Current Audio FIT FastLoc FIT650FL User's Installation Manual

FIT FastLoc 65 and 80 Series
Focused Image Technology, In-Ceiling, Coaxial,
Infinite Baffle Loudspeaker with FastLoc Grille
The easy to install FIT-FL series is a full-range ceiling loudspeaker
incorporating new technology woofers with butyl rubber surrounds and
high grade pivoting tweeters. It features the revolutionary
Image Technology. This feature gives the user the unique Patented
Three Dimensional Positioning (3DP) of the woofer. The 3DP concept
allows the user to separately adjust the angle, tilt and rotation of the
woofer so you can direct the sound where you want it not just where you
installed it. The Positive Positioning Lock (PPL) device prevents baffle
movement and speaker vibrations. Two screws on either side of the
woofer pull the back plane tight and lock the position in place.
It also features the revolutionary FastLoc zero edge quick connect grille.
Architects and designers have resisted the size of the traditional bezel.
The FastLoc feature, found only at Current Audio, exhibits the smallest
exposed bezel that virtually disappears into the ceiling. But the major
feature is the Patent Pending design that allows for rapid install that
conforms to uneven surfaces and prevents the grill from falling off even in
earthquakes. The positive positioning locking device PPL prevents baffle
movement and speaker vibrations.
The speaker grille color is white, and is a close match to Frazee White
Shadow 181. It can be painted to match any décor. The speaker
enclosure is a durable UV-resistant material that allows for both indoor
and outdoor installations. Unlike other grilles that use magnets to hold
them on they must be made of steel that will rust. The perforated powder-
coated aluminum alloy grill is long-lasting, corrosion resistant and rust-
free.
Four built-in expanding transverse dog leg clamps permit installation with
or without pre-wire construction brackets in drywall or material with
thickness of 7/32" to 1 3/16".
Electrical connection, up to 12 gauge wire, is made by two gold plated
constant tension spring-loaded terminals.
With our limited 5 year warranty you are assured years of superior
trouble free operation.

SPECIFICATIONS for 65 Series

Driver
Tweeter, 1", Diffraction-less, Dome
Frequency Response
Power handling
SPL @ 1 Watt/1 meter
Impedance 8 ohm Nominal
Diameter x Depth 10 7/8"(27.6cm)x 5 5/8"(14.4cm)
Retro-fit Cutout Diameter 8 3/8" (21.4cm)
Part Number 92062 FIT650FL; 92008 FIT651FL;
92007 FIT652FL; 92006 FIT654FL
92002 FIT801FL; 92001 FIT802FL;
92000 FIT804FL
Manual URL www.currentaudio.com
Accessories NC6CB or NC8CB New Construction Bracket
Volume Control ZLoc VC25R, ZLoc VC50R,
ZLoc VC75S
Specifications subject to change without notice.
User's Installation Guide
Focused
FIT650FL FIT651FL
Injection Molder Carbon
MetaPlex Composite
Aluminum Ferrofluid
Silk Ferrofluid Cooled
42Hz-20kHz 40Hz-20kHz
5-100 Watts 5-125 Watts
90db
Fixed Crossovers 3 Position Crossovers
FIT652FL
Aluminum
Fiber
Aluminum Ferrofluid
Cooled Cooled
38Hz-20kHz
5-125 Watts
90db 91db
3 Position Crossovers
1830 John Towers Avenue El Cajon, CA 92020 Sales 866-927-7181
FIT654FL
Woven Carbon Fiber
Ceramic Coated Aluminum
Ferrofluid Cooled
35Hz-21kHz
5-150 Watts
91.5db
3 Position Crossovers
www.currentaudio.com
©2009 Current Audio LLC
RPA 12/09
FIT FastLoc Series 1209
