E c h o l u t i o n 2 | E c h o l u t i o n 2 D e l u x e

KNOBS AND TOUCH SWITCHES

EXPRESSION CONTROL

SHORT PRESS cycles between Repeats, Time, Mix, Speed, and
Depth control.
LONG PRESS turns on ENV map to EXP.
REPEATS
Sets the amount of feedback in the delay
line.
TIME
Sets the delay time within the current delay time
range setting. When the time knob is turned, it
takes over from the tap tempo within the delay
time range as set by the last tap tempo value.
DELAY TIME RANGES
SHORT PRESS cycles between Short, Medium, and Long delay
times.
LONG PRESS turns off the delay line.
SPECIAL FX
SHORT PRESS turns on Pong.
LONG PRESS turns on Halo.

MULTI-TAPS

SHORT PRESS cycles between 1, 3/4, 2/3, 1/12, and PHI.
LONG PRESS creates a Second Tap.
8 |
p i g t r o n i x . c o m
MIX
Sets the audio output level of the delay line.
KNOBS AND TOUCH SWITCHES
PRESET SELECTOR
Allows you to save and load presets.

LFO WAVEFORMS

SHORT PRESS cycles between Triangle, Square, Ramp, and
Random waveforms.
LONG PRESS turns on LFO Sync.

DELAY LINE I/O

SHORT PRESS cycles between Trails, Listen and Normal.
LONG PRESS turns on Dry Kill.
SPECIAL FUNCTIONS
SHORT PRESS turns on Reverse.
LONG PRESS turns on Duck.
FILTERS CONTROL
SHORT PRESS cycles between Low Pass, Tape, Comb, and Sweep
filters.
LONG PRESS turns on Crush.
E c h o l u t i o n 2 | E c h o l u t i o n 2 D e l u x e
DEPTH
Sets the amount of LFO modulation that is fed
to the delay line.
SPEED
Sets the LFO speed.
p i g t r o n i x . c o m
| 9
