Table Of Contents - Inner Range CONCEPT IQ User Manual

Version 2.02 December-2002
System Details ............................................................................. 2
1. Introduction
1.1 System Overview ........................................................................... 4
1.2 Types of Users. Installer, Master & Normal Users. .................... 5
1.3 Default Users ................................................................................. 5
2. The LED Terminal (Operator Terminal)
2.1 Special key functions. .................................................................... 6
2.2 Beeper indications. ........................................................................ 6
2.4 Lamp indications. ........................................................................... 7
3. User Operations
3.1 Quick Arming .................................................................................. 8
3.2 Arming / Dis-arming a Single-Area system. ................................. 8
3.3 Arming / Dis-arming Areas in a Multi-Area system. ..................... 8
3.4 Arming / Dis-arming individual Areas in a Multi-Area system. .... 9
3.5 If the selected Area/s will not Arm. ............................................... 9
Unsealed Zones. ...................................................................... 9
Force Arming. ........................................................................... 9
3.6 Alarm Display after Disarming ...................................................... 9
3.7 Isolating (Bypassing) Zone Inputs ................................................ 10
Isolating (Bypassing) System Inputs ............................................ 10
3.8 Emergency Alarm activation. -Panic, Fire and Medical Alarms. . 10
3.9 PIN Code Duress alarm activation ............................................... 11
3.10 Reset SmokeDetectors .................................................................. 11
3.11 Day Alarm On / Off. ........................................................................ 11
3.12 View Alarm History. ....................................................................... 12
3.13 View Fault History .......................................................................... 12
3.14 View Zone Self Test History. ......................................................... 13
3.15 Display Controller Firmware Version. ........................................... 13
4 Master Operations
4.0 Accessing the Operational Modes ................................................ 14
4.1 Adding or Changing Users. ........................................................... 15
4.2 Deleting Users. .............................................................................. 17
4.3 Zone Walk Test Mode. .................................................................. 18
4.4 Siren and Auxiliary Control and Test mode. ................................ 18
4.5 Test Transmission. (Test report) .................................................. 19
4.6 Battery Test. ................................................................................... 19
4.7 Answer Phone. ............................................................................... 19
4.8 View or Edit the Primary and Secondary Telephone numbers. .. 20
4.9 View or Edit the Call Divert Telephone numbers. ........................ 22
4.10 View or Set the Time and Date. .................................................... 24
5 Telephone Remote Control ........................................................ 26
6 Wireless Remote Control ............................................................ 28
7 Domestic Dialer Reporting ......................................................... 30
8 System Inputs Table .................................................................... 31
