E c h o l u t i o n 2 | E c h o l u t i o n 2 D e l u x e
APPLICATION
The ENV RELEASE slider lists increases the release time of the envelope in seconds when moved right.
DUCKING SENSITIVITY and DUCKING RELEASE
DUCK option (see the 'Delay Line i/o' section for more details). The DUCKING SENSITIVITY
slider adjusts the sensitivity of ducking, left being the least sensitive, and right being the most. The
DUCKING RELEASE TIME slider lists increases the release time of the envelope in seconds
when moved right.
The FILTER CUTOFFS adjust the cutoff frequency of each filter. See more in the TOUCH
SWITCHES: FILTERS
section.
MAX PITCH adjusts the pitches of the JUMP function. Select an interval from the drop menu
in order to change the setting. See E2 REMOTE SWITCH
PRESET BLENDING : By utilizing the above mentioned features, the application can automatically
set the advanced settings to blend between 2 two presets. This can be accessed by clicking Edit->Blend
Presets or by clicking command-B on Mac or Ctrl-B on PC.
Note : When using PRESET BLENDING, the TOUCH
from the HEEL setting and do not change when in the TOE setting
DEVICE SETS : A DEVICE SET is a file which holds all of the presets. This file can be uploaded
to the E2 using LOAD DEVICE SET and saved to the computer using SAVE DEVICE
SET. This allows device sets to be shareable and for more than 60 presets to be created. This can be
accessed through the FILE tab in the application. This is also available through right-clicking any of the
presets on the left of the screen and selecting the desired action.
MIDI CHANNEL : This can be set by pressing EDIT-> MIDI
a channel in the drop menu from 0-16.
REMOTE SWITCH : The REMOTE
>REMOTE SWITCH MENU, and selecting a setting from the drop menu.
34 |
p i g t r o n i x . c o m
TIME are controls for the
section.
SWITCH settings are inherited
CHANNEL, and selecting
SWITCH mode can be toggled by pressing EDIT-
GLOBAL SETTINGS is a set of options that accommodates a variety of musical requirements.
To read more about these settings and how to turn them on and off manually, see the BOOT
OPTIONS section on page 8.
Note: These are the factory default Global Boot Options.
The only setting that cannot be toggled manually is the position and cutoff frequency of the FEEDBACK
FILTER. This is a specially designed saturation stage that is largely responsible for the nuance and
texture of the echo as it regenerates. The position of the Feedback Filter can be toggled between "On
Delay Line Output" and "In Feedback Path Only." Additionally, the Corner Frequency can be adjusted by
the slider or by manually entering a frequency from 43 Hz to 11008 Hz.
Note for E2 Deluxe ONLY – The Display Bank Number Instead of LFO option allows the 5 LFO Waveform LEDs
in the upper right hand corner to display the Preset Bank by default. In order to toggle the LFO Waveform,
press the FLO Waveform button once to display the current Waveform. Then press to cycle through the LFO
Waveform options. After 3 seconds of inactivity the LEDs will display the current preset
Reset Global Settings to Defaults allows the user to override any local changes to GLOBAL SETTINGS
by replacing them with the FACTORY DEFAULT settings without performing a full FACTORY
RESET.
E c h o l u t i o n 2 | E c h o l u t i o n 2 D e l u x e
APPLICATION
bank.
| 35
