Installation
and Operating
Instructions
Model:
HO-4-9NF-CER-T-1
For your convenience, we recommend to attach
the serial number label HERE.
As part of Parmco Appliances commitment to improving and updating product ranges,
we reserve the right to alter, change and update technical specifications and appearance
attributes of all Parmco Appliances products. E&OE
727626102014
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Parmco HO-4-9NF-CER-T-1
Summary of Contents for Parmco HO-4-9NF-CER-T-1
- Page 1 For your convenience, we recommend to attach the serial number label HERE. As part of Parmco Appliances commitment to improving and updating product ranges, we reserve the right to alter, change and update technical specifications and appearance attributes of all Parmco Appliances products. E&OE...
- Page 2 Parmco Appliances before any installation is carried out. We hope you enjoy your new appliance. If you would like to nd out more about this product or any other products in Parmco’s extensive range, visit us on the web at www.parmco.co.nz. Regards,...
- Page 3 11. Metallic objects such as knives, forks, spoons and lids should not be placed on the hotplate since they will get hot. 12. If the surface is cracked, switch off the appliance and contact Parmco Appliances. To avoid the possibility of electric shock do not continue to use a damaged hob.
- Page 4 15. WARNING: Accessible parts may become hot during use. Young children should be kept away. 16. This appliance is not intended to be operated by means of an external timer or separate remote-control system. 17. Do not clean this appliance using steam cleaners. 18.
-
Page 5: General Precautions
Operation and maintenance precautions Electrical Shock • Do not cook on a broken or cracked cooktop. If the cooktop surface should break or crack, switch the appliance off immediately at the mains power supply (wall switch) and contact a qualified technician. •... - Page 6 themselves or their surroundings. • Do not repair or replace any part of the appliance unless specifically recommended in the manual. All other servicing should be done by a qualified technician. • Do not use a steam cleaner to clean your cooktop. •...
-
Page 7: Product Overview
Product Overview Top View 1. Max. 1800 W zone 2. Max. 1200 W zone 3. Max. 1100/2000 W zone 4. Max. 1000/2200 W zone 5. Max. 1200 W zone 6. Glass plate 7. Control panel Control Panel 1. Heating zone selection controls 2. -
Page 8: Before Using Your New Ceramic Hob
Before using your New Ceramic Hob • Read this guide, taking special note of the ‘Safety Warnings’ section. • Remove any protective film that may still be on your ceramic hob. Using the Touch Controls • The controls respond to touch, so you do not need to apply any pressure. •... -
Page 9: Using Your Ceramic Hob
Using your Ceramic Hob To start cooking 1. Touch the ON/OFF control. • Once powered on, the buzzer beeps once, all indicators light up for 1 second then go out, indicating that the ceramic hob is now on standby mode. 2. -
Page 10: When You Have Finished Cooking
When you have finished cooking 1. Touch the heating zone selection control that you wish to switch off. 2. Turn the cooking zone off by touching or sliding the slider to "I", and the display shows "0". 3. Turn the whole cooktop off by touching the ON/OFF control. - Page 11 Double Zone function • This function can be used only in #3 and #4 cooking zones. • The dual cooking zone has two cooking areas that you can use a central section and an outer section. You can use the central section (A) independently, both sections (B) at once.
-
Page 12: Locking The Controls
The double loop function is available only in #3 and #4 cooking zones of the hob. The power level for this function can range between 1 - 9. Locking the Controls • You can lock the controls to prevent unintended use (for example, children accidentally turning the cooking zones on). -
Page 13: Using The Timer
Residual Heat Warning When the hob has been operating for some time, there will be some residual heat. The letter “H” appears on the indicator to warn you to keep away from it. Auto Shutdown Auto shut down is a safety protection function for your ceramic hob. It shuts down automatically if you ever forget to turn off a cooking zone. - Page 14 3. Set the time by touching the slider control (eg. 5) 4. Touch the timer control again, and "1" will flash. 5. Set the time by touching the slider control (eg. 9). Now the time is set to 95minutes. 6. Once the time is set, the countdown will begin immediately; the display will show the remaining time.
- Page 15 4. Touch the timer control again, and "1" will flash. 5. Set the time by touching the slider control (eg. 9). Now the time is set to 95 minutes. 6. Once the time is set, the countdown will begin immediately; the display will show the remaining time.
-
Page 16: Cooking Guidelines
Cooking Guidelines Cooking Tips • When food comes to the boil, reduce the temperature setting. • Using a lid will reduce cooking times and save energy by retaining the heat. • Minimize the amount of liquid or fat to reduce cooking times. •... -
Page 17: Heat Settings
cooking large quantities, cook the food in several smaller batches. 3. Preheat the pan briefly and add two tablespoons of oil. 4. Cook any meat first, then put it aside and keep warm. 5. Stir-fry the vegetables. When they are hot but still crisp, turn the cooking zone to a lower setting, return the meat to the pan and add your sauce. -
Page 18: Care And Cleaning
Care and Cleaning What? How? Important! Everyday soiling on 1. Switch the power to the • When the power to the cooktop is glass (fingerprints, cooktop off. switched off, there will be no ‘hot marks, stains left by 2. Apply a cooktop cleaner while surface’... -
Page 19: Hints And Tips
This is normal for cookware and does crackling or clicking construction of your cookware not indicate a fault. noises. (layers of different metals vibrating differently). Technical Specification Cooking Hob HO-4-9NF-CER-T-1 Cooking Zones 5 Zones Supply Voltage 220-240V~50/60Hz Installed Electric Power 7600-9200W Product Size L×W×H(mm) 900x520x51 Cut-out Dimensions A×B (mm) -
Page 20: Selection Of Installation Equipment
Installation Dear Installer: Please affix data label provided on the adjacent cupboard near the appliance for future reference. Thank you. Selection of installation equipment Cut out the work surface according to the sizes shown in the drawing. For the purpose of installation and use, a minimum of 50mm space shall be preserved around the hole. -
Page 21: Before Locating The Fixing Brackets
Note: The safety distance between the hotplate and the cupboard above the hotplate should be at least 650mm. A(mm) B(mm) C(mm) 50 min 30 min Air intake Air exit 10mm Before locating the fixing brackets The unit should be placed on a stable, smooth surface (use the packaging). Do not apply force onto the controls protruding from the hob. -
Page 22: Connecting The Hob To The Mains Power Supply
Adjust the bracket position to suit different work surface’s thickness. Cautions 1. The hob must be installed by qualified personnel. Never conduct the operation by yourself. 2. The hob shall not be mounted to cooling equipment, dishwashers and rotary dryers. 3. - Page 23 1. If the cable is damaged or needs replacing, the operation must be carried out by a qualified technician with dedicated tools to avoid any accidents. 2. If the appliance is being connected directly to the mains, an omnipolar circuit breaker must be installed with a minimum gap of 3mm between the contacts.
-
Page 24: Warranty
• If proof of date of purchase is not supplied, except at the sole discretion of Parmco Sales. Proof of purchase can be for the product itself, or if installed • This warranty is offered as an extra benefi t, and does with a kitchen or house then proof of purchase can be from a Parmco not affect other legal rights, which can not be modifi...
