Summary of Contents for Parmco DDC800BI
- Page 1 INSTALLATION AND OPERATING INSTRUCTIONS Model: DDC800BI As part of Parmco Appliances commitment to improving and updating product ranges, we reserve the right to alter, change and update technical specifications and appearance attributes of all Parmco Appliances products. E&OE. 727626082022...
- Page 2 Dear Valued Customer, Thank you and congratulations on purchasing your new Parmco appliance. All Parmco products are made to the highest quality and design standards. We are sure you will enjoy your new appliance. As a note, please read through these instructions carefully. These will assist you in gaining a complete understanding of the functions and features offered by your appliance.
- Page 3 • If proof of date of purchase is not supplied, except at the sole Service Agent. discretion of Parmco Sales. Proof of purchase can be for the • This warranty is offered as an extra benefit, and does product itself, or if installed with a kitchen or house then proof of...
-
Page 4: Table Of Contents
Content SAFETY INSTRUCTIONS ........................1 PACKING LIST ..........................3 PRODUCRT STRUCTURE ......................4 HOW INDUCTION HEATING WORKS .................... 4 INSTALLATION (EXTRACTION MODE) ..................5 INSTALLATION (RECIRCULATION MODE) ..................7 ELECTRICAL CONNECTION & SAFETY WARNING ..............11 OPERATION ..........................12 MAINTENANCE AND CLEANING ....................18 TECHNICAL PARAMETER &... -
Page 5: Safety Instructions
SAFETY INSTRUCTIONS Please read the following instructions carefully before using the appliance. Especially important: The design of the induction cooker of this product complies with the EEC Directive 89/336 guidelines. When the cooker is working, there is an electromagnetic field near it, and it will not interfere with the use of other electrical equipment during normal use, but special attention should be paid to the following conditions: Those who use pacemakers must ensure that their pacemaker design meets the above guidelines. - Page 6 display "H". At this time, do not touch the glass with your hands to avoid burns, and do not place objects on the glass to avoid being heated by the residual heat of the glass. After using the hob, you should use the control button to shut down. Do not rely on the hob to detect that ...
-
Page 7: Packing List
PACKING LIST Item Unit Image Induction & Cookhood Whole machine Inlet cover Aluminum filter Strip seal User manual... -
Page 8: Producrt Structure
PRODUCRT STRUCTURE For the product structure, refer to image below: HOW INDUCTION HEATING WORKS There is an electronic circuit inside the induction hob which powers and commands a coil. This creates a magnetic field which activates when it comes into contact with suitable pots and pans(magnetic material). The pan on the hob warms up instantly, while the hob remains cold. -
Page 9: Installation (Extraction Mode)
INSTALLATION (EXTRACTION MODE) Installation tips The hob can be installed on a top with a flat surface and thickness of between 30 and 40mm. The cupboard underneath the top should leave enough sufficient area to accommodate inlet plenum, blower cavity, inlet pipe, outlet pipe and so on, and this area should make sure good ventilation and heat dissipation is provided. - Page 10 Make a square opening on the table surface with the size of 765*490mm, refer to Pic above for the specification. After drilling a hole on the table surface, carefully remove shavings or sawdust before inserting the appliance, as they could be sucked up by the appliance and compromising its function. Make sure the table surface is level and square and that no part interferes with the space required for installation.
-
Page 11: Installation (Recirculation Mode)
Put the square to round adapter on the square pipe, and put the outer exhaust pipe on the square to round adapter. See pic 7. Installation is finished. See pic 8. INSTALLATION (RECIRCULATION MODE) Installation tips The hob can be installed on a top with a flat surface and thickness of between 30 and 40mm.The cupboard underneath the top should leave enough sufficient area to accommodate inlet plenum, blower cavity, inlet pipe, outlet pipe and so on, and this area should make sure good ventilation and heat dissipation is provided. - Page 12 Preparing the unit for a built-in appliance Make a square opening on the table surface with the size of 765*490mm,then make a square hole from the beside of the cupboard, with diameter of about 240*100mm, refer to Pic above for the specification. After drilling a hole on the table surface, carefully remove shavings or sawdust before inserting the appliance, as they could be sucked up by the appliance and compromising its function.
- Page 13 Put the right-angle elbow on the air outlet, and then put the square pipe into the right-angle elbow. See pic 5. Tilt the hob into the cupboard at a certain angle. See pic 6. Put the square elbow sleeve, square pipe, square pipe 90° elbow, and inner exhaust pipe on the corresponding pipes according to the pic 7.
- Page 14 Install the aluminum filter. See pic 12. Install the air inlet net. See pic 13. All the pipes must pass under the base of the piece of furniture, inside the lift of the kitchen plinth.
-
Page 15: Electrical Connection & Safety Warning
ELECTRICAL CONNECTION & SAFETY WARNING Disconnect the appliance before any intervention. Disregard of this could cause electric shock and danger of death. The appliance must be installed by qualified personnel with all electrical installation requisites in compliance with the local norms in force. Make sure that the voltage of your electric network is the same voltage as indicated on the appliance rating label. -
Page 16: Operation
The display of the cooking area will show if the pan is suitable, if the power indicator flashes the pan is not suitable or the diameter of the bottom is too small for the diameter of the cooking area. The pots and pans must be placed precisely in the middle of the cooking area. - Page 17 The Control Panel Power ON/OFF Safety lock Select power level Induction hob Boost control Timer Setting Heating zone select Timer display Power ON/OFF Power indicator light Timer indicator light Hood Timer Power setting display Increase speed Decrease speed Using the Cooker Hood After connecting to power, the cooker hood buzzer will ring shortly for a sound, all indicator lights and digital tube will light for 1s,then be off and the cooker hood is in stand-by mode.
- Page 18 Using the Induction Hob To Start Cooking After power on, the buzzer beeps once, all the indicators light up for 1 second then go out, indicating that the hob has entered the state of standby mode. Touch the Power ON/OFF button, all the indicators show ‘—’. Place a suitable pan on the cooking zone that you wish to use.
- Page 19 Using Boost Function Activate the boost function 1. Select the zone with boost function. 2. Touching the ‘boost’ key, then the display shows ‘b’. Cancel boost function 1. Select the zone with boost function. 2. Touching the ‘minus’ key to cancel the Boost function, and select the level you want to set. 3.
- Page 20 Touch timer key, ‘10’ will show in the timer display and ‘0’ will blink. Set the time by touching the ‘-’ , ‘+’ control of timer. Touch timer control again, then ‘1’ will flash. Set the time by touching the ‘-’ , ‘+’ . When the timer is set, it will begin to count down immediately.
- Page 21 Cancel the timer Touching the heating zone selection control that you want to cancel the timer. Touching the timer control, the indicator will flash. Touch the ‘-’ or ‘slider’ control to set the timer to ‘00’, the timer is canceled. Auto shutdown protection Auto shutdown is a safety protection function for your induction hob.
-
Page 22: Maintenance And Cleaning
MAINTENANCE AND CLEANING Daily maintenance Periodically check that dust does not deposit under the fan or in the discharge openings, this could obstruct ventilation for cooling the electronic system, reducing the efficiency of your hob. The hob could be damaged if hard and sharp edged objects fall on it, it is recommended that such objects be kept away from the hob where they cannot fall on it. - Page 23 10. The oil plate of the cooker hood must be cleaned regularly, and the clean method is as following: 11. As shown in the pic below, open the four buckles on the hob by hand and remove the oil plate. 12.
-
Page 24: Technical Parameter & Circuit Diagram
TECHNICAL PARAMETER & CIRCUIT DIAGRAM Technical data Product model DDC800BI Voltage/frequency AC220-240V/50Hz Power consumption 7350W (induction hob 7200W & cooker hood 150W) Cooker hood max air flow 600m³/h Cooker hood wind pressure ≥327Pa Noise level ≤72db <45℃ Working environmental temperature -20℃~45℃... -
Page 25: Troubleshooting
TROUBLESHOOTING Fault Code Possible problem Description No pan or pot, or their size, material, etc. is not suitable, or Pan or pot fault not placed precisely in the middle of the cooking area. Voltage is too high Higher than AC 265V. Voltage is too high Lower than AC 180V. -
Page 26: Environmental Protection
ENVIRONMENTAL PROTECTION Note: Before discarding an old appliance, switch off and disconnect it from the power supply. Cut off and render any plug useless. Cut the cable off directly behind the appliance to prevent misuse. This should be undertaken by a competent person. This appliance is marked according to the European directive 2002/96/EC on Waste electrical and Electronic Equipment (WEEE).
