Owners &
Installation
LISTINGS AND CODE APPROVALS
These gas appliances have been tested in
accordance with AS4553, NZS 5262 and
have been certifi ed by the Australian Gas
Association for installation and operation as
described in these Installation and Operating
Instructions.
Your unit should be serviced annually by
an authorised service person.
I31-3 Gas Inbuilt
PLEASE KEEP THESE INSTRUCTIONS
FOR FUTURE REFERENCE
WARNING:
Improper installation, adjustment, altera-
tion, service or maintenance can cause
injury or property damage. Refer to this
manual. For assistance or additional in-
formation consult an authorised installer,
service agency or the gas supplier.
FOR YOUR SAFETY
Do not store or use gasoline or other fl am-
mable vapours and liquids in the vicinity of
this or any other appliance.
Installation and service must be performed
by an authorised installer, service agency or
the gas supplier.
918-001d
Model:
I31-NG3
I31-LPG3
FOR YOUR SAFETY
What to do if you smell gas:
Do not try to light any appli-
ance
Do not touch any electrical
switch: do not use any phone
in your building.
Immediately call your gas
supplier from a neighbour's
phone. Follow the gas sup-
plier's instructions.
If you cannot reach your gas
supplier, call the fi re depart-
ment.
09/10/12
Advertisement
Table of Contents
Related Manuals for Regency Fireplace Products I31-NG3
Summary of Contents for Regency Fireplace Products I31-NG3
- Page 1 Owners & Installation I31-3 Gas Inbuilt Model: I31-NG3 I31-LPG3 PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE WARNING: FOR YOUR SAFETY Improper installation, adjustment, altera- What to do if you smell gas: tion, service or maintenance can cause Do not try to light any appli- injury or property damage.
-
Page 2: Unit Dimensions
REGENCY GAS FIREPLACE INBUILT FIREPLACE TO THE NEW OWNER Congratulations! You are the owner of a state-of-the-art Gas Inbuilt Fireplace by Regency Industries. The Regency Gas Fireplace Series of hand crafted appliances has been designed to provide you with all the warmth and charm of a fi replace, at the fl ick of a switch. The model I31-3 of this series has been approved by Australian Gas Association for both safety and effi... -
Page 3: Table Of Contents
TABLE OF CONTENTS REGENCY GAS FIREPLACE INSERT Unit Dimensions ............2 Operating Instructions Safety Label..............4 Operating Instructions ..........16 Lighting Procedure ............ 16 Installation Shutdown Procedure ..........16 First Fire ............... 16 For Your Safety ............5 Automatic Convection Fan Operation......16 Specifi... -
Page 4: Safety Label
DATA BADGE DATA BADGE NOTE: Regency units are con- This is a copy of the label that accompanies stantly being improved. Check the label on the each Regency I31-3 Gas Inbuilt fi replace. We unit and if there is a difference, the label on the have printed a copy of the contents here for unit is the correct one. -
Page 5: Installation
INSTALLATION that control compartments, burners and IMPORTANT: circulating air passageways of the appliance 7) Install the optional brick panels. See page SAVE THESE be kept clean and free from excessive lint from carpeting. INSTRUCTIONS 8) Install the log set. See page 8. 4) See general construction and assembly The Regency Gas Fireplace must be installed instructions. -
Page 6: Minimum Fireplace Dimension
INSTALLATION MINIMUM FIREPLACE GAS CONNECTION DIMENSIONS GAS CONNECTION WARNING: Only persons licensed to work with The minimum fi replace dimensions for the Regency gas space heater are shown in the gas piping may make the necessary following diagrams: gas connections to this appliance. 1) If the appliance is to be installed into an existing chimney system, thoroughly clean the masonry or factory built fi... -
Page 7: Draft Diverter Connection
INSTALLATION DRAFT DIVERTER FLUEING TEST FOR FLUE CONNECTION SPILLAGE THE APPLIANCE MUST NOT BE CONNECT- ED TO A CHIMNEY FLUE SERVING A SEPA- 1) Attach the fl ue to the fl ue collar on the A " spillage" test must be made before the RATE SOLID FUEL BURNING APPLIANCE. -
Page 8: Optional Brick Panel
INSTALLATION The smoke should be drawn into the spill tube. OPTIONAL LOG SET If the smoke is still not drawn into the spill tube, BRICK PANEL INSTALLATION turn the unit off and check for the cause of the lack of draft. If necessary, rectify. 1) Unwrap the brick pattern panels from the Read the instructions below carefully and re- protective wrapping. - Page 9 INSTALLATION A)02-43 F)02-48 A)02-43 D)02-46 A)02-43 Side View C)02-56 Front edge of Bracket rear burner Pins on Rear Log Support The bottom right edge of Log F)02-48 must sit snugly against the bracket and the front edge Cutout of the rear burner. 7) Place the notch in Center Log E)02-47 over 4) Place Front Right Log B)02-45 on the two Log B)02-45 and across the cutout on Log...
-
Page 10: Faceplate & Trim
INSTALLATION 4) Place the trim on the assembled faceplate FACEPLATE & TRIM panels, aligning the wire connections from INSTALLATION the switches with the notch on the left side panel. 1) Lay the faceplate panels fl at, face down on 5) Hookup the 3 Fan Switch wires to the fan something soft so they don't scratch. -
Page 11: Flush Louvres
INSTALLATION 3) Place the bottom of the fl ush glass behind Note: Top and bottom louvres and brackets BAY LOUVRES the bottom glass trim. are different. 1) Install top louvre by sliding the two bracket 4) Secure the glass with the two glass clips at 2) The bottom louvre has a hinge that is at- clips into the brackets located on top of the the top corners of the glass. -
Page 12: Hampton Cast Faceplate Installation
INSTALLATION HAMPTON CAST 5) Connect the ON/OFF switch wires by taking the black and FACEPLATE INSTALLATION red wires with the blue female ends thru the hole provided and connecting them to the NOTE: Do not install Cast Faceplate when unit is installed ON/OFF switch. -
Page 13: Hampton Cast Grill Installation
INSTALLATION 11) Mount the cast faceplate panels onto the insert body, sliding HAMPTON CAST the side fi ller brackets into the space between the glass and the GRILL INSTALLATION fi rebox. Secure using the 4 remaining black screws, 2 per side. Before the grills are installed, a grill stop bracket needs to be put in place. -
Page 14: Barossa Curved Front
INSTALLATION BAROSSA CURVED FRONT INSTALLATION 1) Install bottom louver by matching the holes in louver bracket with 4) Fit plates on back of screen into brackets on top of fi rebox. Press in holes in fi rebox frame and secure using 2 screws on each side. to secure from top. -
Page 15: Optional Remote Control
INSTALLATION OPTIONAL REMOTE cover in the wall. The remote control is now CAUTION ready for operation. Do not connect the millivolt CONTROL wall thermostat wires CAUTION to the 240 V wires. Do not connect the millivolt Use the Optional Remote Control Kit approved remote control wires to Thermostat Wire Table for this unit. -
Page 16: Operating Instructions
OPERATING INSTRUCTIONS OPERATING Note: When the glass is cold and the appli- 4) Wait fi ve minutes to allow gas, that may ance is lit, it may cause condensation have accumulated in the main burner INSTRUCTIONS and fog the glass. This condensation compartment, to escape. -
Page 17: Copy Of Lighting Instruction Plate
OPERATING INSTRUCTIONS MAINTENANCE COPY OF LIGHTING INSTRUCTION PLATE INSTRUCTIONS FOR YOUR SAFETY READ BEFORE LIGHTING 1) Always turn the gas valve to off This appliance must be installed in accordance with local codes, if any; if none, follow the National Fuel Gas Code, ANSI Z223.1/NFPA 54, before cleaning. -
Page 18: Maintenance
MAINTENANCE Incorrect fl ame pattern will have small, prob- DOOR GLASS ably yellow fl ames, not coming into proper CAUTION: ANY SAFETY SCREEN REPLACEMENT contact with the rear burner or thermopile. OR GUARD REMOVED FOR SERV- ICING AN APPLIANCE MUST BE Your Regency stove is supplied with high tem- REPLACED PRIOR TO OPERATING perature, 5 mm Neoceram ceramic glass that... -
Page 19: Glass Gasket
MAINTENANCE GLASS GASKET 7) Remove the Burner Tray by removing the screws on each side of the tray. Push the tray to the left and lift up. If the glass gasket requires replacement use 7/8" fl at glass gasket (Part # 936-243) for the Bay Front and for the Flush Front. -
Page 20: Trouble Shooting
MAINTENANCE TROUBLE SHOOTING REGENCY GAS SPACE HEATER SYMPTOM PROBABLE CAUSE CORRECTIVE ACTION 1) Thin black coating [soot]forms on view- a) Incorrect gas pressure Check and correct gas pressure if sooting ing glass. b) Not enough combustion continues open aeration shutter on burner. Note: To clean glass, remove and wipe with cloth or paper towel 2) A change in fl... -
Page 21: Parts List
PARTS LIST MAIN ASSEMBLY Part # Description Part # Description 22) 402-920 Flush Louvre set - Black (Top & Bottom) 1) 400-011 Fan Opening Cover 402-922 Flush Louvre set - Gold/Black (Top & Bottom) 2) 910-169/P Fan Motor (240 V) 402-924 Flush Louvre set - Steel/Black (Top &... - Page 22 PARTS LIST BURNER ASSEMBLY & LOG SET Part # Description 402-565/P Valve Assembly - NG 402-566/P Valve Assembly - LPG 52) 910-026 RobertShaw Valve - NG 910-027 RobertShaw Valve - LPG 53) 910-190 Piezo Ignitor and nut 54) * Valve Heat Shield 55) 904-702 Gasket - Valve Heat Shield 56) *...
-
Page 23: Faceplate Assembly
PARTS LIST FACEPLATE ASSEMBLY Part # Description Part # Description 910-140 Fan HI/OFF/LOW Switch 144) * Faceplate Trim Right - Oversize 910-246 Burner ON/OFF Switch 145) * Faceplate Trim Top - Oversize 146) * Faceplate Trim Left Assy - Oversize 403-912 Faceplate &... - Page 24 PARTS LIST BAY & FLUSH FRONT ASSEMBLY Part # Description Part # Description Flush Door Bay Door 149) 400-531/P Flush Screen - Packaged (Aust. Only) 400-988 Complete Bay Front c/w Black Trim 102) * Glass Retainer Side (Top & Btm) 402-515/P Complete Flush Front Assembly 103) *...
- Page 25 PARTS LIST HAMPTON CAST FACEPLATE ASSEMBLY Part # Description 403-911 Cast Faceplates (Set) - Black Metallic 403-916 Cast Faceplates (Set) - Black Enamel 187) * Burner On/Off Switch 188) * Fan Speed Control 189) * Knob - Black Cast Surround 201) * Cast Faceplate - Right 202) *...
- Page 26 NOTES ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ Regency I31-3 Gas Fireplace Inbuilt...
-
Page 27: Warranty
Regency, shall in no event be liable for any special, indirect consequential damages of any nature whatsoever which are in excess of the original purchase price of the product. Any alteration to the unit which causes sooting or carbon- ning that results in damage to the exterior facia is not the responsibility of Regency Fireplace Products. General: It is essential that all submitted claims provide all of the necessary information including purchase date, serial #, type of unit and part or parts requested. - Page 28 © Copyright 2009, FPI Fireplace Products International Ltd. All rights reserved. Printed in Canada...
