Page 1: Installation Guide
Rack Mount Series CCTV Power Supplies Installation Guide Models Include: • R615DC1016 • R615DC1016CB - 6-15VDC @ 10A. - 6-15VDC @ 10A. - Sixteen (16) Fuse Protected Outputs. - Sixteen (16) PTC Protected Outputs. Rev. 110909... -
Page 2: Specifications
Remove front faceplate to access fuses. Replace with fuses rated @ 3.5A/250VA (Altronix model # Fuse1). b. Tripped PTC (R615DC1016CB) - To reset PTC set power switch on back of unit to the OFF position. After approximately 30 secs. set power switch to the ON (RESET) position (Fig. 1e, pg. 3). - Page 3 Earth GND) LED's LED's LED's LED's Used on PTC Models PTC1 + AC -- + DC -- ALTRONIX CORP. BKLYN, NY 11220 MADE IN U.S.A. XFMR XFMR Power Supply Board Trimpot ALTRONIX CORP. BROOKLYN, NY 11220 MADE IN USA Removable Terminal...
- Page 4 3.26” x 19.125” x 8.5” (83mm x 486mm x 216mm) View from back BACK 3.26" 83mm 17.625" 447.7mm BOTTOM 8.5" 216mm View from front FACEPLATE 19.125" 486mm 0.75" 19.05mm Altronix is not responsible for any typographical errors. MEMBER E12Q R615DC1016 Series...
