INDICATION LAMPS:

OST POWER LAMP
START
STOP STOP
MODE power connected and switched on.
PPLY
START GENERAL ERROR LAMP
STOP STOP
An error has been detected.
START POLARITY ERROR
STOP
reversed polarity or short circuit in charge cables error.
BATTERY ERROR
Battery temperature error. The battery is too hot to charge.
BATTERY VOLTAGE ERROR
overvoltage error on battery connection.
8 • EN
START
STOP
0.00h
SETTINGS BEFORE START:
DISPLAY (V)
indicates voltage set
options: 12 / 24volts
Supply voltage
indicates voltage set
options: 13,6 / 14,0 / 14,4 / 14,8V in 12v setting
options: 27,2 / 28,0 / 28,8 / 29,6V in 24v setting
DISPLAY (A)
indicates current set
options: 40 / 30 / 20 / 10A in 12v setting
options: 20 / 15 / 10 / 5A in 24v setting
DISPLAY (h)
indicates which parameter to set
options: V / SV / A / T / RT[ h ]
V = Nominal voltage
SV = Supply voltage
T = Temperature compensation
RT[ h ] = recond time in BooST program
DISPLAY (h) + (Ah & info)
Displays error codes
A = Current limit
REAL TIME INDICATION DURING ChARGING:
DISPLAY (V)
Displays output voltage
DISPLAY (A)
Displays output current
DISPLAY (h)
Alt. 1. Displays total elapsed charging time (minutes/hours)
Alt. 2. Displays time elapsed until error occured
Alt. 3. Displays error message
DISPLAY (Ah & info)
Alt.1. Displays total charge delivered since start (minutes/hours)
Alt.2. Displays error codes together with Error lamp
1 2 3 4 5 6 7 8
12V 40A
0Ah
SET
NORMAL
MODE
AGM
Ca/Ca
BOOST
START
STOP STOP
SUPPLY
1 2 3 4 5 6
24V
Error:
ERROR CODES:
E01
SET
REVERSE POLARITY
Connect the charger according to "quickguide".
E02
OVER VOLTAGE
Battery voltage too high for the chosen charging program, check
battery voltage.
E03
TIME OUT STEP 1: DESULPhATION
restart the charger. if charging is still being interrupted the bat-
NORMAL
tery is seriously sulphated and may need to be replaced.
E04
TIME OUT STEP 2: SOFT START
restart the charger. if charging is still being interrupted the battery AGM
can not accept charge and may need to be replaced.
E05
STEP 5: ANALYSE
restart the charger. if charging is still being interrupted the bat- Ca/Ca
tery cannot retain charge and may need to be replaced.
E06
BATTERY OVERhEATED
BOOST
The battery is too hot to charge. The battery is damaged and
may need to be replaced.
STOP
E07
LOW BATTERY VOLTAGE IN SUPPLY PROGRAM
SUPPLY
Battery voltage too low or too large consumers connected. Check
if 12v battery connected in 24v battery setting or disconnect
large consumers.
E08
hIGh CURRENT IN SUPPLY PROGRAM
Check if clamps are short circuited or connected reversed polarity.
E99
OVER VOLTAGE PROTECTION
if battery voltage is below 17v the Error lamp is lit when 24v
setting has been selected.
A lt 1. press STArT/STop button to charge with 12v setting.
To set the parameters for customized charging proceed with
"ChArgiNg" step 6 to 9.
Alt 2. press iNCrEASE button to change to 24v setting. press
STArT/STop button to resume. To set the parameters for custom-
ized charging proceed with "ChArgiNg" step 6 to 9.
7 8
20A
E07
MODE
START
