Current Audio PRO CECS80-70V User's Installation Manual

PRO CECS80-70V
8.0" 2-Way 8ohm/70Volt
Dual Purpose, 2-Way Loudspeaker
The dual purpose PRO CECS80-70V Constant Voltage
Distribution speaker is the perfect choice for either main
listening or sound reinforcement applications. It can be used in
household applications or commercial distributed public address
and sound systems. It is the choice of casinos. This full range
speaker supplies serious sound. It is provided with a switchable
8 ohm or 70 Volt input with adjustable wattage taps. If used with
100 volt systems the wattage taps will be 30 and 15 watts. DO
NOT use the 70 volt 30 watt tap on 100 volt systems.
The 8" talc filled polypropylene woofer cone and butyl rubber
surround are virtually impervious to the weather and insects. It
delivers shock and awe. The pivoting 5/8" polycarbonate
FerroFluid cooled dome tweeter presents clear crisp high
frequencies and voice. It complements the hard driving bass of
the woofer.
The speaker is housed in a painted steel back-can with a Safety
Tether connection. The back of the can houses the protected
wiring connections and switchable wattage taps or 8 ohm knob.
This speaker color offered is white or black. It can be painted to
match any décor. The speaker enclosure is a durable UV-
resistant material that allows for both indoor and outdoor
installations. The perforated powdered coated steel alloy grill is
long lasting, corrosion resistant.
Electrical connection via a BX style connector or ½" conduit
hole for is provided on the back cover. Up to 16 gauge wire, is
made by constant tension spring loaded terminals via a ½"
knock out terminal cover. An external switch on the back-can
allows selectable wattage taps of 30-15-7.5 or pass thru 8Ω.
With our limited 5 year warranty you are assured years of
superior trouble free operation.
CECS8070V Front
Part Number 92030 CECS8070V
Manual URL www.currentaudio.com
Accessories 92084 TB8 Tile Support Bracket
Specifications subject to change without notice.
Ceiling Speaker
CECS8070V Back
User's Installation Guide
SPECIFICATIONS
Driver
Tweeter, 5/8" (15.875mm) Dome
Frequency Response
Power Handling 8Ω
Power Handling 70Volts
SPL @ 1 Watt/1 meter
Impedance 8 ohm Nominal
Retrofit Cutout Diameter
Height X Width X Can Depth
Color
CECS8070T Side
1830 John Towers Avenue El Cajon, CA 92020 Sales 866-927-7181
CECS80-70V
8" Mica Filled Polypropylene
Pivoting,Polycarbonate
50Hz-19.5kHz
5-85 Watts @ 8Ω
30-15-7.5 Watts @ 70Volts
88.5db
Fixed Crossovers
9 7/16" (240 mm)
8"(203.2mm) X 10"(273mm) X
7.5"(190.5mm)
White or Black
CECS8070V Back
www.currentaudio.com
©2009 Current Audio LLC
CECS8070V Rev 2 RPA 04082011
