ChARGING PROGRAMS

Choose program by pressing the MoDE-button.
Adjust parameters according to "ChArgiNg" (6–9).
press STArT/STop button to start the selected program.
The table explains the different Charging Programs:
Battery Size
Program
(Ah)
20–1200Ah
NoRmAl
10–600Ah
20–1200Ah
AGm
10–600Ah
20–1200Ah
Ca/Ca
10–600Ah
20–1200Ah
BooST
10–600Ah
20–1200Ah
Supply
10–600Ah
12V
Current Battery size Min
10A 20Ah
20A 40Ah
30A 60Ah
40A 80Ah
• U sing higher current than recommended may result in batteries not being
completely charged.
•Using lower current than recommended will prolong the charging time.
• T he currents are the maximum recommended current for battery charg-
ing. if a parallel consumer is connected then the current setting could be
increased with this current value.
• S ome battery manufacturer could recommend different values. Please
check with the manufacturer if uncertain. The main recommendations are
that gel batteries should be charged in the lower current range, power
AgM's in the upper range and most other battery types in the mid-range.
Explanation
use for gEl, WET and Mf batteries.
use for most AgM batteries. Some AgM should use lower voltage
(NorMAl Mode), check battery manual if unsure.
use for Ca/Ca batteries. use Ca/Ca program to maximize charge with
minimum loss of fluid. including rECoND step. recond your battery once
per year and after deep discharge to maximise lifetime and capacity.
used for recovery of stratified batteries.
use as power supply or use for float maintenance charging when 100%
capacity of the battery is required. Supply program activates step 7 without
time or voltage limitation.
Battery size Max Current
300Ah 5A
600Ah 10A
900Ah 15A
1200Ah 20A
Risk of short circuiting the battery cables. Connect charger cables
to the charger before connecting the battery
Risk of electrical shock if touching positive and negative terminals
Temp range
-20°C–+50°C
(-4ºf–+122ºf)
-20°C–+50°C
(-4ºf–+122ºf)
-20°C–+50°C
(-4ºf–+122ºf)
-20°C–+50°C
(-4ºf–+122ºf)
-20°C–+50°C
(-4ºf–+122ºf)
24V
Battery size Min Battery size Max
10Ah 150Ah
20Ah 300Ah
30Ah 450Ah
40Ah 600Ah
WARNING!
WARNING!
when charging

TEChNICAL SPECIFICATION

Model number 1069
Rated Voltage AC 220–240VAC, 50–60Hz, 3.0A
Charging voltage 14.4V/14.7V/15.8V and 28.8V/29.4V/31.6V
Start voltage 2.0v
Output Selectable, max 40A/12v or 20A/24v
Back current drain* less than 1Ah/month
Ripple** less than 4% of actual DC current
Ambient -20°C to +50°C
temperature (-4°f to +122°f)
Charger type 8 step fully automatic charging cycle
Battery types All types of 12v and 24v lead-acid batteries
(WET, Mf, Ca/Ca, AgM and gEl). Check
with your battery supplier for appropriate
charge information
Battery capacity 12v: 20–1200Ah, 24v: 10–600Ah
Dimensions 254 x 160 x 76mm (l x W x h)
Insulation class ip20
Weight 1.3kg without charge cable
Warranty 2 years
*) Back current drain is the current that drains the battery if the charger is not connected
to the mains. CTEK chargers have a very low back current.
**) The quality of the charging voltage and charging current is very important. A high
current ripple heats up the battery which has an aging effect on the positive electrode.
high voltage ripple could harm other equipment that is connected to the battery. CTEK
battery chargers produce very clean voltage and current with low ripple.

LIMITED WARRANTY

CTEK SWEDEN AB, issues this limited warranty to the original purchaser of
this product. This limited warranty is not transferable. The warranty applies
to manufacturing faults and material defects for 2 years from the date of
purchase. The customer must return the product together with the receipt
of purchase to the point of purchase. This warranty is void if the battery
charger has been opened, handled carelessly or repaired by anyone
other than CTEK SWEDEN AB or its authorised representatives. The
charger is sealed. removing or damaging the seal will void the warranty.
CTEK SWEDEN AB makes no warranty other than this limited warranty and
is not liable for any other costs other than those mentioned above, i.e. no
consequential damages. Moreover, CTEK SWEDEN AB is not obligated to
any other warranty other than this warranty.
