANT MESSAGE BEFORE YOU START INSTALLATION CHECKLIST The Regency Gas Inbuilt must be installed in Installation is to be carried out ONLY by an accordance with these instructions. Carefully authorised person. Before installing vent system ensure that the read all the instructions in this manual fi rst. damper plate is open and secure to prevent the 1) The appliance shall be installed in accord- damper plate from falling down and crushing... -
Page 6: Minimum Fireplace Dimensions
INSTALLATION MINIMUM FIREPLACE Mantel Clearances FLUEING DIMENSIONS THE APPLIANCE MUST NOT The minimum fi replace dimensions for the BE CONNECTED TO A Regency gas space heater are shown in the CHIMNEY FLUE SERVING A following diagrams: SEPARATE SOLID FUEL BURNING APPLIANCE AND MUST BE TERMINATED TO THE OUTDOORS. -
Page 7: Flue Liner Installation
INSTALLATION The Air Intake pipe must be attached to the 4) Seal and or check the pilot outlet (# 8) inlet air collar of the termination cap. 5) The pressure check should be carried out with the unit burning and the setting should be within the limits specifi... -
Page 8: Installation In Masonry Or Zero Clearance Chimney
INSTALLATION INSTALLATION IN MASONRY OR ZERO CLEARANCE CHIMNEY 1) Measure and record dimensions to determine total Note: If you are planning to extend the height of the Flex Liner length requirements (see instructions below chimney using Direct Vent GS Pipe, please refer to the for details). -
Page 9: Aeration Settings
INSTALLATION System Data IG34 IG34-NG: For 0 to 610 meters altitude IG34-LPG: For 0 to 610 meters altitude IG34-ULPG: For 0 to 610 meters altitude Burner Inlet Orifi ce Sizes: ULPG Burner Max. Input 31.7 mj 30.6 mj ULPG 26.4 mj Min. -
Page 10: Conversion From Ng To Lpg
INSTALLATION Conversion Kit #486-968 for NG to LPG Model THIS CONVERSION MUST BE DONE BY A QUALIFIED GAS FITTER IF IN DOUBT DO NOT DO THIS CONVERSION !! 12) Replace the yellow "NG" label with onversion Kit 486-968 Contains: the red "ULPG" label. Pull out the pilot hood by hand. - Page 11 INSTALLATION power cord. 18) Turn on gas supply and plug in After carrying out all adjustments, block the setting screws with paint, taking care not to obstruct the breather orifi ce of the pressure. 19) Adjusting the Outlet Pressure Put back the modulator plastic cap. All the adjustments must be carried out in the following order: WARNING: To ensure the correct operation of the modu-...
-
Page 12: Conversion From Ng To Ulpg
INSTALLATION Conversion Kit #486-967 for NG to ULPG THIS CONVERSION MUST BE DONE BY A QUALIFIED GAS FITTER IF IN DOUBT DO NOT DO THIS CONVERSION !! 12) Replace the yellow "NG" label with onversion Kit 486-967 Contains: the red "ULPG" label. Pull out the pilot hood by hand. - Page 13 INSTALLATION power cord. 18) Turn on gas supply and plug in After carrying out all adjustments, block the setting screws with paint, taking care not to obstruct the breather orifi ce 19) Adjusting the Outlet Pressure of the pressure. All the adjustments must be Put back the modulator plastic cap.
-
Page 14: Optional Stainless Steel Inner Panel Install
INSTALLATION OPTIONAL STAINLESS STEEL INNER PANEL INSTALL Before you start: Stainless panels must be inspected for scratches and dimples prior to installation. All claims to be recorded at this time. Claims for damage after installation will not receive consideration. To protect the fi nish during installation and handling - cotton gloves MUST be worn at all times while handling the panels (even when removing protective coating). -
Page 15: Log Set Installation
INSTALLATION LOG SET INSTALLATION Read the instructions below carefully and refer to the diagrams. If logs are broken do not use the unit until they are replaced. Broken logs can interfere with the pilot operation. The gas log kit contains the following: a) 02-43 Rear Log b) 02-45... - Page 16 INSTALLATION 5) Place the Middle Left Log C)02-56 on the two pins as 7) Place the notch in Center Log E)02-47 over Log B)02- shown. 45 and across the cutout on Log A)02-43. E)02-47 A)02-43 C)02-56 B)02-45 Notch Cutout Logs A)02-43, C)02-56, and B)02-45 in position Logs D)02-46 and E)02-47 in position.
- Page 17 INSTALLATION Front edge of 10) Place the embers and Rockwool on the exposed front rear burner burner tray. A)02-43 F)02-48 Side View Bracket The bottom right edge of Log F)02-48 must sit snugly against Separate platinum embers and place on and around the bracket and the front edge of the rear burner.
-
Page 18: Glass Door Installation
INSTALLATION GLASS DOOR INSTALLATION STANDARD FLUSH DOOR The standard fl ush door comes with a black frame. To install the frame and glass door, simply hook the top door fl ange onto the top of the unit and swing the door towards the unit, diagram 1. Be careful that the glass gasket does not roll up;... -
Page 19: Faceplate & Optional Plinth Trim Assembly
INSTALLATION FACEPLATE & OPTIONAL PLINTH TRIM ASSEMBLY Lay the faceplate panels fl at, face down on something soft so they don't scratch. Take the top faceplate and align the holes in it with the holes in the side panels. Secure with provided nuts and bolts. Install faceplate on unit - see next page. -
Page 20: Faceplate And Door Frame Installation
INSTALLATION THERMODISC & FACEPLATE/DOORFRAME INSTALLATION 1) Position faceplate near the unit and plug the jack from the wiring 3) Secure wiring along the vertical right side of the faceplate (facing harness from the unit into the back of the touch pad - as shown the back of the faceplate) with supplied grey adhesive clips. -
Page 21: Thermodisc Installation
INSTALLATION 9) Install the door frame by hooking the top fl ange over the ) Fold down the 2 hinges on the bottom frame to a fl at top of the glass door. position. The bottom frame is installed with a friction fi t - the opening in the corner of each hinge slides over the metal lip located on the fl... -
Page 22: Final Check
INSTALLATION FINAL CHECK Before leaving this unit with the customer, the installer must ensure that the appliance is fi ring correctly. This includes: 1) Clocking the appliance to ensure the correct fi ring rate (rate noted on label) at 15 minutes. 2) If required, adjusting the primary air to ensure that the fl... -
Page 23: Operating Instructions
OPERATING INSTRUCTIONS OPERATING SUMMARY OF FIRST FIRE INSTRUCTIONS CONTROLS The FIRST FIRE in your heater is part of the paint curing process. To ensure that the paint Before operating this appliance, proceed through On/Off Button is properly cured, it is recommended that you the following check list. -
Page 24: Copy Of Lighting Instruction Plate
OPERATING INSTRUCTIONS COPY OF LIGHTING INSTRUCTION PLATE NORMAL OPERATING SOUNDS OF GAS APPLIANCES It is possible that you will hear some sounds from your gas appliance. This is perfectly normal due to the fact that there are various gauges and types of steel used within your appliance. Listed below are some examples. -
Page 25: Maintenance
MAINTENANCE WARNING: CHILDREN AND MAINTENANCE LOG REPLACEMENT ADULTS SHOULD BE ALERTED INSTRUCTIONS TO THE HAZARDS OF HIGH The unit should never be used with broken logs. SURFACE TEMPERATURE AND Unplug the power cord and allow the unit to cool Any maintenance required accessing the before opening door to carefully remove the logs. -
Page 26: Fan Maintenance
MAINTENANCE FAN MAINTENANCE To Remove Fan: 1) Turn the unit off and allow it to cool to room temperature, 2) Unplug or disconnect power source to stove. 3) Open the bottom louvre. 4) Remove screws that secure protective screen. 5) Remove door frame and screen 6) Remove the ECS harness from the back clip. -
Page 27: Valve Assembly Replacement
MAINTENANCE VALVE ASSEMBLY REPLACEMENT 1) Unplug or disconnect the power source to the stove and shut off gas supply. 2) open bottom louvre and remove protective screen. 3) Remove the door frame and safety screen. 4) Remove the glass door, logs, and black or stainless inner liner, if installed. 5) Remove the rear log tray, burner and grate. -
Page 28: Parts List
PARTS LIST ELECTRONIC COMPONENTS PARTS LIST 910-936 910-082 910-089 910-088 910-912 910-084 910-527 910-935 910-080 910-906 910-083 910-514 910-521, 910-522, 910-523, 910-525 910-916 FG37 FG38 FG39 PG33 PG36 / HG35 PG121/ IG35 IG34 PG36D PG131 ... -
Page 29: Main Assembly
PARTS LIST MAIN ASSEMBLY Part # Description Part # Description 1) 910-169/P Fan Motor (240 V)** 10) 910-936 Pilot Assy (NG) - 3 fl ame convertible top 2) 910-995 Thermodisc** 910-947 Pilot Assy (LPG) - 3 fl ame convertible top 11) 904-240 Orifi... -
Page 30: Faceplate Assembly
PARTS LIST FACEPLATE ASSEMBLY Part # Description 366-942 Plinth Kit 336-914 Faceplate & Trim Complete - Regular 336-532 Flush Screen Door** *Not available as a replacement part. Regency IG34 Gas Inbuilt Fireplace... -
Page 31: Warranty
Regency shall in no event be liable for any special, indirect consequential damages of any nature whatsoever which are in excess of the original purchase price of the product. Any alteration to the unit which causes sooting or carboning that results in damage to the exterior facia is not the responsibility of Regency Fireplace Products. - Page 32 ® Register your Regency warranty online www.regency-fi re.com.au Reasons to register your product online today! • View and modify a list of all your registered products. • Request automatic email notifi cation of new product updates. • Stay informed about the current promotions, events, and special offers on related products.
