Parmco Verso 4I Hob Installation And Operating Instrictions

Hide thumbs
Table of Contents

Advertisement

Quick Links

Installation
and Operating
Instructions
Model:
VERSO 4I Hob
For your convenience, we recommend to attach
the serial number label HERE.
As part of Parmco Appliances commitment to improving and updating product ranges,
we reserve the right to alter, change and update technical specifications and appearance
attributes of all Parmco Appliances products. E&OE
727626022014

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Verso 4I Hob and is the answer not in the manual?

Questions and answers

Related Manuals for Parmco Verso 4I Hob

Summary of Contents for Parmco Verso 4I Hob

  • Page 1 For your convenience, we recommend to attach the serial number label HERE. As part of Parmco Appliances commitment to improving and updating product ranges, we reserve the right to alter, change and update technical specifications and appearance attributes of all Parmco Appliances products. E&OE...
  • Page 2 Parmco Appliances before any installation is carried out. We hope you enjoy your new appliance. If you would like to nd out more about this product or any other products in Parmco’s extensive range, visit us on the web at www.parmco.co.nz. Regards,...

  • Page 3: Table Of Contents

    INDEX Important Safety Warnings 1. Product overview 1.1 Top view 1.2 Control panel 2. What is Induction Cooking 3. Using the Touch Controls 4. Using the right cookware 5. Using your Induction Hob 5.1 To start cooking 5.2 When you have finished cooking 9.

  • Page 4: Important Safety Warnings

    IMPORTANT SAFETY WARNINGS • Read these instructions carefully before installing or using this appliance. • No combustible material or products should be placed on this appliance at any time. • Please make this information available to the person responsible for installing the appliance as it could reduce your installation costs.
  • Page 5 • Do not repair or replace any part of the appliance unless specifically recommended in the manual. All other servicing should be done by a qualified technician. • Do not use a steam cleaner to clean your cooktop. • Do not place or drop heavy objects on your cooktop. •...

  • Page 6: Safety Precautions

     Metallic objects such as knives, forks, spoons and lids should not be placed on the hotplate since they will get hot.  If the surface is cracked, switch off the appliance and contact Parmco Appliances. To avoid the possibility of electric shock do not continue to use a damaged hob.
  • Page 7 Cut Hazard • The razor-sharp blade of a cooktop scraper is exposed when the safety cover is retracted. Use it with extreme care and store it safely , out of reach of children. Failure to use caution could result in injury or cuts. Operation and maintenance •...

  • Page 8: Product Overview

    Congratulations on the purchase of your new Induction Hob. We recommend that you carefully read this Manual as it provides information for a safe installation, use and maintenance. For installation, please refer to the installation section. Keep this manual in a safe place for future reference.

  • Page 9: What Is Induction Cooking

    What is Induction Cooking Induction cooking is a safe, advanced, efficient, and economical cooking technology. It works by electromagnetic vibrations generating heat directly in the pan, rather than indirectly through heating the glass surface. The glass becomes hot only because the pan eventually warms it up. iron pot magnetic circuit ceramic glass plate...

  • Page 10: Choosing The Right Cookware

    Choosing the right Cookware • Only use cookware with a base suitable for induction cooking. Look for the induction symbol on the packaging or on the bottom of the pan. • You can check whether your cookware is suitable by carrying out a magnet test.

  • Page 11: Using Your Induction Hob

    Using your Induction Hob To start cooking 1. Touch the ON/OFF control. After the hob is powered on, the buzzer beeps once “ – “ or “ – – “ indicating that the and all displays show induction hob has entered in standby mode. 2.

  • Page 12: When You Have Finished Cooking

    If the display flashes alternately with the heat setting... • You have not placed a pan on the correct cooking zone or, • The pan you’re using is not suitable for induction cooking or, • The pan is too small or not properly centered on the cooking zone. Heating does not take place unless there is a suitable pan on the cooking zone.

  • Page 13: Locking The Controls

    4. Beware of hot surfaces H will show which cooking zone is still too hot to touch. It will disappear when the surface has cooled down to a safe temperature. It can also be used as an energy saving function - if you want to heat further pans, use a hotplate that is still hot.

  • Page 14: Using The Timer

    Detection of Small Articles When an unsuitable size or non-magnetic pan (e.g. aluminium), or some other small item (e.g. knife, fork, key) has been left on the hob, the hob automatically goes on standby mode in 1 minute. The fan will keep cooking down the induction hob for a further 1 minute.
  • Page 15 2. Touch the timer control. “10” will show on the timer display and start flashing. 3. Set the time by touching ”-“ or ”+” controls Hint: Touch the “-“ or ”+” control of the timer once to decrease or increase by 1 minute. Hold the “-“...
  • Page 16 Setting the timer to turn one cooking zone off 1. Touch the heating zone selection control that you want to set the timer for (eg. zone 3). 2. Touch the timer control and the minder indicator will start flashing, showing "10" in the timer display. 3.

  • Page 17: Cooking Guidelines

    6. When the cooking timer expires, the corresponding cooking zone will switch off automatically. Other cooking zone will keep operating if they have been turned on previously. Cooking Guidelines Cooking Tips • When food comes to the boil, reduce the temperature setting. •...

  • Page 18: Heat Settings

    4. Turn the steak only once during cooking. The exact cooking time will depend on the thickness of the steak and how cooked you want it. Times may vary from about 2 – 8 minutes per side. Press the steak to gauge how cooked it is –...

  • Page 19: Cleaning And Maintenance

    Cleaning and Maintenance What? How? Important! Everyday soiling 1. Switch the power to the • When the power to the cooktop on glass cooktop off. is switched off, there will be no (fingerprints, 2. Apply a cooktop cleaner ‘hot surface’ indication but the marks, stains left while the glass is still cooking zone may still be hot!

  • Page 20: Troubleshooting

    Troubleshooting Problem Possible causes What to do The induction hob No power. Make sure the induction hob is cannot be turned connected to the power supply and that it is switched on. Check whether there is a power outage in your home or area. If you’ve checked everything and the problem persists, call a qualified technician.

  • Page 21: Failure Display And Inspection

    Technical fault. Please note the error code, switch or a cooking zone the power off at the wall, and has turned itself off contact Parmco or an authorised unexpectedly, a technician. tone sounds and an error code is displayed (typically...

  • Page 22: Technical Specifications

    Technical Specification Cooking Hob Verso 4l Hob Cooking Zones 4 Zones Supply Voltage 220-240V~ 50/60Hz Installed Electric Power 6400-7000W Product Size D×W×H(mm) 590X520X60 Cut-out Dimensions A×B (mm) 560X490 Weight and Dimensions are approximate. We continually strive to improve our products so we may change specifications and designs without prior notice.
  • Page 23 Under all circumstances, the Induction hob has to be well ventilated and the air inlet and outlet should not blocked. This is essential to ensure that the Induction hob will be in a good working state. Note: The safety distance between the hotplate and the cupboard above the hotplate should be at least 760mm.
  • Page 24 • The isolating switch will be easily accessible to the customer once the hob is installed. • You consult local building authorities or Parmco if in doubt regarding installation. • You use heat-resistant and easy-to-clean finishes (such as ceramic tiles) for the wall surfaces surrounding the hob.
  • Page 25 Cautions 1. The induction hotplate must be installed by qualified personnel or technicians. Do not attempt to install it yourself to avoid personal injuries and voiding the warranty. 2. The hob cannot be installed directly above a dishwasher, fridge, freezer, washing machine or clothes dryer, as the humidity may damage the hob electronics.
  • Page 26 Any alterations must be made only by a qualified electrician. The power supply should be connected in compliance with the relevant standard, or a single-pole circuit breaker. The method of connection is shown below. • If the cable is damaged or needs to be replaced, this operation must be carried out the by a qualified electrician.

  • Page 27: Year Warranty

    • If proof of date of purchase is not supplied, except at the sole discretion of Parmco Sales. Proof of purchase can be for the product itself, or if installed • This warranty is offered as an extra benefi t, and does with a kitchen or house then proof of purchase can be from a Parmco not affect other legal rights, which can not be modifi...
