INSTALLER: LEAVE THESE INSTRUCTIONS WITH THE APPLIANCE
INSTALLATION MANUAL
Electric 30-inch Free-standing,
Slide-in & Drop-in Ranges
PLEASE KEEP THIS MANUAL FOR FUTURE REFERENCE
THE MANUAL IS INTENDED TO ASSIST IN THE INITIAL INSTALLATION AND ADJUSTMENTS OF THE RANGE.
SPECIAL WARNING
Only qualified personnel should
install or service this range.
Read "Safety Instructions" in the
Use & Care book before using
range.
Improper installation, adjustment,
alteration, service, maintenance or
use of range can result in serious
injury or property damage.
Your range may not be equipped with some of the features referred
to in this manual.

CLEARANCE DIMENSIONS

For complete information in regard to installation
of free-standing, drop-in and slide-in ranges,
see figures 1 through 4 on pages 2, 3 and 4. For
SAFETY CONSIDERATIONS do not install a
range in any combustible cabinetry which is not
in accord with the installation clearances shown
in figure 1.
CAUTION: Some cabinets and building
materials are not designed to withstand the
heat produced by the normal safe operation
of a listed appliance. Discoloration or
damage, such as delamination, may occur.
8101P371-60
(10-2000-00)
