- Page 1 Installation and Operating Instructions Model: HX-1-9NF-CER-T For your convenience, we recommend to attach the serial number label HERE. 727626032017...
- Page 3 Dear Valued Customer, Thank you and congratulations on purchasing your new Parmco appliance. All Parmco products are made to the highest quality and design standards. We are sure you will enjoy your new appliance. As a note, please read through these instructions carefully. These will assist you appliance.
-
Page 4: Table Of Contents
INDEX Important Safety Warnings Product overview Top view Control panel Before using your Ceramic Hob Using your Ceramic Hob To start cooking When you have finished cooking Locking the controls Using the timer Auto Shutdown Cooking guidelines Heat settings Care and cleaning Troubleshooting Technical Specifications Installation... -
Page 5: Important Safety Warnings
11. Metallic objects such as knives, forks, spoons and lids should not be placed on the hotplate since they will get hot. 12. If the surface is cracked, switch off the appliance and contact Parmco Appliances. To avoid the possibility of an electric shock do not continue to use a damaged hob. - Page 6 17. After use switch off the hob element at its control. Other Safety Precautions Your safety is important to us. Please read this information before using your cooktop. • No combustible material or products should be placed on this appliance at any time. •...
- Page 7 Operation and Maintenance Precautions Hot Surface • During use, accessible parts of this appliance may become hot enough to cause burns. • Do not let your body, clothing or any item other than suitable cookware contact the glass until the surface is cool. •...
-
Page 8: Product Overview
Product Overview Top View Control Panel 1. Dual heating zone selection control 2. Power/Timer regulating controls 3. Key-lock/Child-lock control 4. ON/OFF control... -
Page 9: Before Using Your Ceramic Hob
Before using your Ceramic Hob • Read this guide, taking special note of the ‘Safety Warnings’ section. • Remove any protective film that may still be on your ceramic hob. Note: you may notice a little smoke when you turn the hob on for the first time. The smoke is due to the manufacturing residues left on the hob. -
Page 10: Using Your Ceramic Hob
Using your Ceramic Hob To start cooking You will hear a beep each time a touch is registered on the control panel. 1. Touch the ON/OFF control. All the indicators show “-“ or “- -“ • Once powered on, the hob will beep once and all cooking zone indicators will light up briefly, indicating that the ceramic hob is now on. -
Page 11: When You Have Finished Cooking
When you have finished cooking 1. Turn the cooking zone off by scrolling down to “0 “ using the “-“ key on your power regulating control. The display will then show “H" 2. Alternatively turn the whole cooktop off by touching the control 3. -
Page 12: Using The Timer
Using the Timer You can use the timer to turn one or more cooking zones off after a set amount of time. Note: The timer can be set for up to 99 minutes for each cooking zone. Once the time is set it will begin to count down immediately. Setting the timer to turn one heating zone off... -
Page 13: Auto Shutdown
Auto Shutdown Auto shut down is a safety protection function for your ceramic hob. It shuts down automatically if you ever forget to turn off a cooking zone. The default shutdown times for various power levels are shown in the table below: Power level Default working timer (hour) Cooking Guidelines... -
Page 14: Heat Settings
side. Press the steak to gauge how cooked it is – the firmer it feels the more ‘well done’ it will 5. Leave the steak to rest on a warm plate for a few minutes before serving. Stir-frying 1. Choose a ceramic compatible flat-based wok or a large frying pan. 2. -
Page 15: Care And Cleaning
Care and Cleaning What? How? Important! Everyday soiling 1. Switch off the power to • When the power to the cooktop on glass the cooktop at the wall. is switched off, there will be no (fingerprints, 2. Apply a non-abrasive ‘hot surface’... -
Page 16: Troubleshooting
Troubleshooting Problem Possible causes What to do The cooktop No power. Make sure the cooktop is cannot connected to the power supply be turned on. and that it is switched on. Check whether there is a power outage in your home or area. If you’ve checked everything and the problem persists, call a qualified technician. -
Page 17: Technical Specifications
Technical Specification Model HX-1-9NF-CER-T Cooking Zones 5 Zones Supply Voltage 220-240V~ 50Hz Power 1200W (145mm) 1700W/700W (180/120mm) 1800W (180mm) Product Size L×W×H(mm) 860x520x63mm Cut-out Dimensions (A x B) 490(W) x 830(L) mm Dimensions are approximate. Because we continually strive to improve our products we may... -
Page 18: Installation
Installation Dear Installer: Please affix data label provided on the adjacent cupboard near the appliance for future reference. Thank you. Selection of installation equipment • Cut out the work surface according to the sizes shown in the drawing. • For the purpose of installation and use, a minimum of 50mm space shall be preserved around the hole. - Page 19 When installing a rangehood above an appliance, all relevant/current New Zealand building, installation and regulation standards must be adhered to. Note: The safety distance between the ceramic hob and the cupboard above it or rangehood should be at least 650mm. A(mm) B(mm) C(mm)
- Page 20 Inserting and fixing the hob Before inserting the hob into the work surface, place the adhesive seal around the underside edge of the hob. It is important to fix the seal evenly without gaps, to prevent liquids from seeping underneath the hob. Place the gasket around the bottom edge of the hob.
- Page 21 Connecting the hob to the mains power supply The power supply should be connected in compliance with the relevant local standards. ④ CONNECTION DIAGRAM ③ Caution! Voltage of heating elements 220-240V ⑤ Caution! In the event of any connection the safety ②...
- Page 22 Disposal This appliance is labeled in compliance with European directive 2012/19/EU for Waste Electrical and Electronic Equipment (WEEE). By ensuring that this appliance is disposed of correctly, you will help prevent any possible damage to the environment and to human health, which might otherwise be caused if it were disposed of in the wrong way.
