Summary of Contents for Parmco HX-1-6NF-CER
- Page 1 Installation and Operating Instructions Model: HX-1-6NF-CER HX-1-6S-CER For your convenience, we recommend to attach the serial number label HERE. 727626032017...
- Page 3 Dear Valued Customer, Thank you and congratulations on purchasing your new Parmco appliance. All Parmco products are made to the highest quality and design standards. We are sure you will enjoy your new appliance. As a note, please read through these instructions carefully. These will assist you appliance.
-
Page 4: Table Of Contents
INDEX Important Safety Warnings Product overview Top view Control panel Before using your Ceramic Hob Using your Ceramic Hob To start cooking When you have finished cooking Cooking guidelines Heat settings Care and cleaning Troubleshooting Technical Specifications Installation... - Page 5 17. After use switch off the hob element at its control. Other Safety Precautions Your safety is important to us. Please read this information before using your cooktop. • No combustible material or products should be placed on this appliance at any time. •...
-
Page 6: General Precautions
Operation and Maintenance Precautions Hot Surface • During use, accessible parts of this appliance may become hot enough to cause burns. • Do not let your body, clothing or any item other than suitable cookware contact the glass until the surface is cool. •... -
Page 7: Product Overview
Product Overview Top View Knob Controls Control Panel... -
Page 8: Before Using Your Ceramic Hob
Before using your Ceramic Hob • Read this guide, taking special note of the ‘Safety Warnings’ section. • Remove any protective film that may still be on your ceramic hob. Note: you may notice a little smoke when you turn the hob on for the first time. The smoke is due to the manufacturing residues left on the hob. -
Page 9: Using Your Ceramic Hob
Using your Ceramic Hob To start cooking Turn on power supply to the hob. Place a suitable pan on the cooking zone you wish to use. • Make sure the bottom of the pan and the surface of the cooking zone are clean and dry. Turn the associated knob clockwise to turn on the cooking zone. -
Page 10: Cooking Guidelines
Cooking Guidelines Cooking Tips • When food comes to the boil, reduce the temperature setting. • Using a lid will reduce cooking times and save energy by retaining the heat. • Minimize the amount of liquid or fat to reduce cooking times. •... -
Page 11: Heat Settings
5. Stir-fry the vegetables. When they are hot but still crisp, turn the cooking zone to a lower setting, return the meat to the pan and add your sauce. 6. Stir the ingredients gently until they are heated through. Serve immediately. Heat Settings The settings below are guidelines only. -
Page 12: Care And Cleaning
Care and Cleaning What? How? Important! Everyday soiling Switch off the power to • When the power to the cooktop on glass the cooktop at the wall. is switched off, there will be no (fingerprints, Apply a non-abrasive ‘hot surface’ indication but the marks, stains left ceramic cleaner while cooking zone may still be hot! -
Page 13: Troubleshooting
Trouble Shooting Problem Possible causes What to do The cooktop No power. Make sure the cooktop is cannot connected to the power supply be turned on. and that it is switched on. Check whether there is a power outage in your home or area. If you’ve checked everything and the problem persists, call a qualified technician. -
Page 14: Technical Specifications
Technical Specification Model HX-1-6NF-CER & HX-1-6S-CER Cooking Zones 4 Zones Supply Voltage 220-240V~ 50Hz Power 1200W (145mm) 1800W (180mm) Product Size L×W×H(mm) 590x520x76mm HX-1-6S-CER 580x510x76mm HX-1-6NF-CER Cut-out Dimensions (A x B) 494(W) x 564(L) mm Dimensions are approximate. Because we continually strive to improve our products we may... -
Page 15: Installation
Installation Dear Installer: Please affix data label provided on the adjacent cupboard near the appliance for future reference. Thank you. Selection of installation equipment Cut out the work surface according to the sizes shown in the drawing. For the purpose of installation and use, a minimum of 50mm space shall be preserved around the hole. - Page 16 When installing a rangehood above an appliance, all relevant/current New Zealand building, installation and regulation standards must be adhered to. Note: The safety distance between the ceramic hob and the cupboard above it or rangehood should be at least 650mm. A(mm) B(mm) C(mm)
- Page 17 Inserting and fixing the hob Before inserting the hob into the work surface, place the adhesive seal around the underside edge of the hob. It is important to fix the seal evenly without gaps, to prevent liquids from seeping underneath the hob. Turn the hob upside down (ensure the surface will not scratch the ceramic glass).
- Page 18 Connecting the hob to the mains power supply The power supply should be connected in compliance with the relevant local standards. ④ CONNECTION DIAGRAM Caution! Voltage of heating elements 220-240V ⑤ Caution! In the event of any connection the safety ②...
- Page 19 Disposal This appliance is labeled in compliance with European directive 2012/19/EU for Waste Electrical and Electronic Equipment (WEEE). By ensuring that this appliance is disposed of correctly, you will help prevent any possible damage to the environment and to human health, which might otherwise be caused if it were disposed of in the wrong way.
