- Page 1 Installation and Operating Instructions Model: HX-1-75NF-CER-T For your convenience, we recommend to attach the serial number label HERE. 727626032017...
- Page 3 Dear Valued Customer, Thank you and congratulations on purchasing your new Parmco appliance. All Parmco products are made to the highest quality and design standards. We are sure you will enjoy your new appliance. As a note, please read through these instructions carefully. These will assist you appliance.
-
Page 4: Table Of Contents
INDEX Important Safety Warnings Product overview Top view Control panel Before using your Ceramic Hob Using your Ceramic Hob To start cooking When you have finished cooking Locking the controls Using the timer Auto Shutdown Cooking guidelines Heat settings Care and cleaning Troubleshooting Technical Specifications Installation... -
Page 5: Important Safety Warnings
11. Metallic objects such as knives, forks, spoons and lids should not be placed on the hotplate since they will get hot. 12. If the surface is cracked, switch off the appliance and contact Parmco Appliances. To avoid the possibility of an electric shock do not continue to use a damaged hob. - Page 6 17. After use switch off the hob element at its control. Other Safety Precautions Your safety is important to us. Please read this information before using your cooktop. • No combustible material or products should be placed on this appliance at any time. •...
- Page 7 Operation and Maintenance Precautions Hot Surface • During use, accessible parts of this appliance may become hot enough to cause burns. • Do not let your body, clothing or any item other than suitable cookware contact the glass until the surface is cool. •...
-
Page 8: Product Overview
Product Overview Top View Control Panel 1. Heating zone selection controls 2. Power/Timer regulating controls 3. Key-lock/Child-lock control 4. ON/OFF control 5. Timer control... -
Page 9: Before Using Your Ceramic Hob
Before using your Ceramic Hob • Read this guide, taking special note of the ‘Safety Warnings’ section. • Remove any protective film that may still be on your ceramic hob. Note: you may notice a little smoke when you turn the hob on for the first time. The smoke is due to the manufacturing residues left on the hob. -
Page 10: Using Your Ceramic Hob
Using your Ceramic Hob To start cooking You will hear a beep each time a touch is registered on the control panel. 1. Touch the ON/OFF control. All the indicators show “-“ or “- -“ • Once powered on, the hob will beep once and all cooking zone indicators will light up briefly, indicating that the ceramic hob is now on. -
Page 11: When You Have Finished Cooking
When you have finished cooking 1. Touch the cooking zone selection control that you wish to switch off. 2. Turn the cooking zone off by scrolling down to “0 “ using the “-“ key on your power regulating control. The display will then show “H" 3. -
Page 12: Locking The Controls
Locking the Controls You can lock the controls to prevent unintended use (for example children accidentally turning the cooking zones on). When this function is activated, all controls except the ON/OFF control are disabled. To lock the controls 1. Touch and hold the keylock control to lock the control panel. -
Page 13: Auto Shutdown
• If the setting time exceeds 99 minutes, the timer will automatically return to 0 minutes. Cancelling the timer for a heating zone 1. Press the ”-“ timer regulating key to reduce the time outstanding to 0. When the selected cooking time has been reached, the corresponding cooking zone will switch off... -
Page 14: Cooking Guidelines
Cooking Guidelines Cooking Tips • When food comes to the boil, reduce the temperature setting. • Using a lid will reduce cooking times and save energy by retaining the heat. • Minimize the amount of liquid or fat to reduce cooking times. •... -
Page 15: Heat Settings
5. Stir-fry the vegetables. When they are hot but still crisp, turn the cooking zone to a lower setting, return the meat to the pan and add your sauce. 6. Stir the ingredients gently until they are heated through. Serve immediately. Heat Settings The settings below are guidelines only. -
Page 16: Care And Cleaning
Care and Cleaning What? How? Important! Everyday soiling 1. Switch off the power to • When the power to the cooktop on glass the cooktop at the wall. is switched off, there will be no (fingerprints, 2. Apply a non-abrasive ‘hot surface’... -
Page 17: Troubleshooting
Trouble Shooting Problem Possible causes What to do The cooktop No power. Make sure the cooktop is cannot connected to the power supply be turned on. and that it is switched on. Check whether there is a power outage in your home or area. If you’ve checked everything and the problem persists, call a qualified technician. -
Page 18: Technical Specifications
Technical Specification Model HX-1-75NF-CER-T Cooking Zones 4 Zones Supply Voltage 220-240V~ 50Hz Power 1200W (145mm) 1800W (180mm) Product Size L×W×H(mm) 750x510x48 Cut-out Dimensions (A x B) 494(W) x 734(L) mm Dimensions are approximate. Because we continually strive to improve our products we may... -
Page 19: Installation
Installation Dear Installer: Please affix data label provided on the adjacent cupboard near the appliance for future reference. Thank you. Selection of installation equipment • Cut out the work surface according to the sizes shown in the drawing. • For the purpose of installation and use, a minimum of 50mm space shall be preserved around the hole. - Page 20 When installing a rangehood above an appliance, all relevant/current New Zealand building, installation and regulation standards must be adhered to. Note: The safety distance between the ceramic hob and the cupboard above it or rangehood should be at least 650mm. A(mm) B(mm) C(mm)
- Page 21 Inserting and fixing the hob Before inserting the hob into the work surface, place the adhesive seal around the underside edge of the hob. It is important to fix the seal evenly without gaps, to prevent liquids from seeping underneath the hob. Place the gasket around the bottom edge of the hob.
- Page 22 The power supply should be connected in compliance with the relevant local standards. ④ CONNECTION DIAGRAM Caution! Voltage of heating elements 220-240V ⑤ Caution! In the event of any connection the safety ② Wire must be connected to the E terminal. ①...
- Page 23 Disposal This appliance is labeled in compliance with European directive 2012/19/EU for Waste Electrical and Electronic Equipment (WEEE). By ensuring that this appliance is disposed of correctly, you will help prevent any possible damage to the environment and to human health, which might otherwise be caused if it were disposed of in the wrong way.
