Rack Mount Series
CCTV Power Supplies
Installation Guide
Models Include:
• R615DC416
- 6-15VDC @ 4 amp.
- Sixteen (16) Fuse Protected
Outputs.
• R615DC616
- 6-15VDC @ 6 amp.
- Sixteen (16) Fuse Protected
Outputs.
• R615DC1016
- 6-15VDC @ 10 amp.
- Sixteen (16) Fuse Protected
Outputs.
• R615DC416CB
- 6-15VDC @ 4 amp.
- Sixteen (16) PTC Protected
Outputs.
• R615DC616CB
- 6-15VDC @ 6 amp.
- Sixteen (16) PTC Protected
Outputs.
• R615DC1016CB
- 6-15VDC @ 10 amp.
- Sixteen (16) PTC Protected
Outputs.
Rev. 120403
Advertisement
Table of Contents
Related Manuals for Altronix R615DC416
Summary of Contents for Altronix R615DC416
-
Page 1: Installation Guide
Rack Mount Series CCTV Power Supplies Installation Guide Models Include: • R615DC416 • R615DC416CB - 6-15VDC @ 4 amp. - 6-15VDC @ 4 amp. - Sixteen (16) Fuse Protected - Sixteen (16) PTC Protected Outputs. Outputs. • R615DC616 • R615DC616CB - 6-15VDC @ 6 amp. - Page 2 (blown fuse or tripped PTC) the corresponding LED will not be illuminated (Fig. 1, pg. 3). a. Blown fuse (R615DC416) - Set power switch on back of unit to the OFF position (Fig. 1E, pg. 3). Remove front faceplate to access fuses. Replace with fuses rated @ 3.5A/250VA (Altronix model # Fuse1).
- Page 3 Earth GND) LED's LED's LED's LED's Used on PTC Models PTC1 + AC -- + DC -- ALTRONIX CORP. BKLYN, NY 11220 MADE IN U.S.A. XFMR XFMR Power Supply Board Trimpot ALTRONIX CORP. BROOKLYN, NY 11220 MADE IN USA Removable Terminal...
- Page 4 19.125" .75" Altronix is not responsible for any typographical errors. Altronix Corp. 140 58th Street, Brooklyn, New York 11220 USA, 718-567-8181, fax: 718-567-9056 web site: www.altronix.com, e-mail: info@altronix.com, Lifetime Warranty, Made in U.S.A. MEMBER IIR615DC Series B18D - 4 -...
