Page 1: User Manual
Gigabit Ethernet PoE+ Unmanaged Switch POEGE24T2SFP User Manual Version 1.0.0.1 – Oct 2014... -
Page 2: Table Of Contents
4. Powering on the Switch ..........8 5. LED Description .............. 9 6. Network Connection ............. 10 7. Technical Specifications ..........11 Appendix A. Troubleshooting .......... 12 Appendix A. RJ-45 Connections ........13 Alloy Computer Products Pty Ltd Copyright ©2014... -
Page 3: Compliances And Safety Statements
- Surge immunity test according to IEC 61000-4-5:2005 - Immunity to conducted disturbances, Induced by radio-frequency fields:IEC 61000-4-6:2008 - Power frequency magnetic field immunity test according to IEC 61000-4-8:2009 - Voltage dips, short interruptions and voltage variations immunity test Alloy Computer Products Pty Ltd Copyright ©2014... - Page 4 This unit operates under SELV (Safety Extra Low Voltage) conditions according to IEC 60950. The conditions are only maintained if the equipment to which it is connected also operates under SELV conditions. Alloy Computer Products Pty Ltd Copyright ©2014...
- Page 5 Please follow the instructions in the user manual/quick install guide carefully to connect the device to your PC or other electronic product. Any invalid connection may cause a power or fire risk. Do not place this device on an unstable surface or support. Alloy Computer Products Pty Ltd Copyright ©2014...
-
Page 6: Introduction
The POEGE24T2SFP is the ideal solution for adding low cost PoE capability to your newly deployed IP PBX and IP Phone infrastructure. Features ... -
Page 7: Installation
Before connecting the Power Cord please ensure the appropriate voltage switch is set, this switch can be found at the back of the POEGE24T2SFP. Leave at least 10cm of space at the front and rear of the switch to ensure adequate ventilation. -
Page 8: Powering On The Switch
Connect the female connector of the power cord here, and the male connector to the AC power outlet. Make sure the voltage of the power supply meets the requirement of the input voltage. Fig. 4 Rear of the Switch Alloy Computer Products Pty Ltd Copyright ©2014... -
Page 9: Led Description
10/100Mbps: Orange 1000Mbps: Green LINK Blink Traffic is present on port No link established PD PoE device has successfully connected to the port. No POE device connected Fig. 5 Front panel of switch Alloy Computer Products Pty Ltd Copyright ©2014... -
Page 10: Network Connection
Make sure each twisted pair cable does not exceed 100 meters (328 ft) in length. 3. As each connection is made, the relevant port LED (on the switch) corresponding to each port will turn on green to indicate that the connection is valid. Alloy Computer Products Pty Ltd Copyright ©2014... -
Page 11: Technical Specifications
Operating Temperature: 0°C - 40°C Storage Temperature: -10°C - 70°C Environment Operating Humidity: 10%~90% non-condensing Storage humidity: 5%~90% non-condensing Power Supply AC 100V ~ 240V 50/60Hz (Internal Power Supply) Certification RCM, CE, FCC, RoHS Alloy Computer Products Pty Ltd Copyright ©2014... -
Page 12: Appendix A. Troubleshooting
However, if the unit powers off after running for a while, check for loose power connections, power losses or surges at the power outlet. If you still cannot isolate the problem, the internal power supply may be defective. Alloy Computer Products Pty Ltd Copyright ©2014... -
Page 13: Appendix A. Rj-45 Connections
Below is a diagram of a typical straight through and cross-over cable connection: Fig. 5 Straight Through Cable connection Fig. 6 Cross-Over Cable connection Alloy Computer Products Pty Ltd Copyright ©2014...
