I1200S Wood Insert Owners & Installation Manual www.regency-fire.com Tested by: Installer: Please complete the details on the back cover and leave this manual with the homeowner. Homeowner: Please keep these instructions for future reference. FPI FIREPLACE PRODUCTS INTERNATIONAL LTD. 6988 Venture St., Delta, BC Canada, V4G 1H4...
Page 2
Thank-you for purchasing a REGENCY FIREPLACE PRODUCT. The pride of workmanship that goes into each of our products will give you years of trouble-free enjoyment. Should you have any questions about your product that are not covered in this manual, please contact the REGENCY DEALER in your area.
TABLE OF CONTENTS SAFETY LABEL OPERATING INSTRUCTIONS Safety Label..............4 First Fire ..............18 Fan Operation..............19 Ash Disposal..............19 UNIT DIMENSIONS Some Safety Guidelines ..........19 MAINTENANCE With standard flue adaptor ..........5 With offset flue adaptor ..........6 Creosote ..............19 Maintenance Of Gold-plated Doors ......20 INSTALLATION Door Gasket ..............20 Door Latch Adjustment ..........20...
SAFETY LABEL This is a copy of the label that accompanies each I1200S Wood Insert. We have printed a copy of the contents here for your review. NOTE: Regency units are constantly being improved. Check the label on the unit and if there is a difference, the label on the unit is the correct one.
DIMENSIONS WITH STANDARD FLUE ADAPTOR 6" (152mm) Diameter STANDARD FLUE ADAPTOR (171-932) Regency Inserts are designed to use either a 5.5" (140mm) or 6" (152mm) flue. I1200 Regency Wood Insert...
INSTALLATION CHIMNEY 6) Alteration of the fireplace in any manner is not Regency Inserts are constructed with the high- est quality materials and assembled under strict permitted with the following exceptions; SPECIFICATIONS quality control procedures that ensure years of trouble free and reliable performance. a.
Hearth Hearth Side Unit (to Side) (to Top of Unit) (to Side of Unit) Extension* Thickness Extension* I1200S 15" (381mm) 20" (508mm) 14" (356mm) 7-3/8"(187mm) 16" (406mm) 1.5" (38mm) 8" (203mm) 18-3/4"(476mm) Side and Top facing is a maximum of 1.5" thick.
INSTALLATION INSTALLING 3) Install the unit by first setting the rear of 7) Ensure that the unit is still level. the unit into the fireplace. See diagram YOUR INSERT 3. Ensure that the unit is centered in the 8) To complete the installation and to ensure a existing fireplace and lined up with the flue secure fit and connection of the flue adaptor adaptor.
INSTALLATION INSTALLATION INTO A 4) If the floor of your fireplace is below the In Canada this fireplace insert must be level of the fireplace opening, adjust the installed with a continuous chimney liner MASONRY FIREPLACE insert's levelling bolts to accommodate the of 5.5"...
INSTALLATION STAINLESS STEEL SMOKE DEFLECTOR ADJUSTMENT / REPLACEMENT The stainless smoke deflector is located in the upper front area of the firebox. The deflector is held in place with 2 bolts Prior to the first fire, ensure deflector is seated properly and secured with 2 hand tightened bolts. Ensure defector is seated so bolts are situated at the top of the keyhole before tightening.
I1200 INSTALLATION FACEPLATE, TRIM, FAN & OPTIONAL FACEPLATE, TRIM & OPTIONAL BOTTOM FACEPLATE & FAN SUPPORT INSTALLATION BOTTOM FACEPLATE & FAN SUPPORT INSTALLATION Regular Faceplate Dimensions: Oversize Faceplate Dimensions: I1200 Regency Wood Insert 918-676c 01/28/08...
Page 13
I1200 INSTALLATION Regular/Oversize Faceplate Installation: Optional Regular/Oversize Bottom Faceplate Installation: 1) Thread the black 1/4" x 3/4" long hex bolts into the faceplate mount- ing bracket as shown in Diagram 1, leaving them approximately 1/4" 4) Position the assembled faceplate side and top to the insert. Ensure out.
Page 14
I1200 INSTALLATION Regular/Oversize Faceplate Trim Installation: 11) Mount the completed faceplate / trim assembly to the insert. Ensure to align the side faceplate slots with the hex bolts in the mounting (Black Trim included with Regular/Oversize Faceplate brackets and tighten to secure in place. or Optional Brass Trim) 8) Assemble the left and right side trim to the top trim using the trim clips Fan Installation:...
Page 15
I1200 INSTALLATION 14) Cut the bottom edge of the fan support and bottom faceplate (using 18) Secure the bottom faceplate to the 3-sided faceplate using the 4 a metal cutting blade) to the length measured in step 13. supplied bolts/washers. 15) Remove the fan assembly from the ash lip of the insert and position 19) Discard both side trims that were included with the regular/oversize the fan support to the bottom of the fan assembly.
INSTALLATION Installer: Please record unit serial number here before installing blower. Serial No.______________________________ FAN / BLOWER with any hot stove surfaces. WARNING: Electrical Grounding Instructions Do not turn fan ON until your insert has Your fan should only be installed once the unit This appliance is equipped with a reached operating temperature or at least is in place in order to prevent any damage to...
INSTALLATION FIREBRICK ASSEMBLY BRICK FLUE BAFFLE & 4) Important: push both baffle bricks so they are tight against the side walls and SECONDARY AIR TUBE to the back. Firebrick is included to extend the life of your INSTALLATION insert and radiate heat more evenly. Check to see that all firebricks are in their correct posi- tions and have not become misaligned during The flue baffle system located in the upper area...
INSTALLATION SCREEN DOOR FIRST FIRE 9) During the first few hours it may be more difficult to start the fire. As you dry out your fire brick and your masonry flue (if Hook screen to the inside on the right side When your installation is completed and in- applicable), your draft will increase.
OPERATING INSTRUCTIONS INSTALLATION GUIDELINES The fan is to be operated only with the draft control rod pulled out at least 1/2" from the 16) Do not burn salt drift wood as it will corrode fully closed position. The fan is not to be your unit and void the warranty.
MAINTENANCE ADJUSTMENT been dried at least one year. Allow the stove to cool before removing or replac- ing glass. Remove the door from the insert and 4) A small hot fire is preferable to a large remove the glass retainer. Use caution when The door latch may require adjustment as the smouldering one that can deposit creosote removing broken glass to prevent injury.
PARTS LIST MAIN ASSEMBLY Part # Description 850-141 Black Door - Complete 850-143 Nickel Accent Door - Complete 846-302 Glass - Replacement 936-243 7/8" Adhesive Tape Gasket 846-920 Glass Retainer Clips/Screws (set of 8) Screws - 1/4-20 x 3/8" 948-170/P Glass Retainer 846-973 Door Handle Assembly 16) 846-570...
PARTS LIST FACEPLATES Part # Description 171-920 Faceplate & Trim Set - Regular - Black 60) * Faceplate Right Side Regular / Oversize 61) * Faceplate Left Side Regular / Oversize 171-922 Faceplate & Trim Set - Oversize - Black 62) * Faceplate Top Regular / Oversize 171-928...
PARTS LIST FIREBRICK Part # Description 170-960 Complete Brick Set 70) * Brick Regular Full Size: 1-1/4" x 4-1/2" x 9" 76) * Brick Partial: 1-1/4" x 2" x 9" 81) * Brick Partial: 1-1/4" x 1-1/4" x 9" 84) * Brick Partial: 1-1/4"...
WARRANTY S2400 I2400 Z2510 FP90 Regency Fireplace Products are designed with reliability and simplicity in mind. In addition, our internal Quality Assurance Team carefully inspects each unit thoroughly before it leaves our door. is pleased to extend this limited lifetime warranty to the FPI Fireplace Products International Ltd.
Page 28
Register your Regency warranty online ® www.regency-fire.com Reasons to register your product online today! • View and modify a list of all your registered products. • Request automatic email notification of new product updates. • Stay informed about the current promotions, events, and special offers on related products.
