Current Audio OC8 User's Installation Manual

OC8 Indoor/Outdoor Speaker User's Installation Guide
8.0" 2-Way, Indoor/Outdoor
Dual Purpose, Full Range Loudspeaker
The dual purpose OC8 Indoor/Outdoor speaker is the perfect
choice for either main listening or sound reinforcement
applications. This ported bass reflex speaker supplies
serious sound.
The 8" graphite mica mineral impregnated polypropylene
woofer cone and butyl rubber surround are virtually
impervious to the weather and insects. It delivers shock and
awe. The 1" titanium tweeter presents clear crisp high
frequencies to complement the hard driving bass.
The OC8 can also be utilized as a stand alone subwoofer
with or without an equalizer. In this function the OC8 can be
employed to launch deep bass into the listening area further
enhancing the sound quality of your system.
This speaker color is offered is black. It can be painted to
match any décor. The speaker enclosure is a durable UV-
resistant material that allows for both indoor and outdoor
Installations. The perforated powdered coated aluminum
alloy grill is long lasting, corrosion resistant and rust free.
Included in the package is a universal heavy gauge
mounting kit. The kit includes a rust proof serrated U bracket
and large easy to install positive locking knobs. The knobs
are attached to the matching serrated area on the zero
balanced point of the enclosure via threaded studs. This
allows the speaker to easily be positioned to place the sound
where you want it. Hand tightening the knobs will clamp the
speaker in place. The speaker may be mounted either
horizontally or vertically.
Electrical connection, up to 12 gauge wire, is made by gold
plated constant tension spring loaded terminals.
This speaker is also available in a 70 volt version with
various wattage taps and a ½" knock out terminal cover.
One Hardwood Tree is planted in the National Forest to
offset the Styrofoam packaging on each pair.
With our limited 5 year warranty you are assured years of
superior trouble free operation.
Part Number 92038 OC8B Black
Manual URL www.currentaudio.com
Accessories Volume Control ZL25R, ZL50S
Specifications subject to change without notice.

SPECIFICATIONS

Driver
Tweeter, 1" (25.4mm) Dome
Frequency Response
Power handling
SPL @ 1 Watt/1 meter
Impedance 8 ohm Nominal
Height X Width X Depth
Color
OC8B Top
1830 John Towers Avenue El Cajon, CA 92020 Sales 866-927-7181
OC8
8" Mica Filled Polypropylene
Titanium
42Hz-20kHz
5-150 Watts
90db
Fixed Crossovers
16.5"(419m) X 11"(279.4mm) X
10"(254mm)
Black
OC8B Back
www.currentaudio.com
©2009 Current Audio LLC
OC8 RPA 060210
