System Inputs Table - Inner Range CONCEPT IQ User Manual

Version 2.02 December-2002
The Table below shows:
1) The Input Number that each System Input is mapped to for reporting to a Central Monitoring Station.
2) The Zone Lamp that each System Input is mapped to when viewing the "Fault History" (NEXT 13)
Zone Lamp Flashing = Currently in Alarm.
Zone Lamp On = Has been in alarm in the last 5 Arming periods.
3) A description of each type of System Alarm.
SYSTEM ALARM
AC Fail
Low Battery
Cabinet Tamper
Siren Monitor Alarm
LAN Fuse fail
Battery Fuse fail
Comms Fail
System Reset
Keypad Lockout
Zone Self Test Fail
Keypad Medical Alm
Keypad Panic Alarm
Keypad Duress Alarm
Keypad Fire Alarm
Test Report

8. System Inputs Table

I/P Zone DESCRIPTION
No. Lamp
101 1 The AC mains has failed, or has been absent for more than the
AC Fail delay time.
102 2 Battery voltage is too low to provide backup power if AC fails.
103 3 Un-authorised removal of cabinet cover or removal of the
cabinet from it's mounting surface.
104 4 The Siren speaker is disconnected from the Control Panel.
105 5 LAN fuse has blown. Short circuit or over-current condition.
106 6 Battery fuse has blown. Short circuit or over-current condition.
107 7 System failed to report.
108 8 The system has been powered down and powered up again.
Enter: PIN Code, <OFF> to Clear.
You should reset the Time and Date.
109 9 System has registered 5 incorrect PIN code attempts in a row
and the Keypad is now locked out for a period of time.
110 10 One or more Zone Inputs have failed the Zone Self Test.
111 11 The Medical Alarm has been activated on a Terminal keypad.
112 12 The Panic Alarm has been activated on a Terminal keypad.
113 13 A Duress PIN code has been entered on a Terminal keypad.
114 14 The Fire Alarm has been activated on a Terminal keypad.
120 - A Test report transmission has been sent.
31
